Foscam SABIP1100 User Manual

Outdoor hd ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User
Manual
User
Manual
Outdoor HD IP Camera
Model: SABIP1100
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SABIP1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Foscam SABIP1100

Summary of Contents for Foscam SABIP1100

  • Page 1 User Manual User Manual Outdoor HD IP Camera Model: SABIP1100 V1.0...

  • Page 2: Table Of Contents

    Table of Contents 1 Overviews................................3 1.1 Key Features..................................3 1.2 PoE (Power over Ethernet)...............................4 1.3 Read Before Use................................4 1.4 Packing Contents................................4 1.5 Physical Description................................5 1.5.1 Front Panel...................................5 1.5.2 Interface..................................5 1.5.3 Bottom View.................................6 1.5.4 SD Card..................................6 2 Accessing the Network Camera........................6 2.1 Access the Camera in LAN...............................6 2.2 Access the Camera in WAN.............................
  • Page 3 4.3.5 Port....................................39 4.3.6 Mail Settings................................41 4.3.7 FTP Settings................................43 4.3.8 P2P....................................44 4.4 Video....................................44 4.4.1 Video Settings................................44 4.4.2 On Screen Display..............................45 4.4.3 Privacy Zone................................45 4.4.4 Snapshot Settings..............................46 4.4.5 IR LED Schedule...............................47 4.4.6 Lens Distortion Correction............................48 4.5 Alarm....................................48 4.6 Record....................................

  • Page 4: Overviews

    1 Overviews The IP Camera is an integrated IP Camera with a color CMOS sensor enabling viewing resolution 1280*720. It combines a high quality digital video camera, with a powerful web server, to bring clear video to your desktop from anywhere on your local network or over the Internet. The IP Camera supports the industry-standard H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth.

  • Page 5: Poe (Power Over Ethernet)

    1.2 PoE (Power over Ethernet) The Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable. Such as the following picture: connect the Network Camera to a PoE-enabled router/ switch via Ethernet cable. 1.3 Read Before Use Please first verify that all contents received are complete according to the Package Contents listed below.

  • Page 6: Physical Description

    1.5 Physical Description 1.5.1 Front Panel 1 Infrared Lamp Array 2 LENS: CMOS sensor with fixed focus lens 3 Induction IC 1.5.2 Interface 1 Power Interface Connect the external power adapter, request for 12V/1A power. 2 LAN 10/100M adaptive Ethernet interface. Through this interface, IPCAM can be connected with various network devices, such as hub, router, etc.

  • Page 7: Bottom View

    1.5.3 Bottom View There are two labels located of the camera; this is an important feature of original cameras. If your camera does not have labels, it may be a clone. Cloned cameras can not use original firmware and are not eligible for warranty or technical services.

  • Page 8: Access The Camera In Wan

    Figure 2.2 2.2 Access the Camera in WAN 2.2.1 Static IP Addresses Users who have static IP addresses do not need to set DDNS service settings for remote access. When you have finished connecting the camera using the LAN IP address and port forwarding, you can access the camera directly from the Internet using the WAN IP address and port number.

  • Page 9: Dynamic Ip Addresses

    NOTE: If you plug the camera into a router, it will have a dynamic IP address and you need to set DDNS service settings to view it remotely. Step 1: Enter the username and password of the Administrator (default username is admin with a blank password), and click “OK”...
  • Page 10 Modify the Http Port. Enter the Username and password, click OK . Figure 2.5 Step 2: Modify the Http Port and enter the username and password of the Administrator , and click “OK” to apply changes. Step 3: Wait around 10 seconds, you’ll see that the camera’s LAN IP address has changed. Also, the LAN IP address is now fixed at a static IP address of http://192.168.1.110:88.
  • Page 11 Step 2: Create a new column using the LAN IP address & HTTP Port of the camera within the router as shown below, then push OK or Submit to save your settings: Fill the HTTP Port of the camera in the columns of External Port and Internal Port.

  • Page 12: Using The Vlc Player

    Second method : Use the Third party DDNS to access the camera via the Internet Step 1, Please go to the third party DDNS website(such as www.no-ip.com) to create a free hostname. Step 2, DO DDNS Service Settings within the Camera Please set DDNS Settings within the camera by hostname, a user name and password you’ve got from www.no-ip.com Take hostname ycxgwp.no-ip.info, user name cam, password cam2012 for example.
  • Page 13 4) rtsp://admin@192.168.1.11:88/videoMain Open the VLC, and go to MediaOpen Network Stream option, then enter the URL into VLC. Figure 2.9 Figure 2.10 Sometimes you may need to enter the user name and password again. Click OK and you can see the real-time preview.

