6" DUAL ACTION
AIR SANDER
Model 42966
ASSEMBLY AND OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
©
®
Copyright
2004 by Harbor Freight Tools
. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 42966
Summary of Contents for Central Pneumatic 42966
- Page 1 ® 6” DUAL ACTION AIR SANDER Model 42966 ASSEMBLY AND OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http://www.harborfreight.com TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE. ©...
-
Page 2: Product Specifications
Keep this manual and invoice in a safe and dry place for future reference. READ AND UNDERSTAND ALL INSTRUCTIONS Failure to follow all instructions listed in the following pages may result in electric shock, fire, and/or serious injury. SKU 42966 For technical questions please call 1-800-444-3353 PRODUCT SPECIFICATIONS "... -
Page 3: Work Area
Use clamps or other practical ways to secure and support the workpiece to a stable platform. Holding the work by hand is unstable and may lead to loss of control. Only work on a workpiece that is properly secured. SKU 42966 For technical questions please call 1-800-444-3353 WORK AREA... -
Page 4: Specific Safety Rules
Use of unauthorized parts or failure to follow maintenance instructions may create a risk of injury. Maintain labels and nameplates on the Sander. These carry important informa- tion. If unreadable or missing, contact Harbor Freight Tools for a replacement. - Page 5 Do not force the Sanding Paper into the workpiece when sanding. Apply moderate pressure, allowing the Sand Paper to cut without being forced. When turning off the Sander, allow the Pad to spin down and stop on its own. Do not press against the Pad to stop it.
- Page 6 Quick Connector into the Hose Adapter. (See Figure A.) Prior to each use, if an automatic oiler is not included in the air compressor hook up, add two drops of air tool oil (not included) into the Air Inlet fitting of the Sander. RECOMMENDED COMPRESSED AIR SYSTEM SETUP...
-
Page 7: Bottom View
Hub (28) turns to engage the Drive Spindle (35), allowing the Pad (37) to be threaded on securely. Turn the Orbital Hub (28) back out of the way before use. If the Orbital Hub is still in the locked position during use, then the Sander will not operate properly. (See Figure C.) The Sander only uses 6”... -
Page 8: Inspection, Maintenance, And Cleaning
IMPORTANT: Before first use, it is recommended to test the Sander on scrap material to determine the cutting capacity of the Sanding Paper. Connect the air supply hose to the Sander. Turn on the air compressor (not in- cluded), and set its regulator to the recommended 90 PSI for the Sander. -
Page 9: Please Read The Following Carefully
End Plate Cylinder Rotor Rotor Blade NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 42966 For technical questions please call 1-800-444-3353 PARTS LIST Qty. Part # Description Rotor Shaft... -
Page 10: Assembly Diagram
ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 42966 For technical questions please call 1-800-444-3353 PAGE 10...
