- Page 1 OPERATION AND MAINTENANCE MANUAL SKD-B110LZ-42mm SKD-B112LZ-42mm SKD-B110LZ-26.7mm SKD-B112LZ-26.7mm DC-TYPE Automatic Non Carbon-Brush Series KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com Y2F130A-1-006...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injury. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 4) Power tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use power tool if switch does not turn it on or off.
-
Page 5: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 6 Operations Cautions 1) Before changing bits from B110LZ Series screwdriver, make sure the Forward / Reverse switch stays at the middle position The screwdriver must be unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 7: Description Of Operation
CAUTION ● Do not drop or abuse the tool. ● Whenever a tool is not being used, position the Power Switch to the “OFF” position and unplug the power cord. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. -
Page 8: Do Not Attempt To Repair This Electric Screwdriver
All repairs and maintenance of this tool and its word must be performed by an authorized service center. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. Repairs should by made only by authorized, trained personnel. Consult your nearest KILEWS authorized service center. -
Page 9: Specifications
No. 0．．．． Bit use in dia 1.8~2.0mm screw B110LZ-42mm/B112LZ-42mm/B113LZ-42mm with BIT M3 Ø4×40 00# & 0# 1 Pcs. Each B110LZ-26.7mm/B112LZ-26.7mm with BIT Ø1.5*23.5 00# 2 Pcs. Each 2.Suspension rack and Torque fixing ring acceptable for use with the tool are available from KILEWS catalogue. -
Page 10: Torque Adjustment Operation
Torque Adjustment Operation To adjust the torque on these screwdrivers. Proceed as follows : 1. Determine the torque output of the tool by checking a tightened Fastener with a torque wrench. 2. Increase or decrease the torque by rotating the Spring Adjusting Ring. Rotating the Ring clockwise(+) to a higher number on the torque Scale increase torque output while rotating the Ring counterclockwise(-) to a lower number decreases the torque output.
