- Page 1 OWNER'S MANUAL CAR CD/MP3/WMA Receiver Please read this manual carefully before operating your set and retain it for future reference. MODEL LCF600UNS/ LCF600URS LCF800INS/ LCF800IRS P/NO : MFL63287342 www.lg.com.mx...
-
Page 2: Table Of Contents
Table of Contents Safety Note Listening to music from an external device 12-13 Front Panel Listening to the radio Storing desired frequencies manually Remote Control (OPTIONAL) Listening to a preset station Battery installation Adjusting tuner settings About detachable control panel Using an USB device Attaching the control panel Moving to another drive... -
Page 3: Safety Note
Safety Note CAUTION : This product uses a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service center. Performing controls, adjustments, or carrying out procedures other than those specified herein CAUTION may result in hazardous radiation exposure. -
Page 4: Front Panel
Front Panel a [SRC] Selects function sources. f [REC] Recording to USB g Display window [• OFF] Power on/off. b [DISP] h Remote Sensor i [OPEN] Opens the front panel. • Press it, you can check the clock time. • Press and hold it, you can turn off the dis- ] Returns to the previous step. -
Page 5: Remote Control (Optional)
Remote Control (OPTIONAL) Battery Installation Pull out the battery holder with a sharp product like a ball point pen. g Adjusts volume level. h [m M] Put the battery with cor- rectly on the battery holder. Skip / Search / Seek / Tune Push the battery holder back into its original position. -
Page 6: About Detachable Control Panel
About detachable control panel Attaching the control panel Detaching the control panel Attach part A of the control panel to Press the [OPEN] to open the con- part B of the unit. trol panel. Push the control panel to right. Attach part C of the control panel to part D of the unit while pushing the control panel to left. -
Page 7: Installation
Installation ISO-DIN Installation Basic Installation Slide the unit into the ISO-DIN Before installing, make sure that the Bend the claws frame. according to ignition-switch is set to OFF and the thickness Fit screws removed from the old remove the terminal of the car battery of the unit. -
Page 8: Connection
Connection Before connecting, make sure that the ignition switch is set to OFF, and remove the battery # terminal to avoid short circuits. To Audio in (OPTIONAL) To Audio out (OPTIONAL) Rear Left (Sub-woofer Left) Front Left Rear Right (Sub-woofer Right) Front Right *Sub-woofer is optional. -
Page 9: Basic Operation
Turning off the display light Basic Operation 1. Press and hold DISP. 2. Press and hold it again to turn it on. ON PLAYER Note 1. Turn the unit on. Any key Under the light-off condition, press any keys, the light is turned on and then off 2. -
Page 10: Listening To A Cd
For Light setting Listening to a CD You can adjust the light effects by adjusting LED, DIM, or DIM L. LED LED COL1/ COL2/ AUTO: You can change the LED window color. ON PLAYER DIM(Dimmer) OFF / ON / AUTO : You can change the brightness of the dis- 1. -
Page 11: Playing Back Tracks/Files In A Way You Want
LG players when formatting rewritable discs. When setting FUNC 1. Press the option to Live File System, you cannot use it on LG players. 2. Rotate the volume knob to select an item and press it. (Mastered/Live File System : Disc format system for Windows Vista) 3. -
Page 12: Listening To The Radio
Adjusting TUNER settings Listening to the radio On the Unit 1. Press FUNC. ON PLAYER 2. Rotate the volume knob to select an item and press it. 1. Select a source to tuner. 3. Rotate the volume knob to set the option and press it. 4. - Page 13 (OPTIONAL) REG (Region) ON/ OFF REG ON : The unit switches to another station, within the same network, broadcasting the same program when the receiving signals from the current station become weak. REG OFF : The unit switches to another station, within the same network when the receiving signals from the current station become weak.
-
Page 14: Using An Usb Device
Recording to USB from CD or FM tuner Using an USB device 1. Open the USB cover and connect it to the unit. ON PLAYER 2. Select CD or FM tuner. 3. Start playback. 1. Open the USB cover. 4. Press REC to start recording. 2. -
Page 15: Listening To Music By Connecting Ipod
Playing back files in a way you want Listening to music by connecting iPod On the Unit (Only in LCF800INS/ LCF800IRS) 1. Press FUNC. 2. Rotate the volume knob to select an item and press it. 3. Rotate the volume knob to set the option. You can enjoy iPod-stored music on the unit by connecting it to the USB 4. -
Page 16: Steering Remote Control
STEERING REMOTE CONTROL CAR CD/MP3/WMA Receiver... -
Page 17: Before Use
Before Use Appellation Install the specified battery in this unit • Selects function sources. 1. Pull out the battery holder while pressing the bottom of it. 2. Put the battery with correctly on the battery holder. Skip/ Search/ Seek/ Tune 3. - Page 18 Installation Left-Hand-Drive Car WARNING Steering Wheel • Avoid installing this unit in such a location where the operation of safety devices such as airbags is prevented by this unit. Otherwise, there is danger of a fatal accident. Installation • Fix this unit securely to the steering wheel with the belt attached to the Scope unit.
-
Page 19: Installing The Unit On A Left-Hand-Drive Car
Installation Installing the unit on a Left-Hand-Drive Car. 3. Install the remote control unit in the holder. • When the unit is installed on a Right-Hand-Drive car, the horizontal position are inverted. 1. Secure Cover holder to the inner circumference of the steering wheel with belt Fit the Cover holder to the steering wheel so that the arrow-marked... -
Page 20: Troubleshooting
Troubleshooting Symptom Cause Correction General Power doesn’t turn on / Leads and connectors are not properly. Confirm once more that all connections are The unit doesn’t operate. correct. The fuse is blown. Rectify the problem that caused the fuse to blow, and then replace it. -
Page 21: Specifications
Specifications Compatible iPod models General iPod touch • Output Power 53 W x 4 CH (Max.) • iPod classic Power Source DC 12 V Speaker impedance 4Ω • iPod with video (5th generation) Ground System Negative • iPod nano (1st generation) Dimensions (W x H x D) 178 x 50 x 169 mm (Without Control Panel) •... - Page 22 Av. Sor Juana Inés de la Cruz No 555 Col. San Lorenzo Tlalnepantla, Estado de México CP 54033 Tel. (55) 5321-1919 Lada sin costo 01 (800) 347 1919 LG Electronics México S.A. de C.V.
