MODEL NO. AA-11-04109 FV36 DÉCOR FULLVIEW DIRECT VENT GAS FIREPLACE HEATER
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result causing property damage, personal injury or
loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not
use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gasses, unless a
certified kit is used.
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and must be installed.
85-03-01154-H
Installation and Operating Instructions
FV36 DÉCOR
AVERTISSEMENT. Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d'incendie ou d'explosion ou pour
éviter tout dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres vapeurs
ou liquids inflammables dans le voisinage de cet appareil
ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incendies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
Cet appareil peut être installé dans une maison
préfabriquée (É.-U. seulement) ou mobile déjà installée à
demeure si les règlements locaux le permettent.
Cet appareil doit être utilisé uniquement avec les types de
gaz indiqués sur la plaque signalétique. Une trousse de
conversion est fournie avec cet appareil.
Une barrière conçue pour réduire le risque de brûlures
du verre chaud est fournie avec cet appareil et doit être
installée.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AA-11-04109 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mendota AA-11-04109

  • Page 1 Installation and Operating Instructions MODEL NO. AA-11-04109 FV36 DÉCOR FULLVIEW DIRECT VENT GAS FIREPLACE HEATER WARNING: If the information in these instructions AVERTISSEMENT. Assurez-vous de bien suivre les is not followed exactly, a fire or explosion may instructions données dans cette notice pour réduire au...
  • Page 2 85-03-01154 FV36 DÉCOR...
  • Page 3: Hot Surfaces Are Normal

    See chapter Instructions. Read and 3.1.1 Mendota Fireplace Curing follow all instructions given in this Chapter and perform the 3-step curing cycle. After the 3-step curing cycle has been completed, all smoking will have stopped. Some slight odors may remain. With subsequent use of this Fireplace, odors will slowly dissipate and disappear.
  • Page 4: Table Of Contents

    1.3 H ........3 URFACES ARE ORMAL 1.4 P ..3 ERIODIC AND ANNUAL CLEANING ARE REQUIRED 2.1 SAFETY AND WARNING INFORMATION ....6 3.2.17.3.1 Mendota Cool Wall36 2.2 S ..........7 AFETY ARNINGS 3.2.17.3.2 Versiheat 3.2.17.3.3 FlexHeat 2.3 R .
  • Page 5 4.9 O ........78 PERATING NSTRUCTIONS 4.10 T ......78 AS TO IREPLACE 4.11 FREQUENTLY ASKED QUESTIONS ..... 79 3.15 V ............61 ENTING 5.1 R ......83 EQUIRED ERIODIC NSPECTIONS 5.2 C ........83 LEANING IEWING LASS 3.16 L ......
  • Page 6: Safety And Warning Information

    Building Permit & Inspection Requirements All installations of Mendota Fireplaces must comply with all the requirements stated in this Installation and Operating Manual. The dealer and/or installer must obtain all required building permits and inspection approvals from the local building inspection department or the local jurisdiction.
  • Page 7: Safety Warnings

    HIGH-ALTITUDE INSTALLATION INFORMATION: Prior to installing at altitudes higher than 7,500 ft., understand the need for gas input derating. Contact your local gas company to see if your gas type is already derated for your altitude or contact Mendota Technical Service for support.
  • Page 8 Never obstruct the flow of combustion and ventilation air. Keep the front of the fireplace clear of all obstacles and materials for servicing and proper operation. Use only Mendota approved Screens, Fronts and Trim Kits. Due to high temperature, the fireplace should be located out of traffic areas and away from furniture and draperies.
  • Page 9 été plongée dans l’eau. Do not use any fronts or doors with this f ireplace unless they are certified by Mendota and installed by a certified installer.
  • Page 10: Requirements For Thec

    2.3 REQUIREMENTS FOR THE COMMONWEALTH OF MASS. The information in this section applies to all installations performed in the Common Wealth of Massachusetts only. For all side wall, horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes and where the side wall exhaust vent termination is less than seven (7) feet above grade, the following requirements shall be satisfied: 1.
  • Page 11: General Technical References

