OMRON ULTRASONIC
NEBULISER
NE-U17
Model
Instruction Manual
■ Thank you very much for purchasing this OMRON
Ultrasonic Nebuliser.
■ Be sure to read this instruction manual carefully
before using the unit so that you can use it safely and
correctly.
■ Please keep this instruction manual always at hand
for future reference.
■ This unit is a medical instrument. Be sure to use the unit properly
according to instructions given by medical professionals.
Only use medications as prescribed and instructed by your doctor.

Table of Contents

Be sure to Read This Section
Intended Use .............................. 2
Notes on Safety .......................... 3
About the Product
Features of the Product .............. 6
Names of the Parts .................... 8
How to Use the Unit
before Inhalation ...................... 9
How to Inhale ........................... 11
(using optional parts) ............ 13
How to Take Care of the Unit
How to Store the Unit ............... 18
Specifications
Troubleshooting ........................ 19
Specifications ........................... 20
List of Optional Parts ................ 22
IM-NE-U17-E-01-11/2010
EN
DE
NL
FR
IT
ES
1615886-5E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra Air NE-U17 and is the answer not in the manual?

Questions and answers

Summary of Contents for Omron Ultra Air NE-U17

  • Page 1: Table Of Contents

    Model Table of Contents Instruction Manual Be sure to Read This Section ■ Thank you very much for purchasing this OMRON Exemptions from Liabilities ..1 Ultrasonic Nebuliser. Intended Use ......2 ■ Be sure to read this instruction manual carefully Notes on Safety ......
  • Page 2: Exemptions From Liabilities

    However, if you find any omission or error, please inform your local OMRON representative or dealer. 3. It is prohibited to copy all or a part of this Instruction Manual without getting OMRON’s permission. Unless you use this Instruction Manual for your personal (corporate) purpose, you are not allowed to use it without OMRON’s permission in accordance with the Copyright...
  • Page 3: Intended Use

    Intended Use Medical Purpose This product is intended to be used for inhaling medication for respiratory disorders or for humidification in combination with oxygen therapy. Intended User • Legally certified medical experts, such as doctor, nurse and therapist, or healthcare personnel or patient under the guidance of qualified medical experts.
  • Page 4: Notes On Safety

    Be sure to immediately dry the cleaned and disinfected parts, then store them in a dry place in order to prevent them from getting contaminated in the future. In case of any problem with your nebuliser please contact your local OMRON service representative (address on/ inside package).
  • Page 5 Do not disassemble, repair, or modify the unit. • The unit may malfunction or cause injury. Contact your nearest OMRON service representative. Do not use a power cord other than the supplied one. • The unit may ignite or you may suffer electric shock.
  • Page 6 (1) Power-off the unit and unplug the power plug from the electric outlet to make the unit inoperable. (2) Write “Faulty-Do not use” on the main unit so that it will not be used. (3) Contact the store where you purchased the unit or the nearest OMRON dealer.
  • Page 7: Features Of The Product

    Features of the Product Aerosol= Nebulised About the principle of medication nebulisation in the NE-U17 ➀ The NE-U17 transmits the energy of ultrasonic vibration from the vibrator located at the bottom of the water tank into water. ➁ The ultrasonic vibration is transmitted to the medication in the medication cup through the water in the water tank.
  • Page 8: Composition Of The Product

    Composition of the Product Inhalation hose (M) with a cuff, 70 cm Mouthpiece set Two medication cups Main unit ■ Instruction manual (with warranty card) Power cord – As the unit is a Class I electroshock protection type, be sure to use only the supplied power cord with an “earth”.
  • Page 9: Names Of The Parts

    Names of the Parts * indicates replaceable supplies. Medication cup cover Air duct cover Washer Fan cover Mouthpiece set Air filter case Air filter* Handle Inhalation hose M Display of air volume Medication cup* (Refer to the “Description of the LCD Display” on Page 7.) Display Air volume adjustment knob Display of nebulisation rate...
  • Page 10: How To Prepare The Unit Before Inhalation

    How to Prepare the Unit before Inhalation – Clean the parts before starting the inhalation. Filling the cooling water. [Parts that can be disinfected by boiling] (For the disinfecting method, refer to Page 17.) Submerge these parts in a container filled with 1) Remove the nebulisation section sufficient water and boil for 10 minutes.
  • Page 11 How to Prepare the Unit before Inhalation Filling medication into the medication Assembling and attaching the cup. nebulisation unit to the main unit 1) Remove the medication cup cover 1) Fix the nebulisation unit by rotating by rotating it counterclockwise. the medication cup cover-fixing lever counterclockwise.
  • Page 12: How To Inhale

