® 5” AIR SANDER/DRILL Model 35245 ASSEMBLY AND OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http//www.harborfreight.com ® Copyright 1997 by Harbor Freight Tools . All rights reserved. No protion of this manual or any artwork contained therein may be reproduced in any shape or form with- out the express written consent of Harbor Freight Tools.
Inspect all hoses for leaks prior to use. The handles must be kept clean, dry, and free from oil and grease at all times. Page #2 -- SKU: 35245...
Page 3
Sander, follow the Steps below. Sander Assembly Step 1: Open the CHUCK (#31) by turning the CHUCK counterclockwise. Insert the short end of a Hex Key Wrench into the CHUCK and tighten. Page #3 -- SKU: 35245 REV 01/04...
Page 4
These can be purchased at Harbor Freight Tools. Step 6: Place the desired BACKING PLATE (#28, 29, or 30) over the threads of the ROTOR (#19). Place the sandpaper disc over the BACKING PLATE. Page #4 -- SKU: 35245...
Page 5
Step 3: When the Jaws are open wide enough to insert the drill bit, slide the bit into the CHUCK as far as possible. Step 4: By hand, turn the CHUCK to tighten the Jaws. Page #5 -- SKU: 35245...
Dirt and water in the air supply are major causes of pneumatic tool wear. Use a filter/oiler for better performance and longer life. The filter must have adequate flow capacity for the specific application. Consult the manufacturer’s instructions for proper maintenance of your filter. Page #6 -- SKU: 35245...
Page 7
Step 6: Grip the Sander/Drill firmly. Place the drill bit on the spot marked in Step 1. CAUTION Do not operate the Drill before placing the drill bit on the material. Page #7 -- SKU: 35245...
Page 8
Step 3: To operate the Sander/Drill, grip the BODY (#1) with your palm and place pressure on the TRIGGER (#10) to begin sanding. Step 4: You can vary the speed of the Sander/Drill to suit different sanding applications by varying the pressure placed on the TRIGGER. Page #8 -- SKU: 35245...
Step 3: Apply a few drops of oil to the TRIGGER (#10) as shown in Figure 6. Work the TRIGGER a few times to lubricate. Figure 6 — Lubrication Points Page #9 -- SKU: 35245...
TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACMENT PARTS THERETO. Page #10 -- SKU: 35245...