  • Page 14: Ip Camera Connection To The Server

    Figure 2.11 Figure 2.12 If you cannot play the video in the VLC player, please check the port mapping. You can read Quick Installation Guide about How to configure port forwarding. NOTE: If you modify the camera’s username or password, you had better reboot the camera, or else the new username and password cannot take effect when you enter the authentication in the VLC.

  • Page 15: Login Window

    3.1 Login Window Figure 3.1 Please check the login window above, it was divided to 4 sections from no. 1 to 4. Section1 Enter the Username and password The default administrator username is admin with no password, please reset the password at first using and prevent unauthorized users login the camera .
  • Page 16 Figure 3.2 After logging in for the first time, you will go to “Setup Wizard”automatically. Here you can set the basic parameters of camera, such as camera name, camera time, IP configuration. Figure 3.3 Device Name: You could give name for your camera. Figure 3.4 System Time: Select the time zone you need to set the date, time,format, etc.

  • Page 17: Surveillance Window

    Figure 3.5 IP: Set IP address of the camera. You could choose to obtain an IP automatically or set the IP address according to your needs. Figure 3.7 NOTE: It needs about 1 minute to connect the camera to your router. 3.2 Surveillance Window...
  • Page 18 Figure 3.8 Section1 Live Video / Settings buttons Path to surveillance window. Click this button and back to the surveillance window : Path to Administrator Control Panel, Click it, and it will lead to Administrator Control Panel and do advanced settings. : Click this button and back to the Playback panel to view the record files stored in the SD Card.
  • Page 19 Figure 3.9 Section3 Mode/ Stream / Mirror/ Flip buttons Mode 1) 50HZ ---------Indoor surveillance (Region: Europe, China) 2) 60HZ ---------Indoor surveillance (Region: USA, Canada) 3) Outdoor Mode------Outdoor surveillance Stream The default stream supports multiple modes, For example: HD Mode/720P/30fps/2M meanings: Stream type / Resolution / Maximum frame rate/ Bit rate.
  • Page 20 Section4 IR LED Lights Click Infra led and there are three modes to adjust the infrared led: Auto, Manual and Schedule. Auto: Select it and the camera will adjust the infra led (on or off) automatically. Manual: Select it and turn off the infra led manually. Schedule: Select it and the IR led light will be off at the schedule period.
  • Page 21 4----- Record: Click the icon and the camera start recording, you can see a green dot in the live window. Click again and stop recording. The default storage path is C:\IPCamRecord. You can change the storage path: Go to Settings- >Record-> Storage Location panel. 5------Full Screen Click it to make full-screen, or you can double click the surveillance screen to make full-screen.
  • Page 22 Figure 3.11 Full Screen: Select it and Click it to make full-screen, press ESC and exit full-screen. Zoom up/down: Click it and the live view will be digital zoomed up, then click Zoom Down and the live view back to original size. Figure 3.12 NOTE: 1 This camera don’t support Pan/Tilt function, so here cannot allow to use Screen PTZ.

  • Page 23: Advanced Camera Settings

    2 For Mac OS, the plugin cannot support Onscreen Mouse function, so you cannot allow to use it. 4 Advanced Camera Settings Click the button “Settings”, goes to Administrator Control Panel to make advanced camera settings. 4.1 Device Status Device Status contains four columns: Device Information, Device Status, Session Status and Log, it will show you various information about your camera.

  • Page 24: Device Status

    4.1.2 Device Status On this page you can see device status such as Alarm status, NTP/DDNS status and so on. Figure 4.2 4.1.3 Session status Session status will display who and which IP is visiting the camera now. Figure 4.3 4.1.4 Log The log record shows who and which IP address accessed or logout the camera and when.

  • Page 25: Basic Settings

    Click the page number and go to the corresponding page to see more logs Fill in one page number, click Go button and go to the corresponding page Figure 4.4 Reboot the camera and clear the log records. 4.2 Basic Settings This section allows you to configure your Camera Name, Camera Time, Mail, User Accounts and Multi-Device.

