- Page 1 DISHWASHER OWNER'S MANUAL MODEL : LD-2157W(S,M,L,T)H LD-2157W(S,M,L,T)HB LD-2157W(S,M,L,T)HU Please read this manual carefully before operating your dishwasher. Retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY AND CAUTION INSTALLATION INSTRUCTIONS PARTS NAME FUNCTION OF CONTROL BUTTON HOW TO USE AND OPERATE OPERATING SEQUENCE PROGRAM USER MAINTENANCE INSTRUCTIONS TROUBLE SHOOTING GUIDE SPECIFICATION... -
Page 3: Safety And Caution
SAFETY AND CAUTION IMPORTANT SAFETY INSTRUCTIONS WARNING - When using your dishwasher, follow basic precautions, including the following: • Please read this manual carefully before be placed in the dishwasher. using the dishwasher for the first time. (Please avoid utensils; that are non- •... - Page 4 SAFETY AND CAUTION CAUTION concerning the Power Cord Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.
- Page 5 INSTALLING INSTRUCTIONS Step 2 : WARNING PREPARATION FOR ELECTICAL WIRING A qualified electrician/plumber or competent person should carry out any CAUTION electrical/plumbing work required to install this appliance. For personal safety, remove house fuse or open circuit breaker before installation. Do not use an extension cord or adapter Step 1 : plug with this appliance.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Step 3 : Step 4 : PREPARING THE DISHWASHER INSTALLING THE DISHWASHER FOR INSTALLATION IN CUPBOARD Lay the dishwasher on its back. Before sliding the dishwasher into the cupboard opening, all necessary height and Adjust the legs to the required height balancing adjustments should be made as shown in below figure. - Page 7 INSTALLATION INSTRUCTIONS Step 5 : DRAIN LINE CONNECTION If the end of drain hose does not fit to When the drain hose is connected to a the drain line, use a rubber separate standpipe, it is essential that an connector(not supplied) that is airtight connection be made.
- Page 8 INSTALLATION INSTRUCTIONS Step 8 : Step 6 : HOW TO LEVEL THE DISHWASHER WATER SUPPLY CONNECTION Connect the water supply hose to the After installing the dishwasher, you may notice water tap as shown.(Some models consist a slight sticking of the door to the dishwasher, of an inlet valve and hose.) when you open or close the door.
-
Page 9: Parts Name
PARTS NAME 1. Control Panel 10. Adjust Leg 11. Upper Rack 2. Door Handle 12. Cutlery Basket 3. Front Cover 13. Detergent And Rinse Aid Dispenser 4. Lower Cover 14. Vapor Vent Cover 5. Process Monitor 15. Upper Spray Arm 6. -
Page 10: Function Of Control Button
FUNCTION OF CONTROL BUTTON HALF LOAD • In case of small load, use upper or lower rack only to save energy. • With each press, can select upper or lower rack only. • In case you don’t select this button, the machine always works vario washing, which operate upper and lower spray arm... - Page 11 INDICATOR TIME LEFT DELAY START • Before starting, the display window shows the running time of • Refill with • If you want to delay the the selected program. special salt start of selected program, • After starting, the display window shows the remaining time. press this button before •...
-
Page 12: How To Use And Operate
HOW TO USE AND OPERATE Take care not to obstruct the rotation 1. Loading your Dishwasher of the spray arms and ensure that large items do not prevent the detergent For better washing performance, always load dispenser lid from opening. the dishwasher according to the instructions. - Page 13 HOW TO USE AND OPERATE 4. Loading the Upper Rack 5. Adjusting the Upper Rack It is best to load this with more delicate Your upper rack can be raised or lowered to items such as, small plates, long cutlery, cater for different sized crockery.
- Page 14 HOW TO USE AND OPERATE 6. Adding Detergent Push latch to open Dispenser • Detergent must be put into the detergent chamber before starting every program except the Pre-wash. • Please follow the manufacturer’s instructions Place proper within the manual, when determining the detergent into this correct amount of detergent to use.
- Page 15 HOW TO USE AND OPERATE 7. Adding Rinse Aid Dispenser For filling To fill the Rinse Aid chamber, rotate the round cap counter clockwise and remove. Fill the container to the maximum level with a good quality Rinse Aid, then replace and lock the cap.
- Page 16 HOW TO USE AND OPERATE 8. Salt Filling This model has a water softener to soften hard water. Please read these notes carefully for correct operation. In order to provide satisfactory rinsing results, the dishwasher requires soft water, i.e.,containing little or no lime, otherwise water stains will be left behind on the dishes and interior containers.
- Page 17 HOW TO USE AND OPERATE For refilling When the salt container is empty, the salt refill lamp will automatically turn on during operation. The salt should be refilled after the cycle has finished. We recommended the salt refill should always be carried out, as mentioned previous page, prior to starting the next operation. This will immediately thin and drain away any excess salt solution.
- Page 18 HOW TO USE AND OPERATE 10. Separable basket 11. Drying Slide two baskets in opposite directions, To assist drying, we recommend that the then pull them apart. door be fully opened after the cycle. 12. Energy Test(EN50242) Appliance loaded in accordance with standard specifications.
-
Page 19: Operating Sequence
OPERATING SEQUENCE After starting, the display window shows Press the “Power” button the remaining time. The time in the display window will start Check there is rinse aid to decrease minute by minute. If the door is opened during the program a and salt safety device ensures that the machine stops. -
Page 20: Program
PROGRAM Running time may vary according to the water temperature, water pressure and voltage. Running time doesn’t include “Cool dry - 60 min”. WASH RINSE Cool Program Main Heating Pre Wash Rinse 1 Rinse 2 Rinse 3 Wash Rinse Intensive The program sequence is optimized and adapted in accordance Auto with how dirty the dishes are. -
Page 21: User Maintenance Instructions
USER MAINTENANCE INSTRUCTIONS To prevent trouble and poor operating, it is important to check filters and spray arms at regular intervals. Filters Upper Spray Arm • Remove the lower rack first. • Pull the upper rack forwards. • Turn the mesh filter counterclockwise. •... -
Page 22: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE If a problem occurs check below to see whether this can be solved. In the unlikely event that the problem cannot be rectified, please contact a service engineer. Problem Possible Causes No lights come on when the •... - Page 23 MEMO...
- Page 24 LD-2157W(S,M,L,T)H LD-2157W(S,M,L,T)HB LD-2157W(S,M,L,T)HU Capacity 12 Place settings Weight See rating label Power Supply See rating label Power Consumption See rating label Water Feed Pressure 50 ~ 800 kPa P/No.: MFL30149791...
