Introduction
The VX-2500V is carefully aligned at the factory for the specified performance across the
frequency range specified for each version. Realignment should therefore not be necessary
except in the event of a component failure, or altering version type. All component
replacement and service should be performed only by an authorized Vertex Standard
representative,or the warranty policy may be void.
The following procedures cover the sometimes critical and tedious adjustments that are not
normally required once the transceiver has left the factory. However, if damage occurs and
some parts subsequently are placed, realignment may be required. If a sudden problem
occurs during normal operation, it is likely due to component failure; realignment should not
be done until after the faulty component has been replaced.
We recommend that servicing be performed only by authorized Vertex Standard service
technicians who are experienced with the circuitry and fully equipped for repair and
alignment. Therefore, if a fault is suspected, contact the dealer from whom the transceiver
was purchased for instructions regarding repair. Authorized Vertex Standard service
technicians realign all circuits and make complete performance checks to ensure compliance
with factory specifications after replacing any faulty components.
Those who do undertake any of the following alignments are cautioned to proceed at their
own risk. Problems caused by unauthorized attempts at realignment are not covered by the
warranty policy. Also, Vertex Standard reserves the right to change circuits and alignment
procedures in the interest of improved performance, without notifying owners.
Under no circumstances should any alignment be attempted unless the normal function and
operation of the transceiver are clearly understood, the cause of the malfunction has been
clearly pinpointed and any faulty components replaced, and realignment determined to be
absolutely necessary.
The following test equipment (and thorough familiarity with its correct use) is necessary for
complete realignment. Correction of problems caused by misalignment resulting from use of
improper test equipment is not covered under the warranty policy. While most steps do not
require all of the equipment listed, the interactions of some adjustments may require that
more complex adjustments be performed afterwards.
Do not attempt to perform only a single step unless it is clearly isolated electrically from all
other steps. Have all test equipment ready before beginning, and follow all of the steps in a
section in the order presented.
Required Test Equipment
RF Signal Generator with calibrated output level at 1000MHz
Deviation Meter (linear detector)
In-line Wattmeter with 5% accuracy at 1000MHz
50- Ω RF Dummy Load with power rating 100W at 1000MHz
4- Ω AF Dummy Load
Regulated DC Power Supply (standard 13.8V DC, 15A)
VX-2500V Alignment
1/6
FCC ID: K66VX-2500V
Alignment
Vertex Standard Co., Ltd.

Advertisement

loading

Summary of Contents for Yaesu VX-2500V

  • Page 1 VX-2500V Alignment Introduction The VX-2500V is carefully aligned at the factory for the specified performance across the frequency range specified for each version. Realignment should therefore not be necessary except in the event of a component failure, or altering version type. All component replacement and service should be performed only by an authorized Vertex Standard representative,or the warranty policy may be void.
  • Page 2 FCC ID: K66VX-2500V Alignment Frequency Counter with 0.1ppm accuracy at 1000MHz AC Voltmeter DC Voltmeter VHF Sampling Coupler IBM PC / compatible Computer Oscilloscope Vertex Standard VPL-1 Connection Cable & Alignment program Alignment Preparation & Precautions A 50- Ω RF Dummy Load and in-line wattmeter must be connected to the main antenna jack in all procedures that call for transmission, except where specified otherwise.
  • Page 3: Pll Reference Frequency

    FCC ID: K66VX-2500V Alignment AF Generator Ground (Fig 2: J1502 connection for the modulation adjustment) The transceiver must be programmed for use in the intended system before alignment is attempted. The RF parameters are loaded from the file during the alignment process. [Important] In order to facilitate alignment over the complete switching range of the equipment it is recommended that the channel data in the transceiver is preset as the chart below.
  • Page 4 FCC ID: K66VX-2500V Alignment directly as you think fit, and copy this file. That is all of the installation process. Boot the tool Change directly and input in command line, " svc47 [enter] ", and boot the alignment tool. Preparation Setup the test equipment as "Alignment Preparation &...
  • Page 5 FCC ID: K66VX-2500V Alignment specification, as indicated on the deviation meter. When the desired deviation level is attained, press [Enter] to lock in the new data. Select the Channel 2, and set the VCO Deviation (Narrow), same as Channel 1. VCO Deviation(Wide) :4.0[kHz](±0.1[kHz]) VCO Deviation(Narrow):2.0[kHz](±0.1[kHz])
  • Page 6 FCC ID: K66VX-2500V Alignment Actual DCS Deviation(Narrow):0.35[kHz] - [6] LTR Deviation This parameter is used to align the LTR deviation. Press [Enter] on "[6] LTR Deviation " to align LTR Deviation. Select the Channel 1 in alignment range. Press the [Space] key on the keyboard to activate the transmitter, and injects a LTR test tone.
