- Page 2 Toshiba QX7 The Toshiba QX7 adjustable speed drive is designed for HVAC applications where harmonic content is critical to the power grid. The QX7’s patented 18-pulse design is the most sensible solution for the high demands of the HVAC industry. The QX7 eliminates the need to add other filters and costly isolation transformers.
-
Page 3: Current Voltage
Truly Designed for Total Harmonic Distortion (THD) can be caused by multiple factors including: computers, fluorescent lights, copiers, and six-pulse drives. With Toshiba’s patented 18-Pulse Autotransformer design, the QX7 removes distortion that would normally be generated by a six-pulse drive. -
Page 4: User-Friendly
Menu-driven parameters and quick set-up keys allow the operator to program the drive with the smallest amount of keystrokes possible. On top of all these great keypad features, the QX7 also comes with Toshiba windows-based software. Monitor Over 30 Parameters 15 Alarms and 41 Faults Displayed The Fire Speed Circuit allows you to run at a preset speed during a smoke purge. - Page 5 Meets or Exceeds Your Specifications Voltage Class Maximum HP Drive Rating AA Dimensions 100” x 30” x 24” AE Dimensions 100” X 54” X 24” AS Dimensions 100” X 54” X 24” Output Frequency Main Circuit Power Terminlas Control Power Voltage Tolerence Frequency Tolerence Control Method...
-
Page 6: Product Warranty
North American Headquarters and Manufacturing Facility (Houston, TX) TOSHIBA — Quality by Design Toshiba’s culture and history are strongly rooted in quality. Our designs are technologically innovative, and our products are manufactured from start to end using only the highest quality domestic and foreign parts.
