Page 1: Washing Machine
WASHING MACHINE SERVICE MANUAL CAUTION READ THIS MANUAL CAREFULLY TO DIAGNOSE TROUBLES CORRECTLY BEFORE OFFERING SERVICE. MODEL : F1258FDS6... - Page 2 June 2009 PRINTED IN KOREA P/No.:MFL41950130...
-
Page 3: Table Of Contents
CONTENTS 1. SPECIFICATION..........................3 2. FEATURES & TECHNICAL EXPLANATION ................4 3. PARTS IDENTIFICATION ......................7 4. INSTALLATION ..........................8 5. WIRING DIAGRAM / PROGRAM CHART ...................11 6. OPERATION ..........................12 7. TROUBLE SHOOTING........................14 7-1.BEFORE SVC CHECKING ....................14 7-2.QC TEST MODE........................14 7-3.HOW TO KNOW THE WATER LEVEL FREQUENCY............14 7-4.ERROR DISPLAY ........................15 8. -
Page 4: Specification
1. SPECIFICATION ITEM F1258FDS6 POWER SUPPLY 220V a.c 60Hz PRODUCT WEIGHT 91kg WASHING 200W SPIN 300W ELECTRICITY FAN MOTOR CONSUMPTION DRAIN MOTOR WASH HEATER 1000W DRY HEATER 1200W WASH 46rpm REVOLUTION SPEED Gentle/400/800/1000/1200 SPIN OPERATION WATER PRESSURE 0.3-10kgf/cm (30-1000kPa) CONTROL TYPE... -
Page 5: Features & Technical Explanation
2. FEATURES & TECHNICAL EXPLANATION 2-1.FEATURES ■ Ultra Capacity 추가선택, 예약, The Larger drum enables not just higher head drop and stronger centrifugal force, but also less tangling and wrinkling of the laundry. Heavier loads, such as king size comforters, blankets, and curtains, can be washed. ■... -
Page 6: Water Level Control
2-2.DETERMINE WASHING TIME BY FUZZY LOGIC To get the best washing performance optimal time is determined by sensing of water temperature, selected washing temperature and laundry amount. water temperature washing time the best selected FUZZY washing washing rinsing time temperature LOGIC performance spin rhythm, time... -
Page 7: Child Lock
2-5. THE DOOR CAN NOT BE OPENED ● While program is operating ● When a power failed and power plug is taken out in operation ● While Door Lock lights turn on. ● While the motor is in the process of inertial rotating, through the operation is paused. 2-6. -
Page 8: Parts Identification
3. PARTS IDENTIFICATION & Steam Nozzle Drum Light Door Seal ■ ACCESSORIES Spanner... -
Page 9: Installation
4. INSTALLATION 1⃞ Before servicing ask troubles of customers 2⃞ Check the adjustment(power supply is 110V a.c, remove the transit bolts..) 3⃞ Check the troubles referring to the trouble shooting. 4⃞ Decide service steps referring to disassembly instructions. 5⃞ And then, service and repair. 6⃞... - Page 10 ■ HOW TO CONNECT INLET HOSE Check that the rubber packing is inside of the valve connector. Connect the inlet hose firmly to prevent leak. ■ CONNECT DRAIN HOSE · Make sure that the hose is not twisted. · Avoid submerging the end of the hose. ※...
-
Page 11: Test Operation
TEST OPERATION Preparation for Press the POWER button. Press the Start/Pause washing. button. Connect the power plug to the outlet. In case of Coloreds program. Connect the inlet hose. Check the water heating. Check automatic reverse Check the water supply. turn. -
Page 12: Wiring Diagram / Program Chart
6. WIRING DIAGRAM PROGRAM CHART Wash Rinse Spin Extra & Main Stain(4~6) Wash **Approx Working ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ Time (Minute) 90 8"30 60 300 120 (12)" (20)" (42)" 60 300 120 180 60 300 120 180 60 300 120 180 60 300 120 180 60 480 180 20 Cotton Synthetic Delicate... -
Page 13: Operation
5. OPERATION TURBO STEAM POWER BUTTON • This option features upgraded • Use this button to turn the power washing performance with low energy On/Off. and water consumption. CYCLE SELECTOR KNOB • Rotate the Cycle selector knob to select the cycle designed for different types of fabric and soil levels. -
Page 14: Spin
EST. TIME REMAINING • This display shows: a) the estimated time remaining in the STATUS INDICATOR cycle when operating. b) an error code when an error has been • These lights show which portion detected. of the cycle the washer is operating. -
Page 15: Trouble Shooting
7. TROUBLE SHOOTING 7-1.BEFORE SVC CHECKING ■ Be careful of electric shock or disconnecting the parts while trouble shooting. ■ Voltage of each terminal is 220-240V~ and DC while applying an electric current. 7-2.QC TEST MODE. ① ① Pressing Rinse, and Temp. button simultaneously. ②... -
Page 16: 7-4.Error Display
7-5.ERROR DISPLAY. If you press the Start/Pause button in error condition, any error except ‘ ’ will disappear and the machine will change into pause status. In case of d e , d e , d e , if the error is not resolved within 20 sec., and in case of other errors, if the error is not resolved within 4 min., power will be turned off automatically and the error only will be blinked. - Page 17 ERROR SYMPTOM CAUSE • The connector in the LEAD WIRE ASSEMBLY is not connected to MOTOR the connnector of STATOR ASSEMBLY ERROR Reconnect or repair the connector • The hall sensor is out of order/defective. Replace the STATOR ASSEMBLY • The Dry Heater is out of order Replace the Dry Heater HEATOR •...
