INDUSTRIAL MONITORING INSTRUMENTATION DIVISION
sensor – model 603C01
The sensor supplied with the kit is a general purpose industrial accelerometer, Model 603C01. Please refer to the
enclosed specifications on the 603C01 for proper operation of the sensor.
headphones – model 070A47
The headphones are stereo-type with built-in, individual volume controls. The volume knobs are located on the
side of the cuffs. Please keep volume to a comfortable level in order to maintain audio safety.
magnetic mounting base – model 080A131
The supplied magnet can be used for either curved or flat surfaces. To maximize frequency response, always
dab a layer of silicone grease or equivalent between the sensor and the magnet. To minimize errors in readings,
proper surface preparation should be observed. See sensor manual for further information.
cable assembly – model 050BQ006AC
The cable assembly supplied is a 6 ft coiled cable with a right-angle military connector on one end to a BNC plug
on the other. Screw the military connector onto the sensor, and make sure it is hand tight. The BNC plug is then
inserted into the BNC jack on the meter labeled sensor.
PAGE 5
