- Page 1 NS3526 848A9993A0 (806) OWNER’S MANUAL POWER SPRAYER NS3526 GB-1...
-
Page 2: Table Of Contents
NS3526 SAFETY PRECAUTIONS Warning labels bearing the mark on the product and in this Manual refer to important safety matters. Please familiarize your- self with them and observe them well. If a warning label on the product becomes soiled or detached, please order a replacement label from your dealer and attach it in the requisite place. -
Page 3: Specification
Single-cylinder air-cooled 2-cycle gasoline engine G26LS (cc) 25.4 Lubricating oil/gasoline mix 2-cycle engine oil Gasoline 50 : Oil 1 (when using ZENOAH genuine oil) Diaphragm, rotary valve type Electronic controlled flywheel magnet type CHAMPION RCJ-6Y Recoil starter type Primary cable short circuit... -
Page 4: For Safe Operation
NS3526 5. For safe operation Before using this product, please read this Operator's Manual thoroughly to ensure correct operation. The fol- lowing are precautions that should be observed in order to use the product smoothly. Elsewhere in the Manual, warning mark is used to bring your attention to these precautions. - Page 5 • While spraying please hold the grip firmly at all times and be careful not to point the nozzle in the direction of people or animals. NS3526 GB-5...
-
Page 6: Maintenance Precautions
Manual. When maintenance or parts replacement not indicated in this Manual are required, please con- sult your product supplier or nearest ZENOAH prod- uct dealer. • Never keep the engine running while carrying out in- spections or maintenance. -
Page 7: Set Up
5. Tightly screw the rod onto the cock. 6. Tightly screw the spray rod onto the rod. ■ Adjusting spray pressure • NS3526 has a pressure regulating dial to change spray pressure. Set the pressure at a level appropri- ate to the spray conditions. -
Page 8: Fuel
• The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use (JASO FC GRADE OIL or ISO EGC GRADE). -
Page 9: Chemical Filling
2. Lift the choke lever on the right of the air cleaner until it is in the "closed" position, then open the throttle le- ver on the main unit side about 1/3-1/2 from the "slow" position. g. throttle lever h. fast i. slow NS3526 GB-9... - Page 10 NS3526 9. Operation NOTE • When restarting immediately after stopping the en- gine, set the choke lever to "open" and the throttle lever to "slow". 3. Place the sprayer in a stable location, and pull the starter knob with the right hand while holding the chemical tank down with the left hand.
-
Page 11: Maintenance
Con- tact with hot muffler may result in a personal injury. • Do not modify the sprayer or dismantle the engine. • When replacing parts please use Zenoah original parts or designated parts. ■ Air cleaner •... -
Page 12: Tightening Torque
NS3526 10. Maintenance • When replacing plugs, please use designated items. CHAMPION (RCJ-6Y) IMPORTANT • If too much fuel is absorbed or poor quality oil is used, the spark plug electrodes become dirty, making the engine harder to start. • Note that using any spark plug other than those des-... -
Page 13: Storage
2 or 3 times, return the spark plugs to their original position and stop in compressed posi- tion. 6. After oiling the throttle lever and other metal parts with anti-corrosive oil, cover the sprayer and store indoors in a low-humidity location. NS3526 (1) Intake air cooling vent GB-13... -
Page 14: Troubleshooting Guide
Æ clogged with dust cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