  • Page 26: User Accounts

    Figure 4.6 Time Zone: Select the time zone for your region from the drop-down menu. Sync with NTP server: Network Time Protocol will synchronize your camera with an Internet time server. Choose the one that is closest to your camera. Sync with PC: Select this option to synchronize the date and time of the Network Camera with your computer.
  • Page 27 Figure 4.7 How to change the password? Firstly, select the account which you want to change the password, then select “Change password”, enter the old password and the new password, lastly click modify to take effect. Figure 4.8 How to add account ? Select one blank column, then enter the new user name, password and privilege, last click Add to take effect.
  • Page 28 Figure 4.9 Figure 4.10 Delete: Select the account which you want to delete, then click Delete button to take effect. How to change the username ? Firstly, select the account which you want to change the username, then select “Change username”, enter the new password, lastly click modify to take effect.

  • Page 29: Multi-Camera

    Figure 4.11 NOTE: The default administrator account cannot be deleted, but you can add other administrator users. 4.2.4 Multi-Camera If you want to view multi-surveillance screens on one window, you need to login one camera, and set it as the main device, and do Multi-Device Settings, add other cameras to the first one camera.
  • Page 30 1 Click it, camera model, alias, host and HTTP Port will be filled in the following boxes automatically . 2 Enter the User name and Figure 4.1 3 Click Add to take effect . password of the 2nd camera . Camera Model: Our Company produces two series cameras: MJPEG and H.264.
  • Page 31 Back to Surveillance Windows, and click Four Windows option, you will see four cameras you added. Figure 4.12 Figure 4.13 Add cameras in WAN If you want to view all cameras via the internet(remote computer), you will need to add them using DDNS domain name.
  • Page 32 Use DDNS domain name and port to login Make sure each camera you need add could login with DDNS name and port Figure 4.14 Click Multi-Device Settings. Choose The 2nd Device. Fill in the 2nd camera’s name, DDNS domain name, port number.
  • Page 33 Here the Host must be entered as the second camera’s DDNS domain name, not its LAN IP. Figure 4.16 Return to video window. You will see all of the cameras accessible through the internet. When you are away from home, you can use the first camera’s DDNS domain name and port to view all the cameras via internet.

  • Page 34: Network

    4.3 Network This section will allow you to configure your camera’s IP, PPOE, DDNS, UPnP, Port, Mail Settings and FTP Settings. 4.3.1 IP Configuration If you want to set a static IP for the camera, please go to IP Configuration page. Keep the camera in the same subnet of your router or computer.
  • Page 35 Figure 4.19 Set the same Subnet Mask and gateway of the camera with your PC . There are two DNS servers . You can set any of them . Same with gateway is also OK . Figure 4.20 If you don’t know the DNS server, you can use the same settings as the Default Gateway.

  • Page 36: Pppoe

    4.3.2 PPPoE If you are using a PPPoE connection, enable it and enter the User Name and Password for your PPPoE account. Figure 4.21 4.3.3 DDNS The camera has embedded a unique DDNS domain name when producing, and you can directly use the domain name, you can also use the third party domain name.
  • Page 37 Third Party Domain Name Settings User can also use third part DDNS, such as www.no-ip.com. ,www. 3322.com Here take www.no-ip.com for example: ① Step 1, Go to the website www.no-ip.com to create a free hostname Firstly: Login on www.no-ip.com and click No-IP Free to register. Click here to register Figure 4.23 Please register an account step by step according to instructions on...
  • Page 38 Figure 4.24 Figure 4.25 Please create the domain name step by step according to instructions on www.no-ip.com Step 2, DO DDNS Service Settings within the Camera Please set DDNS Settings within the camera by hostname, a user name and password you’ve got from www.no-ip.com Take hostname ycxgwp.no-ip.info, user name cam, password cam2012 for example.
  • Page 39 Secondly, select No-Ip as a server. Thirdly, fill cam as DDNS user, fill password cam2012 as DDNS password, fill ycxgwp.no-ip.info as DDNS domain and server URL, Then click save to make effect. The camera will restart and to take the DDNS settings effective.

  • Page 40: Upnp

    4.3.4 UPnP Figure 4.27 The default UPnP status is closed. You can enable UPnP, then the camera’s software will be configured for port forwarding. Back to the “Device Status” panel, you can see the UPnP status: Figure 4.28 The camera’s software will be configured for port forwarding. There may be issues with your routers security settings, and sometimes may error.
  • Page 41 Another way to change the HTTP port no. Step 1: Open the IP Camera Tool, select the camera you would like to change the port of, right click on the IP address, and click on ”Network Configuration”, this brings up the network configuration box as shown in Figure 4.35 and 4.36.

