ELECTRIC INSTANTANEOUS WATER HEATER
INSTALLATION GUIDE AND OWNERS MANUAL
MODELS COVERED:-
READ THE GENERAL SAFETY SECTION BEGINNING ON THE INSIDE COVER
AND THEN THIS ENTIRE MANUAL BEFORE INSTALLING OR OPERATING THIS
WATER HEATER. IF YOU DON'T FOLLOW THE SAFETY RULES, THE UNIT WILL
NOT OPERATE PROPERLY AND IT COULD CAUSE DEATH, SERIOUS BODILY
INJURY AND/OR PROPERTY DAMAGE. READ ALSO THE ENCLOSED
WARRANTY CARD. WARRANTY OF THIS WATER HEATER WILL DEPEND ON
PROPER INSTALLATION AND OPERATION. THE WARRANTY SHALL BE VOID IF
THE DESIGN HAS BEEN ALTERED IN ANY WAY WHATSOEVER. THE
MANUFACTURER OF THIS HEATER WILL NOT BE LIABLE FOR ANY DAMAGES
BECAUSE OF FAILURE TO COMPLY WITH THE INSTALLATION AND
OPERATING INSTRUCTIONS OUTLINED ON THE FOLLOWING PAGES.
THIS UNIT HAS MULTIPLE POWER SOURCES. ENSURE TO DISCONNECT ALL POWER
THE INSTALLATION MUST CONFORM WITH THE INSTRUCTIONS IN THIS
MANUAL; ELECTRIC COMPANY RULES; AND THE LOCAL CODES, OR IN
THE ABSENCE OF LOCAL CODES, WITH THE LATEST EDITION OF THE
NATIONAL ELECTRICAL CODE. THIS PUBLICATION IS AVAILABLE FROM
YOUR LOCAL GOVERNMENT OR PUBLIC LIBRARY OR ELECTRIC COMPANY
IF YOU REQUIRE ANY HELP OR HAVE ANY QUESTIONS RELATING TO THE
INSTALLATION OR PERFORMANCE OF THIS HEATER, PLEASE CALL OUR
TECHNICAL SERVICE DEPARTMENT TOLL FREE : 1-800-543-6163.
HAVE THE INFORMATION LISTED BELOW BEFORE CALLING :
SERIAL NO.
EEMAX
HOME ADVANTAGE
SS015240TC
SS019240TC 208-240V
WARNING
SUPPLIES BEFORE SERVICING.
MODEL NO.
208-240V
INSTALLATION DATE
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS015240TC and is the answer not in the manual?

Questions and answers

Related Manuals for EemaX SS015240TC

Summary of Contents for EemaX SS015240TC

  • Page 1 EEMAX HOME ADVANTAGE ELECTRIC INSTANTANEOUS WATER HEATER INSTALLATION GUIDE AND OWNERS MANUAL MODELS COVERED:- SS015240TC 208-240V SS019240TC 208-240V WARNING READ THE GENERAL SAFETY SECTION BEGINNING ON THE INSIDE COVER AND THEN THIS ENTIRE MANUAL BEFORE INSTALLING OR OPERATING THIS WATER HEATER. IF YOU DON’T FOLLOW THE SAFETY RULES, THE UNIT WILL NOT OPERATE PROPERLY AND IT COULD CAUSE DEATH, SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE.

  • Page 2: General Safety

    GENERAL SAFETY The “Eemax Home Advantage” heater is specifically designed to take in hot or cold water and heat it to temperatures suitable for normal domestic usage up to a maximum of 140 F(60 C). To obtain optimum performance and energy savings, the unit should be located as near as possible to the point of use.

  • Page 3: Mounting The Unit

    If local codes require the use of a temperature and pressure relief valve it should be installed on the outlet hot water pipe before the outlet ball valve. Showers and the whole house, cabin or condo Lavatory MODELS: SS015240TC 208-240V Shower SS019240TC 208-240V Kitchen About 0.70-3.0 GPM at showering temperature.
  • Page 5 MINIMUM - 8” CLEARANCE ABOVE UNIT serial # MOUNTING HOLES TERMINALS AT RELAYS ELECTRICAL HOOK-UP 240/208 V C/B #4 C/B #3 GROUND LUGS Use pre-install quick connect water connections To 2 Independent circuit breakers, properly rated per UL499 18.4, 150% of the products rating.

  • Page 7: Plumbing Hook-Up

    II. PLUMBING HOOK-UP 1) The unit is supplied with ¾’’ NPT fittings and pre-fitted quick connect/disconnect fittings, Use this if you prefer. You may remove the shark bite type fitting and use the standard ¾’’ NPT fitting if you desire. Remove the shark bite type fitting while the unit is NOT attached to the wall.

  • Page 8: Electrical Hook-Up

    III. ELECTRICAL HOOK-UP WARNING THIS UNIT HAS MULTIPLE POWER SUPPLIES. ENSURE TO DISCONNECT ALL POWER SUPPLIES BEFORE SERVICING THE WATER HEATER. “Eemax Home Advantage” heaters are manufactured to the following specifications: Figure 4 M O DE L TY P E V oltage...
  • Page 9 IV COMMISSIONING YOUR HEATER IMPORTANT BEFORE SWITCHING “ON” THE POWER AT THE MAIN CIRCUIT BREAKER PANEL MAKE SURE THAT THE HOT WATER CIRCUIT IS FREE OF AIR POCKETS OR ELSE PREMATURE FAILURE OF THE ELEMENT WILL OCCUR. TO DO THIS OPEN ALL HOT WATER OUTLETS ONE AT A TIME FOR A MINUTE OR TWO UNTIL THE WATER FLOW IS CONTINUOUS AND FREE FROM “GULPING”...

  • Page 10: Troubleshooting

    The resistance reading should be roughly 5.0 ohms. If the resistance is much greater than this value, call Eemax for a replacement element. 5) ECO TRIPPED (High Limit Thermostat) TURN OFF THE TWO MAIN CIRCUIT BREAKERS! Reset by pushing in red button on each heater module.
  • Page 11 EX1049-1 TRIAC EX278C EX1050-1...
