- Page 1 OWNER'S MANUAL CAR CD/MP3/WMA Receiver Please read this manual carefully before operating your set and retain it for future reference. MODEL LCF800ONS/ LCF800ORS P/NO : MFL63287341 www.lg.com.mx...
-
Page 2: Table Of Contents
Table of Contents Safety Note 16-17 Connecting a Bluetooth wireless technology Front Panel Using the buttons for Bluetooth wireless technology Remote Control (OPTIONAL) Disconnecting a phone Battery installation Answering and ending a call About detachable control panel Rejecting a call Attaching the control panel Making a call saved as preset number Detaching the control panel... -
Page 3: Safety Note
Safety Note CAUTION : This product uses a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service center. Performing controls, adjustments, or carrying out procedures other than those specified herein CAUTION may result in hazardous radiation exposure. -
Page 4: Front Panel
Front Panel a [SRC] Selects function sources. f [REC] Recording to USB g Display window [• OFF] Power on/off. b [DISP] h Remote Sensor i [OPEN] Opens the front panel. • Press it, you can check the clock time. • Press and hold it, you can turn off the dis- ] Returns to the previous step. -
Page 5: Remote Control (Optional)
Remote Control (OPTIONAL) Battery Installation Pull out the battery holder with a sharp product like a ball point pen. g Adjusts volume level. h [m M] Put the battery with cor- rectly on the battery holder. Skip / Search / Seek / Tune Push the battery holder back into its original position. -
Page 6: About Detachable Control Panel
About detachable control panel Attaching the control panel Detaching the control panel Attach part A of the control panel to Press the [OPEN] to open the con- part B of the unit. trol panel. Push the control panel to right. Attach part C of the control panel to part D of the unit while pushing the control panel to left. -
Page 7: Installation
Installation ISO-DIN Installation Basic Installation Slide the unit into the ISO-DIN Before installing, make sure that the Bend the claws frame. according to ignition-switch is set to OFF and the thickness Fit screws removed from the old remove the terminal of the car battery of the unit. -
Page 8: Connection
Connection Before connecting, make sure that the ignition switch is set to OFF, and remove the battery # terminal to avoid short circuits. Wired mic To Audio in (OPTIONAL) To Audio out (OPTIONAL) Rear Left (Sub-woofer Left) Front Left Rear Right (Sub-woofer Right) Front Right *Sub-woofer is optional. -
Page 9: Basic Operation
Turning off the display light Basic Operation 1. Press and hold DISP. 2. Press and hold it again to turn it on. ON PLAYER Note 1. Turn the unit on. Any key Under the light-off condition, press any keys, the light is turned on and then off 2. -
Page 10: Listening To A Cd
For Light setting Listening to a CD You can adjust the light effects by adjusting LED, DIM, or DIM L. LED COL1/ COL2/ AUTO: You can change the LED window color. ON PLAYER DIM(Dimmer) OFF / ON / AUTO : You can change the brightness of the dis- 1. -
Page 11: Playing Back Tracks/Files In A Way You Want
• MENU 1. Press FUNC/ When setting the option to Live File System, you cannot use it on LG players. 2. Rotate the volume knob to select an item and press it. (Mastered/Live File System : Disc format system for Windows Vista) 4. -
Page 12: Listening To The Radio
Adjusting TUNER settings Listening to the radio On the Unit 1. Press FUNC/ • MENU ON PLAYER 2. Rotate the volume knob to select an item and press it. 1. Select a source to tuner. 3. Rotate the volume knob to set the option and press it. 2. - Page 13 (OPTIONAL) REG (Region) ON / OFF REG ON : The unit switches to another station, within the same network, broadcasting the same program when the receiving signals from the current station become weak. REG OFF : The unit switches to another station, within the same network when the receiving signals from the current station become weak.
