Universal Electronics Cricket Kid's Remote Control User Manual

Remote control for ages 3 and up
Hide thumbs Also See for Cricket Kid's Remote Control:

Advertisement

Kids Remote 2006.fm Page 1 Tuesday, March 6, 2007 3:52 PM
Cricket Kid's Remote Control
For Ages 3 and Up
Users Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cricket Kid's Remote Control and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Universal Electronics Cricket Kid's Remote Control

  • Page 1 Kids Remote 2006.fm Page 1 Tuesday, March 6, 2007 3:52 PM Cricket Kid’s Remote Control For Ages 3 and Up Users Guide...
  • Page 2: Table Of Contents

    Kids Remote 2006.fm Page 2 Tuesday, March 6, 2007 3:52 PM TABLE OF CONTENTS Quick Start ..........3 Customizing the Image Compartment .
  • Page 3: Quick Start

    Kids Remote 2006.fm Page 3 Tuesday, March 6, 2007 3:52 PM QUICK START Cricket was designed specifically for children ages three or older, with safety and simplicity in mind. Cricket offers a simple means of control over what content your children are exposed to when they watch television.
  • Page 4 Kids Remote 2006.fm Page 4 Tuesday, March 6, 2007 3:52 PM Step 3: Set TV Control (Optional) With your television ON, and the remote in Programming mode, press the VOL + key. The LED blinks twice. Refer to the TV codes in the back of this manual.
  • Page 5: Customizing The Image Compartment

    Press and hold the key STAR(1) button until the LED blinks twice. STAR(1) now is programmed to the channel that you have assigned. Repeat steps above to assign a favorite channel to the MOON(2) button. Step 5: Set the remote to CHILD mode Set the switch located in the battery compartment to the left position to enter CHILD user mode.
  • Page 6: Low Battery Indication

    Kids Remote 2006.fm Page 6 Tuesday, March 6, 2007 3:52 PM Cut a photo or another image to the size of the circular image compartment and insert photo into opening. Replace clear plastic cover. LOW BATTERY INDICATION When the battery power is low in the Cricket, the LED flashes five times with each key-press.
  • Page 7: Functions And Key Charts

    Kids Remote 2006.fm Page 7 Tuesday, March 6, 2007 3:52 PM FUNCTIONS AND KEY CHARTS Use the illustration below to locate features on the Cricket and then study the Key Charts (on the next three pages) to learn how they function. www.urcsupport.com/cricket...
  • Page 8 Key Charts Function Press ON/OFF to turn the television and cable box on or off. The STAR(1) and MOON(2) keys can be programmed to jump directly to the channel of your choice. When in programming mode, STAR is the 1 key and MOON is the 2 key, VOL + turns the TV volume up.
  • Page 9: Additional Programming Options

    Kids Remote 2006.fm Page 9 Tuesday, March 6, 2007 3:52 PM ADDITIONAL PROGRAMMING OPTIONS Locate the three position switch within the battery compartment. Set the switch to the middle position P to enter programming mode. When programming is complete, set the switch to either CHILD user mode or ADULT user mode before replacing the battery compartment door.
  • Page 10: Advanced Functions

    Kids Remote 2006.fm Page 10 Tuesday, March 6, 2007 3:52 PM Repeat steps above to assign another favorite channel. If the LED flashes one long blink, the entry failed and must be repeated. ADVANCED FUNCTIONS Most users won't need to perform any of the set-up procedures in this section.
  • Page 11 Kids Remote 2006.fm Page 11 Tuesday, March 6, 2007 3:52 PM SETTING CABLE CONTROL In the event that you need to update Cricket to control your cable set-top-box, you can program the remote as follows: While in CHILD or ADULT mode, hold down both MUTE and ON/OFF for three seconds, until the LED blinks twice.
  • Page 12 Kids Remote 2006.fm Page 12 Tuesday, March 6, 2007 3:52 PM • Connect the equipment into an outlet on a cir- cuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This equipment has been verified to comply with the limits for a class B computing device, pursuant to FCC Rules.
  • Page 13: Manufacturer's Codes

    Kids Remote 2006.fm Page 13 Tuesday, March 6, 2007 3:52 PM MANUFACTURER’S CODES Setup Codes for Cable Boxes/Converters 0003, 0008, 0014, 0017 Americast 0899 Amino 1602, 1822 Bell & Howell 0014 Bell South 0899 Clearmaster 0883 ClearMax 0883 Comcast 1982 Coolmax 0883 Digeo...
  • Page 14 Kids Remote 2006.fm Page 14 Tuesday, March 6, 2007 3:52 PM Sasktel 1737 Scientific Atlanta 1877, 0877, 0477, 0008, 0017 Sejin 1602 Sony 1006 Starcom 0003 Supercable 0276 Supermax 0883 Thomson 1256 Tocom 0012 Torx 0003 Toshiba 0000 Tristar 0883 0883 Viewmaster 0883...
  • Page 15: Setup Codes For Satellite Receivers