    If ignition system goes into lockout mode, always wait 5 minutes before attempting to re-light. Never block off convection air openings or paths. Trim panels or surrounds shall not seal ventilation openings in the fireplace. Always use Mendota decorative fronts and Mendota approved vent systems and vent caps only. Keep the flue warm...
  • Page 12 ATTENTION It is important that the blowers are turned on during this step to prevent the curing smoke from staining the wall finish above the fireplace. Mendota recommends completing Step 1 prior to install ation of wall finish materials. Visible smoke and strong odor are to be expected during this step. If desired, disable smoke alarms before this step, smoke from the initial curing c ycle will set off smoke alarms.
  • Page 13: Mechanical Technicalr

    3.2 MECHANICAL TECHNICAL REFERENCES Planning the installation This Mendota Fireplace must be installed and serviced by a qualified installer, service agency, or the gas supplier. When planning on appliance installation, it is necessary to determine the following information before installing: •...
  • Page 14 Listing Label The listing label is in the air gap on the left side of the Fireplace between the glass frame and outer edge of the Fireplace. It is secured to a chain and loosely Fireplace in the left air gap and can be pulled out to be viewed. Figure 3-2 Listing Label 85-03-01154 FV36 DÉCOR...
  • Page 15 Other Warning and Caution Labels A few warnings or caution labels are attached to this appliance body as required per code to inform you of important facts. You can find these labels on the right-side outer surface of this appliance. Make certain you heed all the warning and caution statements during installation and maintenance of this appliance.
  • Page 16 Figure 3-10 Figure 3-11 85-03-01154 FV36 DÉCOR Page 16...
  • Page 17 FV36 DÉCOR Fireplace Ratings Information This Mendota Fireplace can be installed directly on top of a metal, masonry or wood structural surface. ELECTRICAL REQUIREMENTS: 120 Volts AC, 1.5 Amps (minimum line voltage allowed 110 Volts AC) REQUIRED GAS SUPPLY PRESSURE: NAT.
  • Page 18 HINT: To greatly reduce surface temperatures surrounding this Fireplace during operation, Mendota recommends operating the integrated convection air blowers which aid in cooling all surrounding surfaces. Mendota Fireplaces comply with ANSI Z21.88 Standards for maximum surface temperatures (ambient plus 117 F) on exposed “combustible”...
  • Page 19 Fireplace Dimensions and Clearances 50 MINIMUM ENCLOSURE FRAMING WIDTH 10 3/8 72 MINIMUM UNIT FACE TO 18 MINIMUM TO SOFFIT. UNIT BASE TO CEILING VENT CENTERLINE 24" TO VINYL SOFFITS. 20 MINIMUM FRAMING DEPTH 54 MINIMUM ENCLOSURE CEILING HEIGHT FINISHED FRAMING WIDTH 46 3/8 UNIT BASE TO PROTRUSIONS IN THE HATCHED...
  • Page 20 Fireplace Features Identification See below. Identify the features included with this Fireplace and their locations. 46 5/8 OVERALL UNIT WIDTH UNIT WIDTH AT FORNT 19 1/2 UNIT DEPTH GAS SUPPLY INLET " FNPT 40 1/2 UNIT HEIGHT 25 1/8 ELECTRICAL SUPPLY INLET FINISHING GUIDE 110 VAC 32 5/8...
  • Page 21 Convection Blower System Dual blowers are provided as standard equipment with this FV36 DÉCOR Fireplace. The dual blowers have an air output rating of 190 CFM (in free air). This Fireplace is designed to operate with the blowers turned off or on. Turning the blower on aids in distributing and circulating heat to the room this Fireplace is installed in.
  • Page 22 Rough Framing Dimensions Minimum Required Dimensions The rough framing dimensions given are the DIMENSION DESCRIPTION (INCHES) minimum allowed framing dimensions. Be sure 50” ENCLOSURE FRAMING WIDTH when planning the framing of the unit that 43” FINISHED FRAMING WIDTH adequate space to hook up the gas and electrical FRAMING HEIGHT on the left side of the unit.
  • Page 23 Constructing the Appliance Chase A chase is a vertical box-like structure built to enclose this fireplace and its vent system. Vertical vents that run on the outside of a building may be, but are not required to be, installed inside a chase. Construction of the chase may vary with the type of building.
  • Page 24 Clearance from Appliance Side Walls Figure 3-17 CLEARANCE TO BODY 85-03-01154 FV36 DÉCOR Page 24...
  • Page 25 Clearances to Combustible Side Walls The minimum distance required from the side edge of the visible glass to a combustible side wall is 16”. Combustible side walls, mantel corbels, mantel legs and other combustible walls and decorative objects must fall behind a 45-degree line extending outward from the side edges of the visible glass unless such objects are more than 16”...
  • Page 26 Clearances to Combustible Mantels An 8” combustible mantel may be installed at a minimum of 22" above the top of the heat outlet (48-1/2” up from the floor level of this Fireplace). Non-combustible (marble, brick, stone, metal etc.) mantels can be installed at any desired height above the top convection air opening.
  • Page 27 If these materials are used it is recommended that the fireplace is raised at least 12” above the floor. Mendota does not guarantee any materials used around the fireplace. Mendota disclaims any and all liability for any damage to finishing materials including warping, discoloring, cracking, peeling or flaking.
  • Page 28 Finishing to the Bottom Guide WARNING: Careful planning is required to insure a proper finish. Many fronts for the fireplace require different finishing guides than what come on the fireplace. Before installing the hearth pad or wall finishing material on the fireplace insure the correct finishing guides are installed on the fireplace for the front being used.
  • Page 29 1”. This is the depth of the finishing guides on the fireplace and will result in the best final appearance. Mendota does not guarantee any materials used around the fireplace. Mendota disclaims any and all liability for any damage to finishing materials including warping, discoloring, cracking, peeling or flaking.
  • Page 30 Ceramic or Porcelain Tile Use of ceramic or porcelain tiles as facing materials around a Mendota fireplace is approved. If selecting a mosaic tile where tiles are held together with a webbing, ensure the webbing is a non-combustible material like fiberglass. Also ensure that the tiles are not attached to the webbing with a glue or epoxy that will off gas and smell when heated.
  • Page 31: Paint Types Approved For Use

