TENS Therapy Device
Electronic Nerve Stimulator
Thank you for purchasing the OMRON Electronic Nerve
Stimulator HV-F127.
Please read this Instruction Manual thoroughly before using
this unit for the safe and correct use of it.
Please keep this Instruction Manual always at hand for your
future reference.
Instruction Manual
HV-F127
CONTENTS
Notes on Safety...............................1
Features of the Product...................3
Low-Frequency Therapy................4
of the Parts....................................5
How to Attach the Pad ....................8
Examples of Application..................9
How to Treat ..................................11
the Pad........................................17
Troubleshooting .............................19
Specifications ................................20
All for Healthcare

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVF-F127 and is the answer not in the manual?

Questions and answers

Related Manuals for Omron HVF-F127

Summary of Contents for Omron HVF-F127

  • Page 1: Table Of Contents

    Treat with the Relieve Button ..13 Treat with the Region Button ..14 Treat with the Massage Button ..15 Thank you for purchasing the OMRON Electronic Nerve After Treatment –Storing the unit..16 Stimulator HV-F127. Please read this Instruction Manual thoroughly before using Maintenance this unit for the safe and correct use of it.

  • Page 2: Before Using The Unit

    Before Using the Unit Notes on Safety (Please read this section carefully before using the unit.) G The icons and warning signs are indicated here for your safe and correct use of the product as well as to prevent injuries and/or damage to properties. G The icons and meanings are as follows: Examples of Icons icon indicates prohibitions (must not do).
  • Page 3 Notes on Safety CAUTION If the unit is not functioning properly or you feel discomfort, immediately stop using the unit. If you feel any trouble with your body or skin, consult the doctor and follow his/her instructions. If you want to move the Electrode Pad to another region or your body during treatment, be sure to turn off the power.

  • Page 4: General Information On Omron Hv-F127 Electronic Nerve Stimulator

    General information on Omron HV-F127 Electronic Nerve Stimulator The OMRON HV-F127 Electronic Nerve Stimulator is an electro-therapeutic device working according to the TENS principle (Transcutaneous Electrical Nerve Stimulation). The HV-F127 Electronic Nerve Stimulator enables you to reduce and relieve your pain symptoms.

  • Page 5: Components Of The Product

    Components of the Product The following components are included in the box. If any components are missing, please contact the nearest OMRON dealer. 5. Electrode Holder 1. Main unit 2. Type K Electrode Cord Note: This is a consumable. 3. Long-Life Pad 6.

  • Page 6: Names And Functions Of The Parts

    Names and Functions of the Parts Electrode Cord Main Unit Connects the Main unit with the Pad Electrode Cord Plug Intensity Adjustment Dial/Power Button Electrode Turns on and off the power Cord Jack and adjusts the intensity of stimulation. INTENSITY /POWER RELIEVE Automatic Course...
  • Page 7 Electrode Cord Plug Attach the red or the white plug to each Pad. Tab of the Pad Hold the Tab to peel off the Pad. Point & Wide Mode POINT The unit treats the red and the white sides alternately. The unit treats both the red and white sides simultaneously.

  • Page 8: How To Use

    OOOOOO 4. Close the battery cover. General advice from OMRON on the handling of batteries • The supplied batteries are for the trial use only and may wear out in less than three months. • Replace the worn batteries with new ones immediately.

  • Page 9: How To Attach The Pad

    ❇ Although Electrode Cord Plugs are provided in red and white, either plug can be connected with one of the Pads irrespective of color. General advice from OMRON on the handling of Electrode Cord • Avoid excessive bending and pulling of the Electrode Cord.

  • Page 10: Examples Of Application

    Examples of Application Shoulders Stiff shoulder is presumably caused by blood congestion of trapezius muscle that moves shoulders, compression of nerves by the accumulation of fatigue substances, or poor blood circulation of subcutaneous tissues such as muscles. Attach the Pads symmetrically on the region of stiff shoulders with the backbone as the center. Trapezius muscle For stiff shoulders, it is effective to attach the Pads to the shaded...
  • Page 11 Calf Swelling and fatigue of Calf is presumably caused by congestion of blood and accumulation of fatigue substances in that region. Attach the Pads to upper and lower calf. It is effective to attach the Pads to the shaded regions of calf as shown in the diagram.

  • Page 12: How To Treat

    How to Treat This section explains the treatment procedure and the entire operation flow from turning on the power to storing of the unit. Three treatment methods are available. Select your favourite one to receive treatment. – Treat with the Relieve Button When you want to relieve severe acute pain promptly.
  • Page 13 3. Adjust the intensity of stimulation. Select your favorite intensity level from 1 to 10 by rotating the Intensity Dial/Power Button. INTENSITY /POWER RELIEVE SOLE Standard for treatment SHLDR WAIST REGION KNEAD PUSH Duration: 10 to 15 minutes per region for each time MASSAGE Number of treatment times: Once or twice in a day Intensity: As much as you feel comfortable when using this unit...

  • Page 14: Treat With The Relieve Button

    How to Treat Treat the region by selecting one course from Relieve, Region, and Massage. Treat the region with the Button RELIEVE When you want to relieve severe acute pain promptly 1. Push the Relieve Button. This is a program using high-frequency stimulation of 1200 Hz, which INTENSITY /POWER is said to relieve acute pain quickly.

  • Page 15: Treat With The Region Button

    Treat the region with the Button REGION When you want to treat the selected region of shoulder, sole, calf (leg), and lower back (waist) to which the Pads are attached with the effective program 1. Push the Region Button. Each time you push the Region Button, the display flashes in the INTENSITY /POWER order of Shoulder, Sole, Leg, and Waist.
  • Page 16 How to Treat Treat the region by selecting one course from Relieve, Region, and Massage. MASSAGE Treat the region with the Button When you want to treat the region according to your symptom and favourite operation by selecting the massage method from Tapping, Kneading, Pushing, and Rubbing 1.

  • Page 17: After Treatment -Storing The Unit

    After Treatment – Storing the unit If you leave the Pads without taking care of them, they will become dirty or the adhesive property will drop. When the treatment ends, attach the Pads to the Electrode Holder and store them. 1.

  • Page 18: Maintenance

    4. Lightly attach the Pad to the Electrode Holder for storage. (Refer to Page 16.) General advice from OMRON on the handling of Pads • Do not use hot water, detergent, or chemicals such as thinner or benzine. • Do not scratch the adhesive surface with your nail or a brush.

  • Page 19: How To Clean And Store The Unit

    • If you are not going to use the unit for a long time of more than three months, store the unit after removing the batteries. ❇ If you do not observe the above-mentioned notes or correct use of the unit, OMRON cannot take responsibility on quality of the unit.

  • Page 20: Troubleshooting

    (Refer to page 17) irritating. I The adhesive surface of Pad is ⇒ Pad is a consumable. damaged. Replace the Pad with a new one. ❇ If the unit does not operate after taking the above-mentioned measures, contact the nearest OMRON dealer.

  • Page 21: Specifications

    1628361-9D OMRON HEALTHCARE Co., Ltd. 53, Kunotsubo, Terado-cho, Muko, Kyoto, 617-0002 JAPAN OMRON HEALTHCARE SINGAPORE PTE LTD 438A Alexandra Road, #05-05/08, Alexandra Technopark, Singapore 119967 www.omron-healthcare.com.sg Production Facility OMRON(DALIAN) CO., LTD. Dalian, China...