-
Page 18: Error Diagnosis And Check List
8. ERROR DIAGNOSIS AND CHECK LIST 8-1.DIAGNOSIS AND ANSWER FOR ABNORMAL OPERATION SYMPTOM GUIDE FOR SERVICE CALL NO POWER Is the power plug connected firmly to 110 V a.c Outlet? Power failure? or Breaker opened? Visit to check Water inlet trouble No Inlet Is "... - Page 19 SYMPTOM GUIDE FOR SERVICE CALL • Door does not open Started with door opened? • Error displayed on the program Close the door Visit to check Check if the door switch is O K. • DRAIN TROUBLE Is " " displayed? Is the debris filter clogged with foreign Clean up material such as pin, coin and etc.?
- Page 20 SYMPTOM GUIDE FOR SERVICE CALL ° Suds overflow from the Is low-sudsing detergent for the drum appliance. washing machine used? (In this condition, wash and spin do not operate LOW-SUDSING normally) Is the proper amount of detergent used as recommended? Recommend to reduce the using amount of detergent.
-
Page 21: Fault Diagnosis And Trouble Shooting
8-2.FAULT DIAGNOSIS AND TROUBLE SHOOTING CAUTION 1. Be careful of electric shock or disconnecting the parts while trouble shooting. 2. First of all, check the connection of each part terminal with wiring diagram. 3. If you replace the MAIN PWB ASSEMBLY, Put in the connectors correctly. NO POWER When measuring the voltage of the outlet, Check the fuse? -
Page 22: No Water Supply
NO WATER SUPPLY Is water supply shut-off? Is the tap opened? Open the tap. Check the AIR CHAMBER When you press both Rinse button and Temp. and the tube clogged button simultaneously, is the water level frequency below 240? with impurity. Is the inlet valve filter clogged with impurity? Clean the filter. - Page 23 S O F T E N E R D O E S N O T F L O W I N Refer to Is water supplied? ^NO WATER SUPPLY_ Check the wiring on the Are receptacles correctly connected to the terminals dispenser.
-
Page 24: Heating Without Water
HEATING WITHOUT WATER When pressing RINSE and TEMP. at the same time after draining, is the water level frequency Replace the 255? S.PRESSURE SWITCH When pressing RINSE and TEMP. buttons at the ASSEMBLY same time while washing, is the water level frequency between 230 - 243 ? ∑... - Page 25 ∑ ò ∑ Ω ò Ω √ ∑ ù ∑ 110 V a.c? Ω √ ù √ ù √ ù 110 V a.c YELLOW-BLACK BLACK HEATING CONTINUOUSLY ABOVE THE SETTING WATER TEMPERATURE When checking THERMISTOR on the tub is the Push the THERMISTOR THERMISTOR loosened above 2mm from tightly to the rubber.
- Page 26 S P I N T R O U B L E Check the S.PRESSURE SWITCH Check on the spinning, is the frequency of the ASSEMBLY or HOSE (Pressure). water level 248 or more. The frequency can be If the problem is on the checked by pressing the Rinse and Temp.
- Page 27 [dHE] ERROR DISPLAY Replace the thermistor. (6322FR2046J) CHECK FOR DRY HEATER TROUBLE CHECK FOR DRY FAN MOTOR TROUBLE Disassemble the cabinet cover and condensing bellows. Clean the bellows Is there any foreign object in condensing bellows. Disassemble the dry fan assy and dry duct upper, and clean foreign object in duct and fan.
- Page 28 Are receptacles correctly connected to the terminals of the DRY DUCT Reconnect the ASSEMBLY? receptacle PWB HARNESS 110 V a.c Steam...
