- Page 1 DISHWASHER OWNER’S MANUAL MODEL : LD-2263W(S,M,L,T)H LD-2263W(S,M,L,T)HB LD-2263W(S,M,L,T)HU Please read this manual carefully before operating your dishwasher. Retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY AND CAUTION INSTALLATION INSTRUCTIONS PARTS NAME FUNCTION OF CONTROL BUTTON HOW TO USE AND OPERATE OPERATING SEQUENCE PROGRAM USER MAINTENANCE INSTRUCTIONS TROUBLE SHOOTING GUIDE SPECIFICATION... -
Page 3: Safety And Caution
SAFETY AND CAUTION IMPORTANT SAFETY INSTRUCTIONS WARNING - When using your dishwasher, follow basic precautions, including the following: • Please read this manual carefully before During use using the dishwasher for the first time. • Only suitable household utensils should be •... - Page 4 SAFETY AND CAUTION CAUTION concerning the Power Cord Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Step 2 : WARNING PREPARE ELECTRICAL WIRING Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. CAUTION Any plumbing work required to install this appliance should be carried out by a For personal safety, remove house fuse qualified plumber or competent person. - Page 6 INSTALLATION INSTRUCTIONS Step 3 : Step 4 : PREPARE DISHWASHER FOR INSTALL THE DISHWASHER IN INSTALLATION CUPBOARD Lay the dishwasher on its back. Before sliding the dishwasher into the cupboard opening, all necessary final Adjust the legs to the needed height of height adjustment and balancing adjustment cabinet as shown in below figure.
- Page 7 INSTALLATION INSTRUCTIONS Step 5 : DRAIN LINE CONNECTION If the end of drain hose does not fit to ■ When the drain hose is connected to a the drain line, use a piece of rubber separate stand pipe, it is essential that an connector(not supplied) that must be air tight connection is made.
- Page 8 INSTALLATION INSTRUCTIONS Step 8 : Step 6 : HOW TO LEVEL THE PRODUCT WATER SUPPLY CONNECTION Connect the water supply hose to the After installing the product, if you feel some water tap as shown in figure.(Some sticky or hear a frictional sound between the models consist of an inlet valve and hose.) side portion of door and tub when you open or This dishwasher may be fed with either...
-
Page 9: Parts Name
PARTS NAME 1. Control Panel 11. Upper Rack 2. Handle deco 12. Cutlery Rack 3. Door Handle 13. Detergent & Rinse Aid Dispenser 4. Front Cover 14. Vapor Vent Cover 5. Lower Cover 15. Upper Spray Arm 6. Power Switch 16. -
Page 10: Function Of Control Button
FUNCTION OF CONTROL BUTTON INDICATOR : Child lock • • : Refill with Rinse aid • : Refill with special salt. CHILD EXTRA HOT TIME LEFT LOCK / RINSE+ • Used to lock or • With each press, • Before starting, the display window shows the running time of the unlock the selected program. - Page 11 SPRAY PROGRAM TIME DELAY INTENSITY • When you want to select • With each press, the level • If you want to delay the start of program, press each of water jet is changed to selected program, press this button button.
-
Page 12: How To Use And Operate
HOW TO USE AND OPERATE 1. Loading your Dishwasher Be careful large items not to prevent the detergent dispenser lid from For the best washing performance, it is opening important that the dishwasher is loaded according to instructions. 3. Using the Cutlery Basket Before loading items into the dishwasher, you must scrape off large particles in Cutlery should be mixed within each... - Page 13 HOW TO USE AND OPERATE 5. Adjusting the Upper Rack 4. Loading the Upper Rack The upper rack is best loaded with more Your upper rack can be raised or lowered to delicate items, small plates, long cutlery, cater for different sized crockery. Before adjusting, ensure that the rack is empty.
- Page 14 HOW TO USE AND OPERATE 6. Adding Detergent Push latch to open Dispenser • Detergent must be put into the detergent chamber before starting every program except the Pre-Wash. • Please follow the manufacturer’s Place proper instructions printed on the manual when detergent into this determining the correct dosage.
- Page 15 HOW TO USE AND OPERATE 7. Adding Rinse Aid Dispenser � For filling To fill the Rinse Aid chamber, rotate the round cap counter clockwise and remove. Fill the container to the maximum level with a good quality Rinse Aid, then replace and lock the cap.
- Page 16 HOW TO USE AND OPERATE 8. Salt Filling This model has a water softener to soften hard water. So you should read these notes carefully for correct operation. In order to provide satisfactory rinsing results, the dishwasher requires soft water, i.e.,containing little or no lime, otherwise water stains will be left behind on the dishes and interior containers.
- Page 17 HOW TO USE AND OPERATE ■ For refilling When the salt is exhausted, the salt refill lamp is lighted on automatically during operation. Then the salt should be refilled after finished the cycle. But it is recommended the salt refill should always be done (as mentioned previous page) before starting next operation to thin and drain away any excess salt solution immediately.
- Page 18 HOW TO USE AND OPERATE 10. Removable Rack 12. Separable basket Slide two baskets in opposite directions, A removable rack at the lower rack is then pull them apart. detachable for loading pots and pans. ① ② ② ① 11. Glass supporter 13.
-
Page 19: Operating Sequence
OPERATING SEQUENCE Open the door and Press The indicator lights of the program and all the phases the program consists of will the “power” button come on. When you press the “power” button, the Before starting, the display window shows state of default program being set will be the running time of the selected program. -
Page 20: Program
PROGRAM WASH RINSE Program Main Heating Pre Wash Rinse 1 Rinse 2 Rinse 3 Wash Rinse 50℃ ℃ 70℃ ℃ 70℃ ℃ Intensive The program sequence is optimized and adapted in accordance Auto with how dirty the dishes are. 45℃ ℃ 65℃... -
Page 21: User Maintenance Instructions
USER MAINTENANCE INSTRUCTIONS To prevent trouble and poor operating, it is important to check and care for the filters and spray arms at intervals. Filters Upper Spray Arm • Remove the lower rack first. • Pull the upper rack forwards. •... -
Page 22: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE If a problem occurs check below to see whether this can be solved. In the unlikely event that the problem cannot be rectified, please contact a service engineer. Problem Possible Causes The lamps do not come • Plug is not properly inserted in the socket. on when the power switch on. - Page 23 MEMO...
- Page 24 LD-2263W(S,M,L,T)H LD-2263W(S,M,L,T)HB LD-2263W(S,M,L,T)HU Capacity 12 Place settings Weight See rating label Power Supply See rating label Power Consumption See rating label Water Feed Pressure 50 ~ 800 kPa P/No.: MFL30149707...
