Attach Panel(F)&(G)to Panel(H).
Repeat the same method as Step 3.
STEP 9
Upright the unit.
Slide in 3 sets of drawer to the unit.
Insert Runner Stopper(3)to the pre-drilled
hole of Panel(F)&(G),as shown.
Recommended Maximum Weight
30
*Unit in Pound(lbs)
STEP 8
Slot in Panel(I)to Panel(F)(H)(G).
Attach Plastic Drawer Front Panel(6)to
Panel(F)&(G).
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Approx. 15 minutes
Approx. 10 minutes
Approx. 5 minutes
Recomm. 2 Person
Recomm. 1 Person
No Tools Required
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Ubah No Tools 3-Drawers Chest
NT-13012
MODEL
:
DIMENSION :
23.4"(W) x 22.2"(H) x 16.2"(D)
