DV927BT
INSTALLATION/OWNER'S MANUAL
DVD Multimedia Receiver with Bluetooth
®
featuring a
6.2"
Touch Screen Display
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVN927BT and is the answer not in the manual?

Questions and answers

Phil Wolfley
May 26, 2025

Can I have the radio stay on when reverse camera is on

1 comments:
Mr. Anderson
May 27, 2025

Yes, the Dual DVN927BT radio can stay on while the reverse camera is active. The camera input allows a rear view camera to be used, and the head unit will display the camera feed when the vehicle is in reverse, while the unit remains powered.

This answer is automatically generated

Summary of Contents for Dual DVN927BT

  • Page 1 DV927BT INSTALLATION/OWNER’S MANUAL DVD Multimedia Receiver with Bluetooth ® featuring a 6.2" Touch Screen Display Safety Notes: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the parking brake is engaged.
  • Page 2 DV927BT PREPARATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or property damage.
  • Page 3: Safety Information

    Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your DUAL DV927BT is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
  • Page 4 DV927BT INSTALLATION Preparation Before You Start • Disconnect negative battery terminal. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Getting Started •...
  • Page 5 DV927BT INSTALLATION Wiring Diagram - Inputs/Outputs BT Antena REVERSE SWC - 3.5mm JACK REMOTE TURN-ON Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 10 amp ATM mini style fuse located on the power connector. Wiring Notes: Subwoofer output The Subwoofer preamp audio output (black jacket with green RCA) is active in all audio modes.
  • Page 6: Control Locations

    DV927BT OPERATION Control Locations microSD Tune/Track Up Microphone Power / Volume / Mute Eject Tune / Track Down Reset USB Port Navigation Auxiliary Input Power Audio Mode Go To / * Play / Pause Loudness / End Call Mute Number Keys Title Root Subtitle...
  • Page 7: Remote Control Preparation

    DV927BT OPERATION Remote Control Preparation Remove battery insulation tape . Notes: • The remote control uses one 3 volt Lithium CR2025 battery. Remove the battery if the remote will not be used for a month or longer. • Remove and dispose of battery properly. •...
  • Page 8: General Operation

    DV927BT OPERATION General Operation Power On/Off Momentarily press to turn the unit on or off. Volume Rotate the volume knob to increase or decrease the volume level. Mute Momentarily press MUTE to silence the audio. Momentarily press MUTE again to return to the previously selected volume. Rotating the volume knob while the volume is muted will also cancel the mute function.
  • Page 9 DV927BT OPERATION General Operation From the Main Menu screen, select Settings to access the Setup menu and Setup Menu select from five categories represented by the icons on the left side of the screen: General, Language, Audio, Screen and Bluetooth. Select the desired sub-menu, and adjust using the up/down arrows on the right side of the screen.
  • Page 10 DV927BT OPERATION General Operation Touch Screen The touch screen controls on the bottom of each screen allow direct access Controls to important features during any mode of operation. Standby Press to dim the display or put the unit in Stanby mode. Press to eject the disc.
  • Page 11: Am/Fm Tuner Operation

    DV927BT OPERATION AM/FM Tuner Operation Radio Operation Select the Radio icon from the Main Menu screen. Main Menu Press to return to Main Menu screen. Displays current mode of operation. Current Mode Indicator Tune Frequency Down Press << to tune radio to a lower frequency. Press < to tune the unit down one step at a time.
  • Page 12: Cd/Usb Operation

