GENERAL SPECIFICATIONS

Shipping Weight
Operating Weight
Shipping Weights With Optional
Track Shoes
Major Component Weights
Digging Forces:
Bucket Cylinder
Arm Cylinder
Fuel Tank Capacity
Hydraulic System Capacity
Hydraulic Reservoir Capacity
Bucket Heaped Capacity Range
Shoe Type
Shoe Width and Optional Sizes
Ground Pressure Ratings:
Standard 600 mm (23.6")
shoe -
Optional 700 mm (28.0")
shoe -
Optional 800 mm (32.0")
shoe -
Optional 850 mm (34.0")
shoe -
Transport Dimensions
S0202110K
Page 10
33.9 metric tons (74,700 lb), includes 10% fuel, boom, 3,200 mm
3
(10' 5") arm, 1.3 m backhoe bucket and standard shoes
Add weight of full fuel tank and operator.
Add 400 kg (882 lb) for 700 mm (28") shoes
Add 800 kg (1,764 lb) for 800 mm (32") shoes
Add 1,000 kg (2,204 lb) for 850 mm (34") shoes
Standard Boom 2,530 kg (5,577 lb)
2,600 mm (8' 6") Arm 1,100 kg (2,425 lb)
3,200 mm (10' 5") Arm 1,100 kg (2,425 lb)
4,000 mm (13' 1") Arm 1,330 kg (2,932 lb)
Boom Cylinders 285 kg (628 lb) each
Arm Cylinder 419 kg (928 lb)
Bucket Cylinder 269 kg (593 lb)
Counterweight 6,400 kg (14,109 lb)
Upper Turntable 8,870 kg (19,555 lb)
Lower - below Swing Bearing 11,630 kg (25,640 lb)
214 KN or 21,800 kg (48,060 lb) - (with either 3,200 mm [10' 5"]
or 2,600 mm [8' 6"] arm)
171 KN or 17,400 kg (38,360 lb) with 3,200 mm (10' 5") standard
arm
550 liters (145 U.S. gal)
460 liters (122 U.S. gal)
210 liters (56 U.S. gal)
3
PCSA 1.25 - 1.83 m (1.63 - 2.56 yd
IMPORTANT: Refer to the Load Weight, Bucket and Arm Length
Compatibility Table for information on which bucket sizes may be
used safely with which arm length, for load material weights.
Triple Grouser
600 mm (23.6") - standard
700 mm (28") - optional
800 mm (32") - optional
850 mm (34") - optional
2
0.65 kg/cm (9.24 psi)
2
0.56 kg/cm (7.96 psi)
2
0.50 kg/cm (7.11 psi)
2
0.47 kg/cm (6.68 psi)
3
)
Specifications for Solar 340LC-V