    Mendota fireplaces. Mendota further cautions that proper adhesives be used to attach stone facings. Pay attention to the potential of off gassing of chemical vapors from mastic and other adhesives.
  • Page 32 Please read the following instruction before installing the finishing material on the front of this fireplace. If you have any questions about finishing the fireplace, contact a Mendota dealer or the Mendota Service Department. • To prevent damage, remove any decorative front, screen, or door from the fireplace and mask the fireplace glass frame...
  • Page 33 Recessed Mount Guide Kit: Installing Front Flush Or Recessed Into Wall Note: Order the Recessed Mount Guide Kit from the pricing sheet. This option allows the front to mount with any finish material. The front will fit inside the guides. Allowing the front to be recessed into the wall.
  • Page 34 Many television manufacturers specify in their installation instructions that the television must not be installed near or above a heat source. The decision to install a television near or above a Mendota fireplace rests solely on the consumer. It is the consumers responsibility to satisfy television specifications and insure the television will not exceed maximum operation temperatures.
  • Page 35 Recommendation 3: Install a heat transfer system Mendota Hearth offers three heat transfer systems that take heat from the fireplace and redirect it to another area. When used correctly these heat transfer systems can make it possible to mount a television above the fireplace without installing a mantel or creating a recessed cavity.
  • Page 36: Mendota Cool Wall36

    3.2.17.3.1 Mendota Cool Wall The Mendota Cool Wall system uses natural convection to take heat off the wall directly above the fireplace and redirects it up and away from surrounding areas. Testing has shown that when using a Cool Wall system, temperatures above the fireplace are reduced making it possible to mount a television 15”...
  • Page 37: Versiheat

    3.2.17.3.2 Versiheat The Versiheat system uses a fan to redirect heat from the fireplace to an alternate room in the home. WARNING: To reduce temperatures above the fireplace for mounting a television the Versiheat system must always be on when the fireplace is in operation.
  • Page 38: Flexheat

