Thank you for purchasing the Inada DreamWave.
We hope the Inada DreamWave will be a valued partner in your
daily health preservation for many years to come.
●
Please read this Operating Manual before use.
●
Keep this manual nearby so that you can refer to it anytime.
●
This product is designed for home use.
●
●
●
●
●
●
ENGLISH
HCP-11001A
HCP-11001D
HCP-11001E
Operating Manual
Warranty card provided separately

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DREAMWAVE HCP-11001A and is the answer not in the manual?

Questions and answers

Related Manuals for inada DREAMWAVE HCP-11001A

Summary of Contents for inada DREAMWAVE HCP-11001A

  • Page 1 HCP-11001A HCP-11001D HCP-11001E Thank you for purchasing the Inada DreamWave. We hope the Inada DreamWave will be a valued partner in your daily health preservation for many years to come. ● Please read this Operating Manual before use. Operating Manual ●...

  • Page 2: Table Of Contents

    HCP-11001E CONTENTS Thank you for purchasing the Inada DreamWave. SAFETY PRECAUTIONS ··················1 We hope the Inada DreamWave will be a valued partner in your daily health preservation for many years to come. MAIN FEATURES ······························4 COMPONENTS & DESCRIPTION ····5 BEFORE USE ······································9 POSITION ADJUSTMENT ·············11...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Be sure that you have read these SAFETY PRECAUTIONS thoroughly before using your Inada DreamWave for the rst time. The Operating Manual contains important information about how to use the chair safely and correctly, avoiding possible damage to property or injury to persons using the chair and others.
  • Page 4 Safety Precautions: Before Use Warning ● The following persons must not use this massage chair: ◎  P ersons who have been instructed by a doctor to avoid massage therapy. Ex. Thrombosis, severe aneurism, acute varicosity, or dermatitis and/or skin infection including in ammation of the hypodermis. ◎Persons with suspected acute neck sprain (whiplash injury) ●...
  • Page 5 SAFETY PRECAUTIONS Safety Precautions: During Use Caution ● Do not use the chair unclothed. ● Do not use the chair for purposes other than massage, or other than the ordinary uses of a chair. → Could result in accident or injury. ●...

  • Page 6: Main Features

    Automatic Shiatsu Point Locator operation is extended to cover lower positions, to fit the shoulder positions of young people. Benefits As a therapeutic massage device in the general households, the Inada DreamWave provides the following benefits: ● ●...

  • Page 7: Components & Description

    COMPONENTS & DESCRIPTION Chair Shoulder Massage Unit Back Pad Upper-Arm Units Rollers (Storage roller positions are inside the upper part of the seat back.) Armrests Forearm Units Seat Leg Rest Calf Unit Foot Unit Smart Phone Pocket...
  • Page 8 Counter Weight for the Reclining Shoulder Massage Unit Seat Back A weight for adjusting the position of the Shoulder Massage Unit is housed inside. Remote Control Reclining Safety Mechanism Pocket for the Remote Control Control Box Cord Connector Plug Wheel Power Cord Main POWER Switch...
  • Page 9 COMPONENTS & DESCRIPTION Remote Control Remote Control Display Information, such as massage action descriptions, status of progress, and the intensity and speed of the massage in progress, is displayed with both characters and symbols. (See next page.) Preset Programs For selecting a program with the corresponding course name ROLLER Buttons During Preset Programs, roller shoulder positions can...
  • Page 10 Remote Control Display Information, such as massage action descriptions, status of progress, and the intensity and speed of the massage in progress, is displayed with both characters and symbols. Characters and symbols on the display move from right to left. Example: While the Shiatsu Point Locator sensors are being activated, the display shows the following text: “Locating Shiatsu Points...”...

  • Page 11: Before Use

    BEFORE USE ● This product is shipped with the reclining seat back in its fully reclined position and with the armrests and leg rest removed. Before use, be sure to attach the armrests and leg rest (refer to the insertion sheet attached) then raise the seat back to its upright position.
  • Page 12 Checking the Seat Cover Check for holes or tears in the back pad and other parts. Lift the Shoulder Massage Unit Check also that the zippers located at both sides of the up to check for holes or tears in Shoulder the cover of the back pad.

  • Page 13: Position Adjustment

    POSITION ADJUSTMENT How to Sit When the chair is off, the rollers are normally drawn back into the left and right sides of the upper part of the seat back (Storage Position). For safety reasons, first check the positions of the rollers. If they are in any position other than storage positions, set the main POWER switch to ON before sitting down to allow the rollers to return to their storage position.
  • Page 14 Foot Slide Adjustment Function ■ How to Move the Foot Unit Downward To slide the Foot Unit of the leg rest to move it downward, push it down with your feet. ● Be careful not to get hands, feet, or objects caught between the leg rest units or between the leg rest and the chair during a foot slide operation.
  • Page 15 POSITION ADJUSTMENT How to Use the Shiatsu Pads for Shoulders and Feet The Shiatsu Pad for Shoulders (strong) are placed inside the Shoulder Massage Unit. If you feel that the massage given by the Shoulder Massage Unit is too strong, replace it with the Shiatsu pads (light).

  • Page 16: After Use

    How to Use the Upper-Arm/Forearm Units Place your arms in the Upper-Arm and Forearm * Place your arms in the * Be careful not to place your Units, as illustrated. Upper-Arm and Forearm elbows where the air cushions are. Units with your palm down. Be careful not to place your elbows where the air cushions are.

