- Page 1 Wireless Bluetooth MiniMouse User Manual (GME225B) ®...
- Page 2 Apple Computer, Inc. All other brand and product names are trademarks or registered trademarks of their respective holders. IOGEAR® makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents Package Contents................. Overview....................Features....................Requirements..................Additional Bluetooth products..............Pictorial Introduction................Installation....................Operation....................Specification................... Radio & TV Interference Statement............Limited Warranty.................. -
Page 4: Package Contents
Package Contents This package contains: 1 Wireless Bluetooth MiniMouse 1 Carrying case 1 USB battery charger cable 1 User manual 2 AAA rechargeable batteries 1 Warranty/Registration card If any of the items are missing or damaged, please contact your dealer immediately. -
Page 5: Overview
Overview IOGEAR's Wireless Bluetooth Mini Mouse delivers the convenience of a wireless mouse, with the robustness offered by Bluetooth technology. This class 2 Bluetooth mouse gives you a strong signal ranging up to 66 feet. The small and portable design saves precious space in your mobile work area, and it is one less tangled wire in your laptop carrying case. -
Page 6: Features
Features • Compatible with any Bluetooth-enabled computer that supports HID profile • Works up to 66 feet away from computer • 800 dpi resolution offers twice the accuracy of typical mouse movement • Operates on most surfaces without the need for a mouse pad •... -
Page 7: Requirements
Requirements • Bluetooth enabled computer with HID profile • If the computer is not Bluetooth enabled, a Bluetooth USB dongle will be required. Please refer to IOGEAR part no. GBU301, GBU311, GBU201, GBU211 for details... -
Page 8: Additional Bluetooth Products
Additional Bluetooth Products Bluetooth to USB Adapter, class 2 (GBU201, GBU211) Bluetooth to USB Adapter, class 1 (GBU301, GBU311) Bluetooth to USB Printer Adapter, class 2 (GBP201) Bluetooth Combo (USB/Parallel) Print Adapter, class 1 (GBP301) -
Page 9: Pictorial Introduction
Pictorial Introduction 1. Scroll Wheel 2. Left Click Button 3. Right Click Button P301) 4. Battery Compartment 5. Battery Cover Release 6. Optical Sensor 7. Power On/Off Switch 8. Connect Button 9. Battery Charging Connection... -
Page 10: Installation
Installation BATTERY INSTALLATION 1. Pull the battery cover release toward the direction as indicated in the drawing 2. Insert the batteries (included in the package) into the battery compartment 3. Put the cover back on. 4. Make sure the power On/Off switch is at ON position. We do recommend that you charge the batteries for 10 hours before using the mouse. - Page 11 Before you can use the IOGEAR Bluetooth mouse with your computer, you will first need to establish communication and then connect to it. The procedures below may be different, depending on the Bluetooth software you are using. If you need additional help, please consult the manual for your Bluetooth software.
- Page 12 4. Press the Connect button located under the mouse while Bluetooth devices are being detected. 5. The IOGEAR Bluetooth Mini Mouse should be listed as a HID device. Note: If the IOGEAR Bluetooth MiniMouse is not detected, repeat the procedure again until detected.
- Page 13 Installation Right-click the IOGEAR Bluetooth mouse icon Next, right-click on the mouse icon and select and select “Pair Device.” When prompted to “Connect Device” and when prompted to connect, enter a pass key, enter “0000” (four zeroes). click Yes. Your computer and mouse should now be paired.
- Page 14 Installation You should now be able to use the IOGEAR Bluetooth Mini Mouse. Once you have connected and paired your mouse with your Bluetooth-enabled computer, you don’t need to repeat this procedure. Even if you turn on/off the Bluetooth mouse or shut down your computer, the mouse will still connect to the...
- Page 15 Bluetooth support is built-in in MAC OS X. In the example below, we used MAC OS X v10.3.4 to configure the IOGEAR Bluetooth Mini Mouse. 1. Make sure your computer is Bluetooth-enabled and that it supports the Bluetooth HID profile.
- Page 16 Installation Under the settings tab, make sure Next, select the Devices tab and click that Bluetooth is ON and that the box on Set Up New Device. next to Discoverable is checked.
- Page 17 Installation On the next window, select the Mouse This will start the Bluetooth Setup Assistant. Click continue to proceed. option and click Continue.
- Page 18 Installation Turn ON the IOGEAR Bluetooth Mini 9. Your computer will automatically pair Mouse and press on the Connect with the Bluetooth mouse. Upon button located under the mouse. success, click Continue. Your computer will automatically pair with the Bluetooth mouse. Upon...
- Page 19 Installation 10. You are done! Your Bluetooth Once you have connected and paired your mouse should now be functional. mouse with your Bluetooth-enabled To exit the Bluetooth Setup computer, you don’t need to repeat this Assistant, click Quit. procedure. Even if you turn on/off the Bluetooth mouse or shut down your computer, the mouse will still connect to the computer when both devices are turned...
-
Page 20: Operation
Operation Please avoid using this mouse on glass, mirror and metal surfaces. When traveling, it is advised that you turn the power On/Off switch to the OFF position in order to save battery life. When the mouse movements turn sluggish, it may be the time for you to recharge the batteries. -
Page 21: Specification
Specification... -
Page 23: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose. - Page 24 ® Contact info. 23 Hubble • Irvine, CA 92618 • (P) 949.453.8782 • (F) 949.453.8785 • www.iogear.com...