    Kids Remote 2006.fm Page 15 Tuesday, March 6, 2007 3:52 PM Setup Codes for Satellite Receivers AlphaStar 0772 Century 0856 Chaparral 0216 Coolsat 1806 Crossdigital 1109 DirecTV 1377, 0392, 0566, 0639, 1639, 1142, 0247, 0749, 1749, 0724, 0819, 1856, 1076, 1108, 0099, 1109, 1392, 1414, 1442, 1443, 1444, 1609, 1640 Dish Network System...
  • Page 16: Setup Codes For Tvs

    Kids Remote 2006.fm Page 16 Tuesday, March 6, 2007 3:52 PM Philips 1142, 0749, 1749, 0724, 1076, 0722, 0099, 1442, 0856 Proscan 0392, 0566 Proton 1535 RadioShack 0869 0566, 0855, 0143, 1392 Samsung 1377, 1276, 1108, 1109, 1442, 1609 0856 Sanyo 1219 Sony...
  • Page 17 Kids Remote 2006.fm Page 17 Tuesday, March 6, 2007 3:52 PM America Action 0180 Ampro 0751 Anam 0180, 0004, 0009, 0068 Anam National 0055, 0161 0030, 0003, 0019, 0052, 0137, 0185, 1365 Apex Digital 0748, 0879, 0765, 0767, 0890, 1217, 1943 Archer 0003 Astar...
  • Page 18 Kids Remote 2006.fm Page 18 Tuesday, March 6, 2007 3:52 PM Citizen 0060, 0030, 0092, 0039, 0046, 0056, 0186, 0280, 0561, 1928, 1935 Clairtone 0185 Clarion 0180 Classic 1984 Colt 1906 Commercial Solutions 1447, 0047, 1125, 1126 Compaq 0749, 0750 Concerto 0056 Contec...
  • Page 19 Kids Remote 2006.fm Page 19 Tuesday, March 6, 2007 3:52 PM Emerson 0154, 0236, 0463, 0180, 0178, 0171, 0282, 0623, 1394, 1905, 1909, 1911, 1913, 1928, 1929, 1944, 1963, 0280, 0270, 0185, 0183, 0182, 0181, 0179, 0177, 0158, 0039, 0038, 0019 Emprex 1422, 1546...
  • Page 20 Kids Remote 2006.fm Page 20 Tuesday, March 6, 2007 3:52 PM Havermy 0093 Helios 0865 Hello Kitty 0451 Hewlett Packard 1088, 1089, 1101, 1494, 1502 Hisense 0748 Hitachi 1145, 0145, 1960, 1904, 1445, 0797, 0770, 0723, 0576, 0413, 0409, 0279, 0227, 0173, 0151, 0097, 0095, 0056, 0038, 0032, 0016...
  • Page 21 Kids Remote 2006.fm Page 21 Tuesday, March 6, 2007 3:52 PM Kreisen 0876, 1474 0180, 0030, 0039, 0183, 0185, 0217, 0280 1265, 0178, 0442, 0700, 0823, 0829, 0856, 1178, 1325, 1378, 1423, 1637, 1758, 1934, 1993 Lloyd's 1904 Loewe 0136, 0633, 0693, 0694 Logik 0016 Luce...
  • Page 22 Kids Remote 2006.fm Page 22 Tuesday, March 6, 2007 3:52 PM Mitsubishi 0093, 1250, 0150, 0178, 1917, 1550, 1392, 1350, 1279, 1278, 0868, 0836, 0592, 0358, 0331, 0155, 0098, 0019, 0014 Monivision 0700, 0843 Motorola 0093, 0055, 0835 Moxell 0835 0060, 0030, 0019, 0049, 0056, 0091, 0185, 0216 Multitech...
  • Page 23 Kids Remote 2006.fm Page 23 Tuesday, March 6, 2007 3:52 PM Penney 0047, 0156, 0051, 0060, 0178, 0030, 1926, 1919, 1907, 1378, 1347, 0747, 0309, 0149, 0138, 0135, 0110, 0039, 0032, 0027, 0021, 0019, 0018, 0003, 0002 Petters 1523 Philco 0054, 0030, 0019, 0020, 0028, 0096, 0302 Philips...
  • Page 24 Kids Remote 2006.fm Page 24 Tuesday, March 6, 2007 3:52 PM 1447, 0047, 2002, 1958, 1953, 1948, 1922, 1919, 1917, 1907, 1547, 1347, 1247, 1147, 1047, 0747, 0679, 0278, 0254, 0174, 0135, 0090, 0038, 0029, 0019, 0018 Realistic 0154, 0180, 0178, 0030, 0019, 0032, 0039, 0056, 0165 Rhapsody...
  • Page 25 Kids Remote 2006.fm Page 25 Tuesday, March 6, 2007 3:52 PM Signature 0016 Signet 0800, 0844, 1262 SIM2 Multimedia 1297 Simpson 0186, 0187 Sinudyne 0347 Solarism 1220 Sony 1100, 0000, 0011, 0080, 0111, 0273, 0353, 0810, 0834, 1317, 1904, 1925, 1651 Soundesign 0180, 0178, 0179, 0186...
  • Page 26 Kids Remote 2006.fm Page 26 Tuesday, March 6, 2007 3:52 PM Teknika 0054, 0180, 0150, 0060, 0092, 0016, 0019, 0039, 0056, 0175, 0179, 0186, 0312, 0322 Telefunken 0702, 0056, 0074, 0101 Telemagic 0735 Tera 0031 Thomas 1904 Thomson 0209, 0210, 0625 0178, 0056, 0177 TNCi 0017, 0709...
  • Page 27: Setup Codes For Tvs (Dlp)