    3.2.17.3.3 FlexHeat The FlexHeat system uses two inline fans to redirect heat from the fireplace outside the home or to an alternate room in the home. WARNING: To reduce temperatures above the fireplace for mounting a television the FlexHeat system must always be on when the fireplace is in operation.
  • Page 39 Installation by unauthorized personnel; installation of any damaged component; unauthorized modification of vent system; installation of any components not approved by Mendota; failure to meet all clearance requirements; failure to properly twist -lock and positively seal all components.
  • Page 40 Flue Venting Components Identification Diagrams Prior to installing at altitudes higher than 7500, please contact the Mendota technical service department for specific venting requirements and venting restrictions. ITEM DESCRIPTION 6" or 7” PIPE (DuraVent 6”/Amerivent 7”), 9”, 12” 12" VENT STACK 24"...
  • Page 41 Approved Vent Systems STRAIGHT UP, VERTICAL VENTING ZERO VERTICAL HORIZONTAL TERMINATION VERTICAL RISE HORIZONTAL TERMINATION NOT ALLOWED 40 FEET MAXIMUM NOT ALLOWED APPROVED APPROVED VERTICAL RISE DUAL 90° ELBOWS HORIZONTAL TERMINATION VERTICAL RISE DUAL 90° ELBOWS VERTICAL TERMINATION ZERO VERTICAL DUAL 90°...
  • Page 42 Exterior Vent Locations and Restrictions Note: All measurements are to be taken from the center of the vent cap.  -  -  - Vent Terminal Air Supply Inlet Area where terminal is not permitted Clearance above grade, veranda, porch, deck, or *Not to be installed above a meter/regulator balcony (*18 inches (45 cm) minimum) assembly within 3 feet (90 cm) horizontally from the...
  • Page 43 Side by Side installation of two Vent Caps When two or more vertical vent caps are located within proximity of one another, it is required that a galvanized steel 18-gauge or heavier barrier wall be installed between the two vent caps to eliminate recirculation of exhaust gases from one cap to another.
  • Page 44: Lectrical Echnical Eferences

    ELECTRICAL TECHNICAL REFERENCES AC Power Requirements WARNING: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. For normal operation, this appliance requires 120 VAC, 2 Amp power or a 6V DC power source. The AC power supply to this Fireplace must be hot at all times and shall not have a switch installed in it.
  • Page 45 Backup DC Power Inlet Port Installation INSTALLATION: It is important that you install the supplied harness, outlet box and cover plate on the left side of this appliance. The DC Power Inlet harness is 6 feet long, allowing installation of the single gang box up to 5 feet to the left of this appliance. Install the single gang box at a maximum height of 18”...
  • Page 46 PF2 Ignition System Diagram Note: Connect wires in junction box located on the left side This appliance must be electrically connected and grounded of this appliance to house power using supplied wire nuts. in accordance with local codes or, in the absence of local codes, with the current NFPA 70- National Electric Code.
  • Page 47: Lumbing Technical References

    TRAIN. ADHERE STRICTLY TO LOCAL AND NATIONAL CODES. Gas Supply Line Sizing This Mendota Gas Fireplace comes equipped with a 1/2" N.P.T. Female inlet. Gas supply piping must enter the Fireplace cabinet on the left side. Use the table, below, to determine the proper gas line diameter that must be installed to run from the supply regulator to the factory installed manual shutoff valve.
  • Page 48 Gas Pressure Requirements and Checking Two pressure taps for checking input and output gas pressures are located on the main gas valve. A qualified installer should use this fitting for setting the correct gas pressure during initial installation. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in...
  • Page 49 Factory Installed Manual Gas Shutoff Valve A manual gas shutoff valve is factory installed and located in the left-side convection chamber. To operate the manual gas shutoff valve, insert the tip of the glass latch tool into the hole in the valve activation bracket. Rotate the tool 90-Degrees counter clockwise or until it stops to fully close the Valve.
  • Page 50 Gas Input Rate Verification Natural Gas Input Rate Verification Verify main orifice size. The main orifice body has the orifice hole size stamped on it. NG orifice size shall be #32 for all elevations. Verify that the Manifold Gas Pressure is within 3.5" WC +/- 1/8". Once setup, read the main home gas supply meter reading.
  • Page 51: Installation Checklist

    ❑ Adjust vent damper to match vertical chimney length. See 3.15.15 Vent Damper Adjustments ❑ Co-axial vent rigid pipe, wall vent cap or roof vent cap is installed by a Mendota approved serviceperson in accordance with instructions. ❑ All joints are secured, "twist-locked" and leak-proof.
  • Page 52: Unpacking The Fireplace

