- Page 1 New Product Information Sheet Specifications subject to change © OMRON HEALTHCARE EUROPE B.V. Model (code): Complete (HEM-7530T-E3) Versions Remark Date Without DoC content 30/09/2020 + key visual All information added 17/02/2021 PM-2020-01-07/2020...
- Page 2 PM-2020-01-07/2020...
- Page 3 Complete 2-in-1 home blood pressure and ECG monitoring Product Name: Complete (HEM-7530T-E3) Product Description: Automatic Upper Arm Blood Pressure Monitor + Product Category: Electronic Sphygmomanometers with ECG function Features: Packaging content: - ECG Recording - Monitor - Blood Pressure Measurement...
- Page 4 Product category Electronic Sphygmomanometers with ECG function Product description Automatic Upper Arm Blood Pressure Monitor Single lead electrocardiogram Model (code) Complete (HEM-7530T-E3) BP reading display LCD digital display Operation mode Continuous operation IP classification IP 21 Rating DC6 V 4 W Power source 4 “AA”...
- Page 5 Blood pressure measurement: Cuff pressure range 0 to 299 mmHg Blood pressure measurement SYS: 60 to 260 mmHg range DIA: 40 to 215 mmHg Pulse measurement range 40 to 180 beats / min. Accuracy Pressure: ±3 mmHg Pulse: ± 5 % of display reading Inflation Automatic by electric pump Deflation...
- Page 6 (ECG or EKG) recording. There are 3 ways to use this monitor: measuring blood pressure only; ECG only; blood pressure and ECG simultaneously. Visit the “Help” section in the “OMRON connect” app for additional information about using the app. Packaging content The manufacturer produces Complete with the applicable accessories included, necessary for the application of its intended purpose.
- Page 7 Key features: - ECG Recording - Blood Pressure Measurement - Afib indicator function - Record measurements - Omron connect - Intellisense technology - Cuff Wrap Guide - Clinically validated Description of operating principle The device operates on the oscillometric principle. It detects blood movement through the brachial artery and converts the movements into a digital reading.
- Page 8 7. Sit correctly and place your arm at your heart’s level. Remain still and don’t talk. 8. Open the OMRON connect app on your smartphone 9. Follow the instructions to start an ECG recording on your smartphone and place the phone on the smartphone stand of your monitor 10.
- Page 9 Tachycardia, Normal, Unreadable, Unclassified or other messages. The blood pressure reading will also appear on the phone screen. 13. Release the electrodes and remove the arm cuff. 14. Press the BP (START/STOP) button to turn the monitor off. Please, review the Instruction Manual for the full details on the application of this product.
- Page 10 Materials for accessories Item Parts Material Air plug Inner cloth Polyester / PVC Outer cloth Nylon / PVC Cuff Tube PVC (polyvinyl chloride) HEM- Bias Polyester / Cotton RML31* Hook Fastener Polyester Nipple Ring Steel Air plug Inner cloth Polyester / PVC Outer cloth Nylon / PVC Cuff...
- Page 11 Unfolded package design of main device and accessories Main device: PM-2020-01-07/2020...
- Page 12 Accessories: Arm Cuff (HEM-RML31) Accessories: Arm Cuff (HEM-CS24) PM-2020-01-07/2020...
- Page 13 List of Harmonized EN Standards The device is classified as a medical device, Class IIa (MDD Article 9 Annex IX Rule 10) Applicable Directives: Medical Device Directive (MDD) 93/42/EEC Radio Equipment Directive 2014/53/EU RoHS Directive 2011/65/EU Applicable standards: EN 1041:2008+A1:2013 EN ISO 10993-5:2009 EN 1060-1:1995+A2:2009 EN ISO 10993-10:2013...
- Page 14 Maintenance To protect your monitor from damage, follow the directions below: • Changes or modifications not approved by the manufacturer will void the user warranty. • DO NOT disassemble or attempt to repair this monitor or other components. This may cause an inaccurate blood pressure readings and/or ECG recordings.
- Page 15 physician. ONLY a physician is qualified to diagnose and treat high blood pressure and other heart related conditions. • DO NOT use this monitor on an injured arm/fingers or an arm/fingers under medical treatment. • DO NOT apply the arm cuff on your arm while on an intravenous drip or blood transfusion.
- Page 16 Cautions (Cautions indicate a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the user or patient or damage to the equipment or other property.) • Stop using this monitor and consult with your physician if you experience skin irritation or discomfort.
- Page 17 ECG after an extreme temperature change could lead to an inaccurate blood pressure readings and/or ECG recordings. OMRON recommends waiting for approximately 2 hours for the monitor to warm up or cool down when the monitor is...
- Page 18 • OMRON makes no warranty for any data or information that is collected erroneously by the monitor, or misuse or malfunction as a result of abuse, accidents, alteration, misuse, neglect, or failure to maintain the product as instructed.
- Page 19 ECG as normal. You should notify your physician for possible changes in your health. • If the “OMRON connect” app detects possible atrial fibrillation in an ECG, consult with your physician before making any medical decision, including altering your use of any drug or treatment.
- Page 20 ECG. If the battery cover is not in place, recording an ECG may not be successful. If you have lost the battery cover, contact your OMRON retail outlet or distributor. Disposal This product should not be disposed of, with other household wastes at the end of its working life.
- Page 21 5 years Repair During the period of warranty OMRON will, without charge for labor or parts, repair or replace the defect product or any defective parts. Repair or replacement under the warranty does not give rise to any extension or renewal of the warranty period.
- Page 22 LEGAL MANUFACTURER OMRON HEALTHCARE Co., Ltd 53, Kunotsubo, Terado-cho, Muko, KYOTO, 617-0002 Japan OMRON HEALTHCARE Co., Ltd. Matsusaka Factory 1855-370, Kubo-cho, Matsusaka-shi, Mie, 515-8503 Japan EU-REPRESENTATIVE OMRON HEALTHCARE EUROPE B.V. Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS PM-2020-01-07/2020...
