STEP 7
Attach Panel(H)&(I)to Panel(J).
Repeat the same method as Step 3.
STEP 9
Upright the unit.
Slide in 2 sets of drawer to the unit.
Insert Runner Stopper(5)to the
pre-drilled hole of Panel(H)&(I),
Recommended Maximum Weight
40
*Unit in Pound(lbs)
STEP 8
Slot in Panel(K)to Panel(H)(I)&(J).
Attach Plastic Drawer Front Panel(8)to
Panel(H)&(I).
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 40 minutes
Approx. 30 minutes
Approx. 15 minutes
Approx. 10 minutes
Approx. 5 minutes
Recomm. 2 Person
Recomm. 1 Person
No Tools Required
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Ubah No Tools Entertainment
Center w/2-Drawers
NT-13015
MODEL
:
DIMENSION :
46.3"(W) x 15"(H) x 15.6"(D)
NT1301520140425
Advertisement
Related Manuals for Furinno NT-13015
Summary of Contents for Furinno NT-13015
- Page 1 Slot in Panel(K)to Panel(H)(I)&(J). Repeat the same method as Step 3. Attach Plastic Drawer Front Panel(8)to Panel(H)&(I). its Space. its Budget Assembly Instruction Furinno Ubah No Tools Entertainment Center w/2-Drawers NT-13015 MODEL DIMENSION : 46.3”(W) x 15”(H) x 15.6”(D) Approx. 10 minutes Approx.