    Lift the outer box vertically straight upward until lower edge of the box clears the top of the unit body. Set the box aside. Mendota recommends recycling the outer box. Figure 3-33 Outer Box Removal 85-03-01154 FV36 DÉCOR...
  • Page 53: Contents Of The Manual Packet

    Once the outer box is removed, you will find the Fireplace body and a manual packet white box. This manual packet white box includes the items shown in the table, below. Contact Mendota Technical Service if any parts are missing.
  • Page 54: Bending Up The Shipping Clips

    3.10 BENDING UP THE SHIPPING CLIPS Once the unit is detached from the pallet by removing the securing lag screws that hold these shipping clips to the pallet, either bend these clips up 90-degrees or break them off using a screw driver and back and forth cold working motion (see below). A bending relief is provided within the clip to ease bending or breaking.
  • Page 55: T Oremove Door

    3.11 TO REMOVE DOOR Use the glass latch tool to disconnect the spring latches from the glass frame. Insert tool into hole in latch, pull towards you and rotate 90-degrees to disengage top latches. Remove tool. There are two spring latches on top of this gas fireplace. Always make certain the hook glass latches are in the upside-down position after removing the glass frame.
  • Page 56: Light Bulb And Light Lensi

    3.13 LIGHT BULB AND LIGHT LENS INSTALLATION WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Before you install a firebox inner liner kit or a log set, install the accent light bulb and the accent light lens kit. To install the light bulb and light lens kit, follow these instructions: 1.
  • Page 57: Natural Gas To Lpg Conversion

    3.14 NATURAL GAS TO LPG CONVERSION WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion o r production of carbon monoxide may result causing property damage, personal injury or loss of life.
  • Page 58 CAUTION: Always use one 7/16” open end wrench and one large pliers or vice grips tool to hold, loosen and tighten pilot hood base to prevent d amage to pilot mount bracket. 5. While holding the pilot base body with large vice grips tightly, loosen the pilot’s hex-shaped base using a 7/16” open end wrench.
  • Page 59 Pressure Regulator Conversion WARNING: Failure to position the parts in accordance with these diagrams or failu re to use only parts specifically approved with this appliance may result in property damage or personal injury. 1. See Figure 3-12-1: Using a Torx T20 (supplied) or slotted screwdriver, remove and discard the two pressure-regulator mounting screws (A);...
  • Page 60 Burner Ignition Characteristics Note: Connect gas supply and verify that the minimum inlet and outlet pressures are conforming. Once the conversion to LPG and all the above steps have been completed, light the main burner. Use remote transmitter to turn on pilot light and burner. Main burner should now light IMMEDIATELY and flame should not "lift"...
  • Page 61: Venting

    CAUTION: Each installation must conform to all local, state and national codes. Refer to the national fuel gas code and local zoning and code authorities for details on installation requirements. The Mendota Fireplaces must be vented to the outside in accordance with the latest edition of the National Fuel Gas Code.
  • Page 62 12’ – 40’ Varies point vertically and directly to the vent termination cap. High Altitude Installation Information Prior to installing at altitudes higher than 7500, please contact the Mendota technical service department for specific venting requirements and venting restrictions. 40'-0" 36'-0"...
  • Page 63 Using 90 Elbows The FV36 DÉCOR Fireplace by MENDOTA allows maximum flexibility in the use of 90 elbows in the vent system. The length of the first straight vertical section directly connected to the fireplace’s starter collar determines the maximum horizontal run and the number of 90 elbows allowed for this fireplace.
  • Page 64 Zero Rise Horizontal Termination The FV36 DÉCOR Fireplace must be installed by a qualified Mendota approved serviceperson. A maximum horizontal run of 12” is allowed if a 9” vertical starter section and one 90° elbow is connected directly to this fireplace’s flue starter collar.
  • Page 65 Vertical Rise Horizontal Termination The minimum vertical section required to be connected directly to the starter adapter on this fireplace is 4’ when used with a maximum horizontal run of 32’. If the total length of the vertical sections connected directly to the starter adapter on this fireplace is between 4’...
  • Page 66 V(2’ MIN) H1 + H2 MAX 2’ 9’ 11” 3’ 19’ 6” Vertical Rise 4’ 32’ Three 90° Elbows 4’ – 12’ 32’ Horizontal Termination Use the Master Venting Chart to calculate For V greater than 12’, see allowable lengths. Master Venting Chart VERTICAL RISE DUAL 90°...
  • Page 67 Vertical Through-The Roof Venting The maximum vertical run of vent pipe is 40 ft. from the top of the fireplace. The fireplace will support a run of a maximum of 40 ft. Maintain 1" air space clearances on all sides of vents (3" above horizontal runs). If an offset is required directly on top of the fireplace, two 45 elbows may be connected directly to the top of this fireplace to create a horizontal offset then to run upwards vertically.
  • Page 68 STRAIGHT UP, VERTICAL VENTING VERTICAL RISE DUAL 90° ELBOWS VERTICAL TERMINATION 40 FEET MAXIMUM 85-03-01154 FV36 DÉCOR Page 68...
  • Page 69 Mendota has spent considerable time and effort in the design of this fireplace and its venting system. Through this effort, Mendota has been able to certify the use of Four 90 elbows.
  • Page 70: Log Set/ Media Installation

