OWNER’S MANUAL WASHING MACHINE Please read this manual carefully before operating your washing machine and retain it for future reference. F1252RD7 www.lg.com P/No.: MFL48165936...
Contents........2 Thank you for buying a LG Fully Product feature......3 Automatic Washing Machine. Warnings Please read your owner’s manual Important safety instructions ....4 Save these instructions......4 carefully, it provides instruction on safe installation, use and maintenance. Specification ......6 Retain it for future reference.
roduct Feature Direct Drive System The advanced Brushless DC motor directly drives the drum without belt and pulley. 6 Motion Washer is able to perform various drum actions or a combination of different actions depending on the wash program selected. Combined with a controlled spin speed and the ability of the drum to rotate both left and right, the wash performance of the machine is greatly improved, giving you perfect results every time.
arnings READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION BEFORE USE For your safety, the information in this manual must be followed to minimize WARNING! the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using the washer,...
Page 5
arnings To minimize the risk of fire in a tumble dryer, the following should be observed: • Items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in a tumble dryer. Oil-affected items can ignite spontaneously, especially when exposed to heat sources Such as in a tumble dryer.
pecification Shipping Bolts Power Plug • If the supply cord is damaged, it must be replaced by the Inlet Hose manufacturer or its authorized service technician in order to Dispenser avoid a hazard. Control Panel Drum Door Lower cover cap Drain Hose Drain Pump Filter Drain Plug...
nstallation Install or store where it will not be exposed to temperatures below freezing or exposed to the weather. Properly ground washer to conform with all governing codes and ordinances. The base opening must not be obstructed by carpeting when the washing machine is installed on a carpeted floor.
nstallation Installation place requirement Level floor : Drain Hose Allowable slope under entire washer is 1° Washer Power outlet : Must be within 1.5 meters of either side of location of washer. Do not overload the outlet with more than one Laundry appliance.
nstallation Electrical connection 1. Do not use an extension cord or double adapter. 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or similarly qualified person in order to avoid a hazard. 3.
nstallation Connecting water supply hose • Water supply pressure must be between 30 kPa and 1000 kPa (0.3 ~ 10.0 kgf / cm • Do not strip or crossthread when connecting inlet hose to the valve. • If the water supply pressure is more than 1000 kPa, a decompression device should be installed.
Page 11
nstallation Type-C : Connecting one touch type hose to tap without thread 1. Unscrew the adapter ring plate and the 4 adapter retaining screws. 2. Remove the guide plate if the tap is Ring plate too large to fit the adapter. Guide plate 3.
nstallation This equipment is not designed for maritime use or for use mobile installations such as caravans, aircraft etc. Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday), especially if there is no floor drain(gully) in the immediate vicinity. When disposing of the appliance, cut off the mains cable, and destroy the Plug.
※ ※ Insert the rubber cups to reduce vibration. ※ ※ Rubber cups ( p/no. 4620ER4002A) can be purchased from the LG spare parts department. Important! • Proper placement and levelling of the washer ensures long, regular and reliable operation.
are before washing Before the first washing Select a cycle (COTTON 60°C, add a half load of detergent) allow the unit to wash without clothing. This will remove residues from the drum that may have been left during manufacturing. Caring before washing 1.
dding detergent Adding detergent and fabric softener 1. The Dispenser Drawer • Main wash only ➔ • Pre Wash + Main Wash ➔ WARNING • Keep all washing detergents away from children as there is danger of poisoning. • Too much detergent, bleach or softener may cause an overflow.
Page 16
dding detergent 3. Detergent dosage WARNING • The detergent should be used according to the • Do not let the detergent harden. instruction of the detergent manufacture. Doing so may lead to blockages, poor rinse performance or bad odor. • If too much detergent is used, too many suds can occur and this will decrease the washing ❋...
ow to use washer Washing program table • Recommended courses according to the laundry type. Proper Temp. Additional Maximum Program Fabric Type Option Load (Option) Pre Wash, Intensive, Normal, Color fast garments (shirts, night 40˚C Rating Cotton Light, Shoes Wash, dresses, pajamas...)and lightly soiled (Cold, 60˚C) No Wash,...
