VERSION
# 20-08-25
1 / 10
MODEL #
CM7897EK/CK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America Davida CM7897EK
Summary of Contents for Furniture of America Davida CM7897EK
- Page 1 MODEL # CM7897EK/CK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 10...
- Page 5 CM7897EK/CK #4 8pcs #2 1pc #3 2pcs #1 1pc Support Leg Headboard Footboard Side Rail 195x30x30mm #5 1set #6 2pcs #7 8pcs Slat （ 13pcs ） Plastic Feet Support Rail #A 8pcs #B 8pcs #C 8pcs Lock Washer Ø5/16" Bolt Ø5/16" x 2-1/2" Flat Washer Ø5/16"...
- Page 6 CM7897-CK/EK is packed in 3 cases Carton Disignation Part Hardware Headboard CM7897-EK/CK Side Rail CM7897-EK/CK Support Rail Footboard #A x 8 pcs #Bx 8pcs Support leg #Cx 8 pcs #D x 34 pcs CM7897-EK-FB Slat （ 13pcs ） #E x 1pc Plastic Feet 6 / 10...
-
Page 7: Exploded View
Exploded View 7 / 10... - Page 8 ASSEMBLY INSTRUCTIONS Align plastic feet (#7) to the footboard (#2), then secure by using screws (#D). There may not be pre-drilled holes. Part #2 x1pc Part #7 x8pcs Hardware #D x8pcs Align side rails (#3) to headboard (#1) and footboard (#2), then secure by using bolts (#A) Part #1 x1pc with washers (#B,C).
- Page 9 ASSEMBLY INSTRUCTIONS Align center slats (#6) to the slat kit (#5), then secure by using support legs (#4). Part #4 x8pcs Part #5 x1set Part #6 x2pcs Align slats to the side rails, then secure by using screws (#D). Hardware #D x26pcs 9 / 10...
- Page 10 ASSEMBLY INSTRUCTIONS 10/10...