  • Page 17: Massage Programs

    MASSAGE PROGRAMS & SELECTION PRESET PROGRAMS A total of 16 Preset Programs provide massages to meet your desired purpose and application according to the preset menus. Massage Courses MANUAL SELECTION MODE You can combine your favorite massage types. You can also adjust the speed, intensity, and roller positions.
  • Page 18 Full Body For a comprehensive full-body Healthcare massage. This program is recommended for persons who feel fatigue or lack of energy. Full Body Air HEALTHCARE For a comprehensive full-body massage focused on air massage. PROGRAMS This program is recommended for persons who prefer softer massage.

  • Page 19: Preset Programs

    PRESET PROGRAMS Preset Programs ● Sixteen automatic programs provide a variety of different massages to relieve fatigue. ● With the Preset Program buttons, you can choose your favorite program, which will provide a carefully crafted massage suited to your needs. Various Adjustments ■...
  • Page 20 Press the POWER button. ❶ If no selection is made within 2 minutes, the power will automatically shut off. Press the desired button. ● Press and hold the program button for 2 seconds selects the Deep Relaxation version of the massage course.

  • Page 21: Manual Selection Mode

    MANUAL SELECTION MODE How to Operate Manual Selection Mode ① ④ You can combine massaging actions of your choice from among menus ● A circle in the adjustment column means that the particular adjustment can be made in the course of that massage action.
  • Page 22 ③ Rolling Automatic Shiatsu Point Locator is performed in the same manner as in the Preset Program. Operation Button Action Indication Width Down This performs stretching of the full Full Rolling or partial spine with only up and ○ ○ down movements of the rollers.
  • Page 23 MANUAL SELECTION MODE Various Adjustments ■ ■ BACK 3-D Buttons Change in Forward/Reverse Directions Operation Indication Action Operation Button Action The intensity of back massage can During Kneading, Human ＋ Forward Intensity be continuously adjusted with [ Hands, and Kneading & −...
  • Page 24 How to Operate Manual Selection Mode Press the POWER button. ❶ If no selection is made within 2 minutes, the power is automatically shut off. Press the desired button. ❷ * Full Rolling, or Partial Rolling is selected, the Automatic Shiatsu Point Locator starts locating Shiatsu points.

  • Page 25: Troubleshooting

    TROUBLESHOOTING If there is still a problem after trying the solutions given in this troubleshooting guide, stop using the product immediately so as to prevent accident or injury and unplug the product from the wall outlet. For contact your local distributor, please refer to the last page of this booklet. Noise during operation: Problem ●...
  • Page 26 Anyone other than an authorized serviceperson must not repair or disassemble. The Automatic Shiatsu Point Locator Function is not working properly. Problem (The height of rollers does not fit the shoulders.) Sit further back in the chair so that your head rests firmly on the Shoulder Massage Unit. The Cause &...
  • Page 27 TROUBLESHOOTING If I try to recline the seat back or adjust the angle of the leg rest during air Problem massage, the chair stops. For safety purposes, the air pressure massage is designed to stop if the reclining seat back or the Cause &...

  • Page 28: Faq

    How do I make the massage deeper? During Preset Programs, adjust the intensity of massage with the BACK 3-D, AIR LEVEL, Back Vibe button (behind the panel), or each operation button for air massage (behind the panel) on the remote control. In Manual Selection mode, adjust the intensity of massage with the BACK 3-D, Back Vibe button (behind the panel), or each operation button for air massage (behind the panel) on the remote control.

  • Page 29: Care And Storage

    CARE AND STORAGE Storage ● After wiping off any dust or dirt, store the product in a place that is relatively dry. ● If you are not going to use the product for some time, put a cover on it that will protect it from dust and dirt.

  • Page 30: Customer Service And ·········· 28 Warranty Regular Maintenance

    CUSTOMER SERVICE AND WARRANTY 1. Warranty Please read the contents carefully and keep it in a safe place. Please complete and mail in the warranty card that was include with your chair. If the chair is to be used outside the home (in a commercial setting, for example), fees will be charged for repairs.
  • Page 31 REGULAR MAINTENANCE FOR SAFETY Regular Maintenance Will Preserve the Life of Your Chair Have you experienced any of these problems? ● The chair does not start with the main POWER switch set to ON. ● The power cord has been cracked or scratched. ●...

  • Page 32: Specifications

    SPECIFICATIONS Model Number HCP-11001A HCP-11001D HCP-11001E Power Supply AC 120 V AC 220-240 V AC 110 V~ Power Consumption 208 W Power Frequency 60 Hz 50-60 Hz 60 Hz Rated Time 30 minutes 3 levels, from minimum approx. 9 times/minute to maximum approx. 32 Kneading Speed times/minute 3 levels, from minimum approx.
  • Page 33 HCP-11001A HCP-11001D HCP-11001E...
  • Page 44 RECLINE LEG REST...
  • Page 51 ❶ ❷ ❸ ❹ ❺...
  • Page 52 • •...
  • Page 55 ❶ ❷ ❸ ❹...
  • Page 64 HCP-11001A HCP-11001D HCP-11001E...
  • Page 82 ❶ ❷ ❸ ❹ ❺...
  • Page 83 • •...
  • Page 86 ❶ ❷ ❸ ❹...
  • Page 95 DATE OF ISSUE (day/mo/yr) Manufactured by FAMILY INADA CO., LTD. 1/7/2014 Made in Japan 778612002...