    3.16 LOG SET/ MEDIA INSTALLATION There is a plethora of options for log sets and media kits to compliment your new Mendota fireplace. To learn more about all the log set and media kit options available please consult your local Mendota dealer.
  • Page 71: Air Shutter Control Andf

    3.18 AIR SHUTTER CONTROL AND FLAME APPEARANCE During initial installation, the air shutter opening should be checked to be certain that the shutter is set correctly at 1/16”-1/8" open for natural gas and 1/4" minimum open for L.P. gas. NOTE: For altitudes above 5,000’, some variations may be required.
  • Page 72: Aesthetic Considerations

    We are committed to quality and satisfaction for all Mendota owners. Thank you for choosing a Mendota to be a source of comfort and beauty in your home.
  • Page 73: Operating Information

    4.4 OPERATING INFORMATION Using Your Remote Control Your Mendota remote control is pre-programmed to your fireplace. Ensure you have installed 3 AAA batteries into your remote. Press the top button on the remote control. If you do not hear a beep when you press this button, follow the instructions below to synchronize your fireplace and remote control.
  • Page 74 Remote Control Functions NOTE: You will hear an audible beep once every time a remote-control button is pressed, signaling that the command has been received. If you do not hear the beep, press the button again. Locate the four function buttons on the remote control: On/Off Button: This button turns the fireplace on or off.
  • Page 75: Remote Control Operating

    4.5 REMOTE CONTROL OPERATING INSTRUCTIONS To Turn on the Fireplace NOTE: If the fireplace does not respond to the remote-control commands, the fireplace system may have entered “safety Chapter 4.11.12 Why won’t my fireplace turn on? lockout” mode. To reset the system, see Press the on/off button.
  • Page 76 Icon Details Mode Button: Pressing the mode button toggles between the various available functions: flame height, fan speed, accent light intensity and rear burner on/off. Flame Height: Six flame height levels are available. While the flame height icon is displayed, pressing the up or down button once will increase or decrease the flame height by one of six increments.
  • Page 77: Ipi And Cpi Modes

    Note: The snowflake icon will be visible on the display at all times when in CPI mode. Recommended: Mendota recommends that CPI mode is used during the winter months ° when the average daily high temperature falls below 50 F.
  • Page 78: Operating Instructions

    4.8 First Time Lighting Instructions WHAT TO DO IF YOU SMELL GAS Warning: If you do not follow these instructions Do not light any appliance. exactly, a fire or Do not touch any light switch explosion may result Do not use any phone in your building. causing property Call your gas supplier from a neighbor's phone.
  • Page 79: Frequently Asked Questions