    DV927BT OPERATION CD/USB Operation To play audio files from a disc or MP3 files from a disc or USB device, CD/USB Operation insert disc or device and playback will begin automatically. To return to disc or USB playback from another mode of operation, select the corresponding icon from the Main Menu.
  • Page 13 DV927BT OPERATION Media Compatibility - CD/DVD File Type Level 1, Level 2  ISO9660 Level 3 Playback  ISO9660 JOLIET File System Extension Filename 32 bytes Playback ROMEO Other Filename Extensions Apple ISO .mp3/.MP3/.Mp3/.mP3  File Extension .rmp/.m4a MPEG 1 ...
  • Page 14 DV927BT OPERATION Media Compatibility - USB File Type FAT 12 File System FAT 16/FAT 32  .mp3/.MP3/.Mp3/.mP3  File Extension .rmp/.m4a MPEG 1  MPEG MPEG 2  Format MPEG 2.5  MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5 8/11.025/12kHz MPEG 1...
  • Page 15: Media Compatibility

    DV927BT OPERATION Media Compatibility Media Compatibility The following types of discs/files are compatible: • CD-DA, CD-ROM (ISO), CD-R, CD-RW • DVD Video, DVD+R/RW, DVD-R/RW The following types of discs/files are not compatible: • WMA files that are protected by DRM (Digital Rights Management) •...
  • Page 16: Dvd Operation

    DV927BT OPERATION DVD Operation Inserting a Disc Insert disc into the slot, and playback will begin automatically. Sub- menus may have to be pressed to access the DVD content. Read the directions of your specific DVD disc for other features. Ejecting the Disc Press to eject the disc.
  • Page 17 DV927BT OPERATION DVD Operation Screen Setup Press to adjust screen color settings. Zoom Press to zoom in or out on an image. Subtitle Press to access subtitle options. Audio Press to adjust audio options. Monitor On/Off Press to put the monitor in standby mode. Settings Press to directly access the setup menu.
  • Page 18: Bluetooth Operation

    DV927BT OPERATION Bluetooth Operation Preparation Before you can use a Bluetooth device, it must be paired and connected. Make sure that Bluetooth is activated on your device before you begin the pairing process. Pairing a New Device The unit broadcasts the pairing signal constantly when no devices are currently connected.
  • Page 19 DV927BT OPERATION Bluetooth Operation Standby Press to put the monitor into standby mode. Eject Eject the disc. Audio Press to adjust Audio options. Settings Press to access the Settings menu. Bluetooth Music Press to display the keypad and make a call. Press to go back to the previous file or track.
  • Page 20: Ipod Operation

    DV927BT OPERATION iPod Operation Connecting an iPod Device Connect an iPod device to the unit's USB port. Main Menu Press to return to the Main Menu screen. Current Mode Indicator Displays current mode of operation. Repeat Press to select a repeat option: Repeat 1, Repeat All (default) or Repeat Off.
  • Page 21: Navigation Operation

    DV927BT OPERATION Navigation Operation Navigation Operation To access navigation functions, select Navigation from the Main Menu. Front 3.5mm Aux Input & Rear RCA A/V Input Auxiliary Input Connect an optional audio source into the 3.5mm (front panel) input. Select auxiliary input from the Main Menu to listen to audio. Adjust volume on the external audio source as needed (if connected to the headphone output of the device).
  • Page 22: Swc Input Operation

    1. Set "Radio Select Switch". Set the SWI-RC to position 7 - "Pioneer/Other/Sony". 2. To program, use the Pioneer/Sony/Other radio function mapping order for Dual units. 3. When programming the SWI-RC, if a function is not supported (or not desired), then the function MUST be skipped as per the PAC SWI-RC instructions.
  • Page 23 Dual iPlug App Operation The Dual iPlug™ Smart App is the ultimate wireless remote control for your multimedia receiver. You can download the Dual iPlug app from Apple Appstore or Google Playstore and install it on your smartphone or tablet.
  • Page 24: Specifications

    DV927BT OPERATION Specifications Disc Frequency response: 20Hz-20kHz Channel separation @ 1kHz: >80dB D/A converter: 24 Bit FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range: 530kHz-1710kHz Usable sensitivity: 24uV...
  • Page 25: Troubleshooting

    Physical defect in media Check media for scratches Disc Region Incorrect Region code error Use discs labeled "Region 1" or "All" only appears on display When it comes to quality car stereos, Dual is the brand you can depend on.
