Digital Watchdog MEGApix DWC-MPB72Wi4T User Manual page 14

Setup - Video & Audio Setup
Video Configuration
1
2
3
4
5
Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
1
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with a higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
2
accordingly.
Description - Input the additional description of the selected channel. Max. 30 alphanumeric characters may
3
be used, including spaces.
Resolution - Select video resolution.
4
Available Frame Rate may differ even if the same codecs are in use.
<Resolution of Video Format>
1080p/i
1920 x
NTSC 1280 x 720800 x 600640 x 480
1080
1920 x
PAL 1280 x 720800 x 600640 x 480
1080
Frame Rate - Select the maximum Frame Rate.
5
Available Frame Rate can be different although the same codecs were set up.
720p/i SVGA VGA 4CIF CIF
704 x 576 352 x 288
704 x 480 352 x 240
704 x 576 352 x 288
704 x 480 352 x 240
