- Page 1 NS3526S 115745826 (1509) OWNER’S MANUAL POWER SPRAYER NS3526S GB-1 1̲NS3526S̲GB̲三 Adobe PageMaker 6.5J/PPC Page 1 15.8.26, 1:49 PM...
-
Page 2: Table Of Contents
NS3526S SAFETY PRECAUTIONS Contents Warning labels bearing the mark on the product and in this Manual refer to important safety matters. Please familiarize your- Parts location ..........2 self with them and observe them well. If a warning label on the product becomes soiled or detached, Specification ........... -
Page 3: Specification
25.4 Fuel used Lubricating oil/gasoline mix Lubricating oil used 2-cycle engine oil Admixture ratio Gasoline 50 : Oil 1 (when using ZENOAH genuine oil) Carburetor Diaphragm, rotary valve type Ignition system Electronic controlled flywheel magnet type Spark plugs CHAMPION RCJ-6Y... -
Page 4: For Safe Operation
NS3526S 5. For safe operation Before using this product, please read this Operator's • When using for the first time, before commencing Manual thoroughly to ensure correct operation. The fol- actual spraying please receive guidance in operat- lowing are precautions that should be observed in order ing the product from a person with adequate experi- to use the product smoothly. - Page 5 NS3526S 5. For safe operation IMPORTANT PRECAUTIONS WHEN TRANSPORTING THE SPRAYER Check and follow the local regulations as to sound • Do not transport the sprayer while it has chemicals or level and hours of operations for the product. fuel in the tank, as these could leak out as a result of impact during transportation.
- Page 6 Manual are required, please con- another similar method. In addition, please take ev- sult your product supplier or nearest ZENOAH prod- ery care that the water used to clean spraying tools uct dealer.
-
Page 7: Set Up
6. Set up ■ Connecting the spray hose and nozzle ■ Adjusting spray pressure • NS3526S has a pressure regulating dial to change spray pressure. Set the pressure at a level appropri- ate to the spray conditions. Set the pressure regulating dial as follows: •... -
Page 8: Fuel
• The Zenoah engines are lubricated by oil specially WARNING formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added 1. Select bare ground for fueling. quality oil expressly labeled for air-cooled 2-cycle 2. -
Page 9: Chemical Filling
NS3526S 8. Chemical filling ■ Procedure for filling WARNING 1. Use a bucket or other suitable container and dilute • Chemical substances should be handled correctly, the chemical to the requisite strength. observing the precautions marked on the container. 2. Place the sprayer on an even and stable surface and Some chemicals are extremely hazardous to humans remove the chemical tank cap. - Page 10 NS3526S 9. Operation ■ Spraying NOTE • When restarting immediately after stopping the en- WARNING gine, set the choke lever to "open" and the throttle lever to "slow". • Please use correctly, observing the precautions in this Manual ("For Safe Operation", p5 to 7).
-
Page 11: Maintenance
• Do not modify the sprayer or dismantle the engine. • When replacing parts please use Zenoah original parts or designated parts. ■ Air cleaner • After every 25 hours of operation, please remove the air cleaner cover and inspect the element. - Page 12 NS3526S 10. Maintenance • When replacing plugs, please use designated items. NOTE • Warm up the engine before adjusting the idling speed. • Throttle wire play Throttle wire play should be 1 to 2 mm. After com- pletely returning the throttle lever, take the throttle wire...
-
Page 13: Storage
NS3526S 10. Maintenance INTAKE AIR COOLING VENT WARNING • Never touch the cylinder, muffler, or spark plugs with your bare hands immediately after stopping (1) Intake air the engine. The engine can become very hot when cooling vent in operation, and doing so could result in severe burns. -
Page 14: Troubleshooting Guide
→ clogged with dust → clean cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
