DS-MPE-GE210
PCIe MiniCard Gigabit Ethernet Module
Rev A.00 July 2014
Date
Comment
Initial release
Copyright 2014
Diamond Systems Corporation
555 Ellis Street
Mountain View, CA 94043 USA
Tel 1-650-810-2500
Fax 1-650-810-2525
www.diamondsystems.com
Advertisement
Table of Contents
Related Manuals for Diamond Systems DS-MPE-GE210
Summary of Contents for Diamond Systems DS-MPE-GE210
- Page 1 PCIe MiniCard Gigabit Ethernet Module Rev A.00 July 2014 Revision Date Comment A.00 7/10/2014 Initial release Copyright 2014 FOR TECHNICAL SUPPORT Diamond Systems Corporation PLEASE CONTACT: 555 Ellis Street Mountain View, CA 94043 USA support@diamondsystems.com Tel 1-650-810-2500 Fax 1-650-810-2525 www.diamondsystems.com...
- Page 2 Packing List ...............................4 Functional Overview ............................5 Functional Block Diagram ..........................5 Mechanical Board Drawing ..........................5 Installation .................................6 Connector Pinout and Pin Description ......................7 PCIe MiniCard Edge Connector (J1) ......................7 Ethernet Connector (J2) ..........................7 Specifications ..............................8 www.diamondsystems.com DS-MPE-GE210 User Manual Rev A.00 Page 2...
- Page 3 The list here describes common causes of failure found on boards returned to Diamond Systems for repair. This information is provided as a source of advice to help you prevent damaging your Diamond (or any vendor’s) embedded computer boards.
- Page 4 2. INTRODUCTION 2.1 Description The DS-MPE-GE210 provides a convenient, compact, cost-effective means to add an extra gigabit Ethernet port to your embedded system. The Intel 210IT Ethernet controller provides 10/100/1000Mbps operating speed with industrial temperature range capability. The module includes link and speed LEDs as well as latching connectors for enhanced ruggedness.
- Page 5 The DS-MPE-GE210 block diagram is shown below. 4.2 Mechanical Board Drawing The DS-MPE-GE210 conforms to the PCIe MiniCard electromechanical specification revision 1.2, full size format. Overall dimensions are 50.95mm L x 30.00mm W. The two mounting holes are isolated from the CPU ground and not connected to any ground lines.
- Page 6 The DS-MPE-GE210 plugs in to any socket meeting the PCIe MiniCard specifications. It has one connector for the Ethernet port and a pair of mounting holes. To install the DS-MPE-GE210, fully insert the board into a PCIe MiniCard connector and secure in place by inserting one screw from the hardware kit into each of the mounting holes, see the diagram below.
- Page 7 6. CONNECTOR PINOUT AND PIN DESCRIPTION 6.1 PCIe MiniCard Edge Connector (J1) The DS-MPE-GE210 module is compatible with the standard Mini PCIe socket pinout as shown below. WAKE# +3.3VAUX_3 COEX1 GND9 COEX2 +1.5V_1 CLKREQ# UIM_PWR GND1 UIM_DATA REFCLK- UIM_CLK REFCLK+...
- Page 8 Linux 2.6.16, 2.6.27, 2.6.31, and 2.6.32 Operating temperature -40°C to +85°C Operating humidity 5% to 95% non-condensing MTBF tbd hours 50.95mm x 30mm (2” x 1.18”) Dimensions Weight 8.5g (0.3oz) RoHS Compliant www.diamondsystems.com DS-MPE-GE210 User Manual Rev A.00 Page 8...