    How to Inhale Setting the inhalation time. Push the START/STOP Button ( The fan will rotate and the unit starts Setting the inhalation time by rotating to nebulise. the timer knob clockwise. 1) To set the timer The timer can be adjusted by 1 minute when setting the time up to 15 minutes.
  • Page 13 How to Inhale Inhaling the aerosol. Finishing the treatment. <Example of correct use> When the timer is used: The buzzer sound notifies the completion of time set by the timer and the unit stops operation. When the operation ends, “0” on the display illuminates and the display changes to the initial set time.
  • Page 14: How To Inhale (Using Optional Parts)

    How to Inhale (Using Optional Parts) Using the unit for a long time By using the optional “long time nebulisation set (4997217-7)” and the “supply medication set (4997206-1)”, the unit can nebulise continuously for a long time. ➀ Remove the medication cup cover of the main unit. Attach an optional long time nebulisation set in place of the medication cup cover and assemble the unit according to the procedure shown on Page 10.
  • Page 15 How to Inhale (Using Optional Parts) Oxygen supply pipe Using a bacterial filter Having passed through a bacterial filter, the filtered air can be supplied to the inside of the long time nebulisation set. ➀ Remove the medication cup cover and assemble the long time nebulisation set with the main unit. To assemble, use the long time nebulisation set in place of the medication cup cover by following the procedure shown on Page 10.
  • Page 16: How To Take Care Of The Unit

    How to Take Care of the Unit How to Take Care of the Parts Turn off the power by pushing the ON/ OFF Button ( ), and unplug the power plug from the electric outlet. Remove the mouthpiece set, or inhalation mask.
  • Page 17 How to Take Care of the Unit How to Take Care of the Air Filter Replace the air filter when it becomes dirty. ➀ Remove the nebulisation unit from the main Nebulisation section device. ➁ Remove the fan cover by lifting it up. ➂...
  • Page 18: How To Disinfect The Unit

    How to Disinfect the Unit How to Disinfect the Unit Disinfection by boiling cannot be done to some parts. They may become deformed. [Parts that can be disinfected by boiling] Medication Washer cup cover Inhalation hose (M) with a cuff, 70 cm [Parts that cannot be disinfected by boiling] Air filter case Air duct cover...
  • Page 19: How To Store The Unit

    How to Disinfect and Store the Unit Sterilization with ethylene oxide gas (E.O.G.) Observe the Instruction Manual of the sterilizer and consult with the manufacturer of the E.O.G. sterilizer for the details. Some of the rubber and plastic parts of the nebuliser may have residual ethylene oxide gas. After sterilization, consult with the manufacturer of the sterilizer and provide sufficient aeration until the safe level to human beings can be obtained.
  • Page 20: Troubleshooting

    E1 is displayed. Contact the nearest OMRON dealer. stopped. – If the unit does not operate normally after taking the above-mentioned measures, do not touch the internal mechanism and consult the store where you purchased the unit or the nearest OMRON dealer.
  • Page 21: Specifications

    • Subject to technical modification without prior notice. • This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co., Ltd., Japan. • The device may not work if the temperature and voltage conditions are different to those defined in the specifications.
  • Page 22 EN60601-1-2 standard has been implemented. This standard defines the levels of immunity to electromagnetic interferences as well as maximum levels of electromagnetic emissions for medical devices. This medical device manufactured by OMRON Healthcare conforms to this EN60601-1-2:2007 standard for both immunity and emissions.
  • Page 23: List Of Optional Parts

    List of Optional Parts Medication cup Bacterial filter Air filter set Air filter (4997211-8) (4997213-4) (4997214-2) (4997215-0) Used to transmit the ultrasonic Used for inhalation such as for Protects the unit from the dust in air. Material: PS vibration. (If it has any damage or tracheal lavage.
  • Page 24 Manufacturer OMRON HEALTHCARE Co., Ltd. 24, Yamanouchi Yamanoshita-cho, Ukyo-ku, Kyoto, 615-0084 JAPAN EU-representative OMRON HEALTHCARE EUROPE B.V. Kruisweg 577, 2132 NA Hoofddorp, THE NETHERLANDS www.omron-healthcare.com OMRON MATSUSAKA Co., Ltd. Production facility 1855-370, Kubo-cho, Matsusaka-city, Mie-prefecture 515-8503, Japan OMRON HEALTHCARE UK LIMITED Opal Drive, Fox Milne Milton Keynes, MK15 0DG U.K.