  • Page 42: Mail Settings

    LAN IP address! Figure 4.32 NOTE: If the camera cannot be accessed, please make sure the port forwarding is succeed. HTTPS port: The default port is 443. You can use the url to access the camera: https:// IP + HTTPS port. ONVIF port: By default, the ONVIF port is set to 888.
  • Page 43 select. 2-----SMTP Username/ password: ID account and password of the sender email address 3-----Sender E-mail Mailbox for sender must support SMTP 4-----Receiver Mailbox for receiver need not support SMTP, you can set 4 receivers 5-----Save Click Save to take effect 6-----Test Click Test to see if Mail has been successfully configured.

  • Page 44: Ftp Settings

    4.3.7 FTP Settings If you want to upload record files and images to your FTP server，you can set FTP Settings. Figure 4.35 Figure 4.36 FTP server: If your FTP server is located on the LAN, you can set as Figure4.41. If you have an FTP server which you can access on the internet, you can set as Figure 4.42.

  • Page 45: P2P

    4.3.8 P2P Access the camera by smart phone (Android or iOS operating system) First of all, you need to open the P2P function of the camera at “Settings-->Network-->P2P.” Figure 4.37 Search and install IPCam Viewer on Google Play for Android devices, search and install IPCam_Viewer on APP Store for iOS devices.

  • Page 46: On Screen Display

    Stream type: There are four types to identify different streams you have set. Resolution: The camera supports multiple types, For example: 960P, 720P, VGA. The higher the resolution is, the clearer video will become. But the code flux will become larger too, and it will take up more bandwidth. (Different models support different specific types.

  • Page 47: Snapshot Settings

    Allow On Screen Display Mask: There are two options: Yes or NO. Select yes and draw a mask area on the video, the mask area will be black on the video. The mask area Figure 4.41 Click Back button and return to the OSD page, click Save to take effect. Figure 4.42 Back to the surveillance window, you can see the mask area as the following picture: Figure 4.43...

  • Page 48: Ir Led Schedule

    Figure 4.44 Image Quality: Low, Middle and High. The higher the quality, the picture will be clearer. Alarm Pictures Save Path: FTP. If you have done FTP and Alarm settings, when alarming, the camera will snap pictures to the FTP automatically. Enable timing to capture To enable capture interval, follow the steps below: 1 Select Enable timing to capture...

  • Page 49: Lens Distortion Correction

    4.4.6 Lens Distortion Correction On this page you can set the distortion correction. There are three options: Low, Medium, High. Figure 4.46 If you replace the lens, the image has found distortion, uneven and so on, you can modify the Select The Distortion Correction Parameter to calibration images.
  • Page 50 3 Trigger interval--- The interval time between two motion detections. Here supports 5s/6s/7s/8s/9s/10s/11s/12s/13s/14s/15s. Select one interval time. 4 Select the alarm indicators When the motion has been detected, the alarm status will turn to Detect alarm. Figure 4.48 There are four alarm indicators: A PC Sound If you select PC Sound, when the motion has been detected, the people around the PC will hear beep alarm sound.
  • Page 51 Figure 4.49 6 Alarm Schedule ① Alarm anytime when motion is detected Click the black button up the MON, you will see all time range turn red. When something moving in the detection area at anytime, the camera will alarm. Click this button and select all time range Figure 4.50 ②...

  • Page 52: Record

    Figure 4.51 ③ Press the left mouse and drag it on the time boxes, you can select the serial area. Figure 4.52 7 Click Save button to take effect. When the motion is detected during the detection time in the detection area, the camera will alarm and adopt the corresponding alarm indicators.

  • Page 53: Alarm Record

    Figure 4.53 Recording Location: SD card or FTP. When the camera alarmed, it will store the alarm files to the SD card or FTP. Make sure the camera has been inserted the SD card. On this page, you can see the available space of the SD card.

  • Page 54: Record Schedule

    4.6.4 Record Schedule On the page you can configure the schedule record.  When the parameter Recording Location is set SD Card on the Storage Location page, you can configure parameters as shown in follow figure. Figure 4.56 You can select the main stream or sub stream from the drop-down. ...

