Hardware Designed for Professional Installers -
Equips You with Instant Diagnostic Tools
Installing and programming the MSC-400 Master System Controller is sped enormously by a combination of
hardware and software design features. The MSC-400 is optimized for installation in a equipment rack or
MX-3000
cabinet. Softly glowing blue and green LED's on the front panel indicate connections, sensor status and the RF
environment. In one glance, the professional installer can diagnose the system. When programming is required,
the installer simply connects a laptop via USB cable to the front panel programming port. No controls are
accessible to the end user (even if the end user were to connect to the MSC-400's programming port, they
cannot upload the configuration).
Software Designed for Professional Installers -
Optimizes Programming
Flexibility with SPEED
MRF Editor software offers extensive control options,
MX-950
RS232 Two Way Diagnosis, IF/ELSE nesting logic and
elaborate speed options, like the channel favorites tool,
which enables installers to program dozens of numeric
keypad macros in seconds. The result, no limits on your
imagination when it comes to dreaming up new features
to make operation easier and fast, fast programming...
Expands to Control 22 Components
TX-1000
The unique Master/Slave programming options enables installers to combine two MSC-400's into one
equipment location with complete integration of all macros in one Master MSC-400. The two MSC-400's are
slaved together via the #12 RS-232 Ports on both units. Thus a combined system controls 22 components.

Specifications

Microprocessor: Advanced ARM7TDMI
microprocessor enables the MSC-400 to perform
sophisticated logic, with nested IF ELSE
statements and tests of sensors and variables.
Memory: 32 Megabytes of SDRAM and 64
Megabytes of NAND Flash Memory enable the
MSC-400 to support vast, complex configurations.
MX-900
Macro Capability: Supports up to 32,640 macros of
255 steps in each macro. Since Macros can be
nested as one step inside another Macro, there is
no realistic limit for macro steps.
COMPLETE
COMPLETE
CONTROL
Instead of a simple macro, the MSC-400 intelligently tests each component to see whether it is on or off, then
sends the exact commands needed to reconfigure the system. As a result, the system responds perfectly to the
user, as if an invisible engineer was concealed in the system cabinet, operating the system for them.
™
500 Mamaroneck Avenue, Harrison, NY 10528
Learning Capability: Standard frequencies
(15kHz to 460kHz)
RF Range: (Radio Frequency):
50 to 100 feet, depending
upon the environment
RF Frequency: 418 MHz
Weight: 77.6 oz.
Size: 17.25" x 8.5" x 2.5"
Phone: (914) 835-4484
www.universalremote.com
Fax: (914) 835-4532