ow to use washer Control panel 2. Manual Selecting 1. Cotton automatically selected upon power on. • Press the Power( ) button to turn the washer on. • Press the Power( ) button to start. • Select the desired cycle with the program •...
ow to use washer (10) (11) (12) (1)Button: Power (4)Button: Wash (7)Button: Spin (10)Button: Time Delay (2)Dial: Program (5)Child lock (8)Button: Temperature (11)Button: Tub Clean (3)Button: Start/Pause (6)Button: Rinse (9)Button: Add Load (12)Button: Dry Power Program 1. Power • Press the Power( ) button to turn power on and off.
ow to use washer Start/Pause Wash 1. Start 1. Pre Wash • This Start/Pause button is used to start • Use this option for loads that need wash cycle or pause the wash cycle. pretreatment. This adds 16 minutes of pre washing before draining.
ow to use washer Child Lock Rinse Use this option to prevent unwanted use of • By pressing the Rinse button, the Rinse the washer or to keep cycle settings from type can be selected. being changed while the washer is operating. •...
ow to use washer Spin Water Temperature • By pressing the Spin button, the spin speed can be chosen. • By pressing the Temp. button, the water 1. Spin selection temperature can be selected. • Water temperature can be selected as •...
ow to use washer Add Load Time Delay Use this function to add loads or remove the Preparing washing before starting “Time Delay” foreign material. - Turn on the water tap. - Load laundry and close the door. - Place the detergent and fabric softener in •...
ow to use washer Tub Clean Use this function to sanitize drum to remove NOTE any bacteria and keep the drum clean. Auto Tub clean notification function( • When you turn on the power by pressing the Power button, and the following sign is shown on the panel, it means that you need to clean the drum.
ow to use washer NOTE The maximum drying capacity for this 1. Drying Automatic guide model is 8 kg. When loading, please use the maximum drying capacity • Use your Automatic Cycles to dry most loads. indicator behind the door as shown Electronic sensors measures the temperature below.
Page 26
ow to use washer 2. Manual Drying time guide Rubber and Plastics - Do not dry any items made from or • By pressing the Dry button, the drying time containing rubber or plastics, such as: can be selected. a) aprons, bibs, chair covers •...
ow to use washer Display 3. Completion of washing • When washing cycle is completed, “ ” is displayed on the “Multi display”. 1. Special function display 4. Time left • When Child lock is selected, the “ ” is •...
aintenance ❋ Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock to avoid electrical shock hazards. ❋ When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside. The water inlet filter - "...
aintenance The drain pump filter ❋ The drain filter collects threads and small objects left in the laundry. Check regularly that the filter is clean to ensure smooth running of your machine. CAUTION First drain using the drain hose and then open the pump filter to remove whatever any threads or objects.
aintenance Dispenser drawer ❋ After a while detergents and fabric softeners leave a deposit in the drawer. • It should be cleaned from time to time with a jet of running water. • If necessary it can be removed completely from the machine by pressing the catch downward and by pulling it out.
aintenance The water circulation nozzle & steam nozzle • Clean the water circulation nozzle, if clogged. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent.
roubleshooting guide ❋ This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not function at all, check the following points before you contact your service provider. Diagnosing Problem Symptom Possible Cause...
Page 33
roubleshooting guide Symptom Possible Cause Solution Water in the washer • Drain hose is kinked or clogged. Clean and straighten the drain hose. does not drain or drains slowly. • The drain filter is clogged. Clean the drain filter. Washer does not start •...
Page 34
roubleshooting guide Symptom Possible Cause Solution • It takes time to balance the Wash cycle time The washing time may vary by the laundry before the spin cycle delayed amount of laundry, water pressure, water temperature and other usage conditions. If the imbalance is detected or if the suds removing program works, the wash time shall be increased.
roubleshooting guide Error Messages Symptom Possible Cause Solution Check another tap in the house. • Water supply is not adequate in area Fully open tap. • Water supply taps are not completely open. Straighten hose(s). • Water inlet hose(s) are kinked. Check the filter of the inlet hose(s).
erms of Warranty What Is Not Covered: • Service trips to your home to teach you how to use the product. • If the product is connected to any voltage other than that shown on the rating plate. • If the fault is caused by accident, neglect, misuse or Act of God. •...