    Kids Remote 2006.fm Page 27 Tuesday, March 6, 2007 3:52 PM Wards 0054, 0178, 0030, 1156, 0866, 0202, 0179, 0174, 0165, 0111, 0096, 0080, 0056, 0029, 0028, 0027, 0021, 0020, 0019, 0016 Waycon 0156 Westinghouse 0885, 0889, 0890, 1282, 1577 White Westinghouse 0463, 0623, 1909 WinBook...
  • Page 28: Setup Codes For Tvs (Lcd)

    Kids Remote 2006.fm Page 28 Tuesday, March 6, 2007 3:52 PM Olevia 1610 Panasonic 0250, 0650, 1291 Pioneer 0679 Princeton 0717 1447 Samsung 0812, 0702 Sharp 0688, 0689 Toshiba 1256 Setup Codes for TVs (LCD) Accurian 1803 Action 0873 Akai 1935 1365 Apex Digital...
  • Page 29 Kids Remote 2006.fm Page 29 Tuesday, March 6, 2007 3:52 PM Kost 1262 Kreisen 0876, 1474 0856, 1178, 1993 Magnavox 1454, 0802, 1198, 1365, 1990 Marantz 0855 Maxent 0762, 1211, 1755 Micro 1436 Mintek 1603, 1990 Mitsubishi 1250 NetTV 0762 Niko 1581, 1618 Norcent...
  • Page 30: Setup Codes For Tv/Dvd Combos

    Kids Remote 2006.fm Page 30 Tuesday, March 6, 2007 3:52 PM Sylvania 0171, 1271, 1314, 1394 Symphonic 0171 Syntax 1144, 1240, 1331 Tatung 1286 Techview 0847 Teco 1040 Toshiba 0845, 1343, 1635, 1656 Ultra 1323 US Logic 1286 Vidikron 1398, 1629 Viewsonic 0857, 0864, 0885, 1330, 1578, 1627...
  • Page 31 Kids Remote 2006.fm Page 31 Tuesday, March 6, 2007 3:52 PM 1962 Konka 1939, 1940 1993 Magnavox 1963, 1990 Mintek 1990 Naxa 1998 Panasonic 1941 Philips 1961 Polaroid 1991 Prima 1933 1948, 1958, 2002 Samsung 1903 Sansui 1935 Sova 1952 Sylvania 1394, 1963 Toshiba...
  • Page 32: Setup Codes For Tv/Vcr Combos

    Kids Remote 2006.fm Page 32 Tuesday, March 6, 2007 3:52 PM Setup Codes for TV/VCR Combos Aiwa 1914 America Action 0180 Audiovox 0180 Broksonic 1905, 1911, 1929 Citizen 1928 Colt 1906 Curtis Mathes 1919 Daewoo 1909, 1928 Emerson 0236, 1905, 1909, 1911, 1913, 1928, 1929 Funai 1904...
  • Page 33: Setup Codes For Tv/Vcr/Dvd Combos

    Kids Remote 2006.fm Page 33 Tuesday, March 6, 2007 3:52 PM White Westinghouse 1909 Zenith 1904, 1909, 1911, 1929 Setup Codes for TV/VCR/DVD Combos Akai 1903 Broksonic 1938 Diamond Vision 1996 Emerson 1944 1944 Funai 1199, 1979 Magnavox 1944 Panasonic 1946, 1947 Polaroid 1992...
  • Page 34 Kids Remote 2006.fm Page 34 Tuesday, March 6, 2007 3:52 PM NOTES www.urcsupport.com/cricket...
  • Page 35 Kids Remote 2006.fm Page 35 Tuesday, March 6, 2007 3:52 PM NOTES...
  • Page 36 6101 Gateway Drive, Cypress, California 90630-4841, USA...