- Page 29 ∑ ∑ ò Ω (1)-Yellow, 3pin ò Ω √ ∑ ù ∑ Ω √ ù √ ù √ ù ∑ ∑ ò Ω ò Ω √ ∑ ù ∑ 20~30 Ω √ ù √ ù Black √ ù Yellow...
- Page 30 (5221ER1002C) 110 V a.c Steam...
-
Page 31: Disassembly Instructions
9. DISASSEMBLY INSTRUCTIONS Be sure to unplug the machine out of the outlet before disassembling and repairing the parts. CONTROL PANEL ASSEMBLY TOP PLATE ASSEMBLY ① ① Unscrew 2 screws on the back of the top plate. ② ② Pull the top plate backward and upward as shown. ③... - Page 32 ① Unscrew 1 screw on the pressure switch. ② Open the protect cover. Pressue switch PROTECT CO ① Disconnect connectors from the wiring. ② Push the hook of between BASE,CABINET and PWB ASSEMBLY below as shown. ③ Pull the PWB assembly (Main) to arrow direction.
- Page 33 ① Disassemble the top plate assembly. ② Pull out the drawer. ③ Push out the DISPENSER ASSEMBLY after unscrew 2 screws. ① Unscrew the nut at the lower part of the dispenser. ① Disassemble the 4 or 5 connectors from the valves.
- Page 34 CABINET COVER ① ① Unscrew the 5 screws from upper of the canbinet cover. ② ② Unscrew the screw from filter cover. ③ ③ Put a flat ( - ) screwdriver or putty knife into the both sides of the filter cover, and pull it out. ④...
- Page 35 ⑩ ⑩ Open the door. ⑪ ⑪ Disassemble the clamp assembly. ⑫ ⑫ Tilt the cabinet cover. ⑬ ⑬ Disconnect the door switch connector. ※ ※ NOTE: When assembling the CABINET COVER, connect the connector. ⑭ ⑭ Lift and separate the cabinet cover.
-
Page 36: Door Lock Switch Assembly
DOOR ① ① Open the door. ② ② Remove the two screws from the Hinge. ※ When removing the Door Assembly, it is necessary to hold the Bracket that is inner of the cabinet cover. ※ ※ Be careful! The door is heavy. DOOR LOCK SWITCH ASSEMBLY ①... - Page 37 PUMP ① ① Disassemble the cabinet cover. ② ② Separate the pump hose, the bellows and the circulation hose assembly from the pump assembly. ③ ③ P P r r e e s s s s t t h h e e h h o o o o k k . . ④...
- Page 38 WHEN FOREIGN OBJECT IS STUCK BETWEEN DRUM AND TUB ① ① Disassemble the cabinet cover. ② ② Separate the heater from the tub. ③ ③ Remove any foreign objects (wire, coin, etc.) by inserting a long bar in the opening. MOTOR/DAMPER ①...
- Page 39 Checking the TSG (TURBO STEAM GENERATOR) ① ① To check out the fault diagnosis of TSG, in case of removing the water inside, you can pull out the plug and let the water drain away. ② ② Be cautious in case of the TSG is hot temperature.
- Page 40 ③ ③ Taking out the screws of Body Frame (4EA) ④ ④ Separate the hoses from the TSG. ⑤ ⑤ Remove the Body Frame and then, separate the TSG from the washer...
-
Page 41: Exploded View And Parts List
10. EXPLODED VIEW AND PART LIST 10-1. CABINET & CONTROL PANEL ASSEMBLY M400 M410 F215 A485 F210 F110 A455 A450 A106 A104 A105 A102 A111 A110 A410 A103 A150 A154 A152 A101 A141 A390 A151 A153 A100 A131 A130 A430 A140 A133 A440... -
Page 42: The Exploded View Of Drum And Tub Assembly
10-2. DRUM & TUB ASSEMBLY K143 K123 K351 K350 K360 F140 K610 K411 K410 K611 K115 F466 K110 K141 K111 K140 F315 F310 K572 K571 F465 F463 K513 K570 K122 F464 K125 K511 K130 K320 K530 K121 K510 K512 K560 K135 K131 F328... -
Page 43: The Exploded View Of Control Panel And Dispenser Assembly
10-3. CONTROL PANEL AND DISPENSER ASSEMBLY F322 F321 F330 F462 F300 F340 F329 F170 F160 F226 F327 F225 F220 F430 F441 F120 HOT (RED) A275 COLD (BLUE) A276 F130... -
Page 44: The Exploded View Of Dryer
10-4. THE EXPLODED VIEW OF DRYER M111 M110 M120 M100 M121 M210 M230 M215 K311 M240 M130 M101 K311 M312 M220 M310 M311 M260 M235...