  • Page 55: Sd Card Management

    Figure 4.57 Click Save button to take effect. 4.6.5 SD Card Management On this page you can see the information of the SD card. This camera supports SD Card and the max size of SD card must be under 32G. Figure 4.58 SettingsStatusDevice Status Go to the...

  • Page 56: Firewall

    Figure 4.59 The default storage path of alarm record files is SD card, when the available size of SD card is less than 256M, the old record files will be deleted automatically. 4.7 Firewall This section explains how to control the access permission by checking the client PC’s IP addresses. It is composed of the following columns: Block access from these IP addresses and Only allow access from these IP addresses.

  • Page 57: System

    4.8 System In this panel, you can back up/restore your camera settings, upgrade the firmware to the latest version, restore the camera to default settings and reboot the device. 4.8.1 Back-up& Restore Click Back-up to save all the parameters you have set. These parameters will be stored in a bin file for future use.
  • Page 58 Figure 4.63 Figure 4.64 CAUTION: If your camera works well with the current firmware, we recommend not upgrading. Please don’t upgrade the firmware unnecessarily. Your camera may be damaged if mis-configured during an upgrade. NOTE: 1) Don’t upgrade the firmware through the web UI in WAN, or else the upgrade may be failed. 2) Please ensure you have download the correct firmware package for your camera before upgrading.

  • Page 59: Patch Installation

    4.8.3 Patch Installation Click "Browse" to select the correct patch file, and then click "Install Patch" to install the patch. Do not turn off the power during it installing. After installing is complete, you will receive a system prompt. Figure 4.65 4.8.4 Factory Reset Click Factory Reset button and all parameters will return to factory settings if selected.
  • Page 60 Section 1 Define the Record files time and Type : The storage path of record files : Here supports three types: current day, current month and All records. Another way, select the time on the time&date manually. Figure 5.1 : The type of records files, Here supports two typs: Normal record, Alarm record and All records.

  • Page 61: Appendix

    Section 2 Search record files On this panel you can see all record files satisfy the conditions you set. Section 3 Play/Stop/Full screen buttons Please select one record file before use these buttons. Click this button to play the record files Click this button to stop the record files Click this button to make full screen, and double click left mouse to exit full screen.
  • Page 62 Figure 6.2 Figure6.3...
  • Page 63 Figure 6.4 Figure 6.5...

  • Page 64: Uninstall The Activex Of Firefox Browser, Google Chrome And Ie Chrome

    Figure 6.6 6.1.2 Uninstall the ActiveX of Firefox browser, Google Chrome and IE Chrome. Figure 6.7...

  • Page 65: I Have Forgotten The Administrator Password

    Figure 6.8 Figure 6.9 6.1.3 I have forgotten the administrator password To reset the administrator password, you had better unplug the network cable firstly. After that, press and hold down the RESET BUTTON about 5 seconds. Releasing the reset button, the password will turn to the factory default.

  • Page 66: No Pictures Problems

    because of the security settings of computer. There are two ways to resolve this problem: (1) Please add the camera as a trusted site to resolve this issue. The steps are IE browserToolInternet PropertiesSecurityTrusted sitesSitesAdd (2) Open IE browser, then right click, select “Run as administrator” 6.1.6 No Pictures Problems The video streaming is transmitted by the ActiveX controller.

  • Page 67: Can't Access Ip Camera In Internet

    NOTE: Make sure that your firewall or anti-virus software does not block the camera or ActiveX. If you could not see video, please shut down firewall or anti-virus software to try again. 6.1.7 Can’t access IP camera in internet There are some reasons: 1 ActiveX controller is not installed correctly 2 The port which camera used is blocked by Firewall or Anti-virus software.

  • Page 68: Ce & Fcc

    Image Compression H.264 Image Frame Rate 30fps(60Hz), 25fps(50Hz), downward adjustable Resolution 720P(1280 x 720), VGA(640 x 480), QVGA(320 x 240) Stream dual stream Video Image adjustment The hue, brightness, contrast, saturation, sharpness are adjustable Flip image flip and mirror Infrared mode Automatic or manual Night visibility With 1 Infrared Lamp Array, Night Vision Range up to 20m...
  • Page 69 This device compiles with FCC Rules Part 15. Operation is subject to the following two conditions. This device may not cause harmful interference, and   This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