    Where can I find the model and serial numbers? When requesting service, you will be asked to provide the model number and serial number to your Mendota dealer. This information will expedite the warranty verification process. The Listing Label contains the model number and serial number for your particular appliance.
  • Page 80 Can I use my Fireplace during power outages? This electronic ignition system uses the supplied 110VAC power when it is available for all functions of this system. If you experience a power outage, plug in the battery pack (6V DC maximum, supplied with this fireplace) to the fireplace backup power inlet port.
  • Page 81 These adjustments should be made by a qualified technician to achieve the best flame performance. Contact your installer or Mendota dealer if you feel your fireplace is not burning correctly. Improper setup and adjustment is not covered under warranty.
  • Page 82 This should clear the lockout mode. Turn on the remote and start the fireplace. Ensure the master switch is in the run/on position. After completing these steps, contact your Mendota dealer if fireplace won’t turn on. What happens when I first light my fireplace? When you first light your fireplace, the initial curing phase is initiated.
  • Page 83: Required Periodic Inspections

    MAINTENANCE INFORMATION 5.1 REQUIRED PERIODIC INSPECTIONS Check to verify that the vent system and vent cap are open and free of blockage. Have qualified service person check the operation of the pilot light. Pilot light must light within the first five to eight seconds of ignitor sparks initiation.
  • Page 84: Over Firing Or Under Firing Of

    If you are using a “backyard” Natural Gas well as the gas source, you must submit formal gas analysis data sheets to Mendota Fireplaces for review and calculation of proper main burner orifice sizes prior to first firing. It is known that unpurifi ed Natural Gas from “backyard” wells can contain high energy levels causing over firing.
  • Page 85: Replacement Parts Information

    5.7 REPLACEMENT PARTS INFORMATION How to Access Components The descriptions below show where the main fireplaces components are located and how to access them for service. The descriptions show how to access the components after the fireplace has been installed. All components are also accessible from the outside of the unit before the fireplace is installed.
  • Page 86 Convection Air Blower System Parts HA-110-00002 LEFT BLOWER ASSEMBLY HA-110-00003 RIGHT BLOWER ASSEMBLY 15-02-00130 EBM BLOWER LH, ROTATED 65-02-01032 FV36 BLOWER GASKET 15-02-00129 EBM BLOWER, RH ROTATED Figure 5-3 FV36 DÉCOR BLOWER ASSEMBLIES Accent Light Parts HA-58-04606 ACCENT LIGHT HOUSING 10-11-00020 LIGHT BULB, G9 XENON, 25W 10-11-00025...
  • Page 87 Gas Train Assembly Parts Figure 5-5 Gas Train Assembly Parts 85-03-01154 FV36 DÉCOR Page 87...
  • Page 88 Burner Figure 5-6 Burner 85-03-01154 FV36 DÉCOR Page 88...
  • Page 89 Glass Frame Parts Replacement Procedure WARNING: do not use substitute materials. All replacement materials must be certified and obtained through Mendota fireplaces. TO REPLACE DAMAGED GLASS Bend glass retainer tabs up 90 degrees. Four tabs hold down the glass and gasket assembly.
  • Page 90: Final Installation And Homeowner Checklist

    ❑ Burner flames are “stable” and are not “lifting” off burner. ❑ Inform owner that an initial curing step is required. Read and follow Mendota Fireplace and Insert Curing Instructions (found on unit and in owner’s manual). Smoke will emit during initial curing step.
  • Page 91: Warranty Policy Statement

    6.2 WARRANTY POLICY STATEMENT Mendota Fireplace, a division of Johnson Gas Appliance Company, extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below.
  • Page 92: Onditions

    Owner accepts that this appliance requires close monitoring of children and vulnerable individuals who are in the vicinity of this appliance when it is in operation. Mendota does not assume or accept any liability claims for burns or other physical or material damages resulting from touching hot glass surface and hot metal surfaces that are part of this appliance or other adjacent object such as hearth pads and mantels that may heat up during operation of this appliance.
  • Page 93 How to Obtain Warranty Service If you discover a problem that you believe to be covered by the warranty, you must report to your Mendota Dealer within 30 days, with proof of purchase, purchase date, model name and serial number.
  • Page 94 Owner Registration After installation, Mendota fireplace owners must register with Mendota to qualify for the Lifetime Limited Warranty within 30 days. Product registration will activate your Lifetime Limited Warranty. Owners should complete the forms available at: mendotahearth.com/warranty Note: Your Mendota dealer can assist with warranty applications and information.
  • Page 96 Johnson Gas Appliance Company 520 E Avenue NW Cedar Rapids, Iowa 52405 Mendota Warranty Registration...
