OPERATION AND WARRANTY
MANUAL
The world leader in products for a healthy and comfortable
environment - bringing the Garden of Eden into your home.
EdenPureStore.com
MODEL 500-XL
IMPORTANT
SAVE THESE INSTRUCTIONS
To ensure you get the best results from your portable heater,
please read this manual first and keep it for future reference.
For additional information please visit our website at
www.edenpureservice.com or call 1-866-786-8946
Thank you for purchasing the EdenPURE
Quartz Infrared Portable Heater.
U.S. PATENT NO. 7,046,918. FOREIGN PATENTS PENDING.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500-XL and is the answer not in the manual?

Questions and answers

Summary of Contents for EdenPURE 500-XL

  • Page 1 For additional information please visit our website at www.edenpureservice.com or call 1-866-786-8946 Thank you for purchasing the EdenPURE ™ Quartz Infrared Portable Heater. U.S. PATENT NO. 7,046,918. FOREIGN PATENTS PENDING.
  • Page 2: Important Instructions

    Important Instructions READ ALL INSTRUCTIONS BEFORE USING THE HEATER 1) The grill of the heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet (0.9m) from the front of the heater and keep them away from the sides and the rear.
  • Page 3 15) Do not use it in areas where gasoline, paint, or flammable liquids are used or stored. A heater has hot or arcing or sparking parts inside. 16) Do not plug the heater into a loose fitting or broken receptacle. 17) Do not alter the heater’s design or you will void the warranty.
  • Page 4 Care • Operation • Service READ ALL INSTRUCTIONS BEFORE USING THE HEATER Operation – 7 step set-up for EdenPURE Model 500-XL ™ 1) Unpackage heater: cut open tape area, fold back flaps and gently turn entire box upside down. Lift box from styrofoam packing. Remove styrofoam, turn upright.
  • Page 5: Filter Maintenance

    Filter Maintenance WASHABLE LIFETIME FILTER SYSTEM The EdenPURE Heaters come equipped with a washable lifetime filter ™ which is easy to clean. The manufacturer recommends the filter to be cleaned once a month or as needed. To do this, follow these steps: 1) Press the tabs on the top of the filter to release the filter and pull it straight out.
  • Page 6 Heaters have an excellent safety record. They produce ™ safe, clean, economical heat by using Infrared Quartz Heating Elements. The unique EdenPURE Heaters use a process that virtually prevents ™ wasteful accumulation of heat on the ceiling. These heaters deliver ultimate comfort by keeping the heat virtually even from “head-to-toe.”...
  • Page 7: Performance Suggestions

    Performance Suggestions To assure maximum performance of the EdenPURE Heater, please note ™ the following recommendations: 1) For best result, do not locate the heater in an area with a high rate of air filtration and movement as the warm air will be exhausted.
  • Page 8: Questions And Answers

    Questions and Answers Why does the Blower Fan keep running after I have turned off the rocker switch? The Blower Fan will continue to run until the proprietary heat chambers have cooled down. After a few minutes the fan will shut off automatically. Can the heating elements be replaced? Yes.
  • Page 9 Heater Model 1000-XL was tested by an independent lab in a home environment and determined to use approximately 1.263 kilowatts per hour. Heater Model 500-XL uses approximately half the kilowatts per hour as the 1000-XL model. What is the BTU Rating for the heaters? Heater Model 500-XL is approximately 2300 BTUs.