-
Page 14: Using Usb Device
Quick search of a desird file Using an USB device You can select and play a desird file regardless of the order in USB. ON PLAYER 1. Press ENTER (or the volume knob) to check all files. 1. Open the USB cover. 2. -
Page 15: Listening To Music By Connecting Ipod
Playing back files in a way you want Listening to music by connecting iPod On the Unit 1. Press FUNC/ • MENU You can enjoy iPod-stored music on the unit by connecting it to the USB 2. Rotate the volume knob to select an item and press it. connector using the appropriate cable. -
Page 16: Connecting A Bluetooth Wireless Technology
Using the buttons for Blutetooth wireless technology Connecting a Bluetooth wireless technology Before you start the pairing procedure, make sure the Bluetooth wire- less technology is turned on in to your phone. Refer to your phone’s user guide. Pairing links your unit and phone with Bluetooth wireless technolo- gy, and is required only once for the initial setup. -
Page 17: Disconnecting A Phone
Using a Bluetooth wireless technology - Saving call numbers in the latest calls You can easily save up to 6 phone numbers in the latest calls. Go to the menu more you can do (CALL -> RECEIVED or MISSED -> Rotate the volume knob to select the phone number you want to save ->... -
Page 18: Adjusting The Setting (Bluetooth Wireless Technology)
Adjusting the setting. ( Bluetooth wireless technology) RECEIVED/DIALED/MISSED Phone number list. CALL RECEIV • To call the phone number, select the phone number and press BT. • To save it, select the phone number and press the volume knob. “SAVE” will be DIALED shown. -
Page 19: Phone Compatibility List (Bluetooth Wireless Technology)
Phone compatibility list ( Bluetooth wireless technology) H : Handsfree P : Phonebook Sync (GET) Bluetooth list and manufacturing company applicable. A : Audio Streming (A2DP) V : Object Push(Vcard, ADD) Company List Company List Company List Nokia 3230 Nokia Motorola E398 3250... - Page 20 Bluetooth list and manufacturing H : Handsfree P : Phonebook Sync (GET) company applicable. A : Audio Streming (A2DP) V : Object Push(Vcard, ADD) Company List Company List Company List SONY T68i G600 CU500 ERICSSON V600 i900 KE970 KG245 V800 L600 W550i U600...
- Page 21 “The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.” Bluetooth ® wireless technology is a system which allows radio contact between electronic devices within a max. range of 10 meters.
-
Page 22: Steering Remote Control
STEERING REMOTE CONTROL CAR CD/MP3/WMA Receiver... - Page 23 Before Use Appellation Install the specified battery in this unit • Selects function sources. • Answering or ending a call 1. Pull out the battery holder while pressing the bottom of it. 2. Put the battery with correctly on the battery holder. Skip/ Search/ Seek/ Tune 3.
- Page 24 Installation Left-Hand-Drive Car WARNING Steering Wheel • Avoid installing this unit in such a location where the operation of safety devices such as airbags is prevented by this unit. Otherwise, there is danger of a fatal accident. Installation • Fix this unit securely to the steering wheel with the belt attached to the Scope unit.
- Page 25 Installation Installing the unit on a Left-Hand-Drive Car. 3. Install the remote control unit in the holder. • When the unit is installed on a Right-Hand-Drive car, the horizontal position are inverted. 1. Secure Cover holder to the inner circumference of the steering wheel with belt Fit the Cover holder to the steering wheel so that the arrow-marked...
- Page 26 Troubleshooting Symptom Cause Correction General Power doesn’t turn on / The Leads and connectors are not properly. Confirm once more that all connections are unit doesn’t operate. correct. The fuse is blown. Rectify the problem that caused the fuse to blow, and then replace it.
- Page 27 Specifications Compatible iPod models eneral • iPod touch Output Power 53 W x 4 CH (Max.) • iPod classic Power Source DC 12V • iPod with video (5th generation) Speaker impedance 4 Ω Ground System Negative • iPod nano (1st generation) Dimensions (W x H x D) 178 x 50 x 169 mm (Without Control Panel)
- Page 28 Av. Sor Juana Inés de la Cruz No 555 Col. San Lorenzo Tlalnepantla, Estado de México CP 54033 Tel. (55) 5321-1919 Lada sin costo 01 (800) 347 1919 LG Electronics México S.A. de C.V.
