USER MANUAL
ENGLISH
Thank you very much for choosing the
iiyama LCD monitor.
We recommend that you take a few
minutes to read carefully through
this brief but comprehensive manual
before installing and switching on the
monitor. Please keep this manual in a
safe place for your future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite B2280HS and is the answer not in the manual?

Questions and answers

Related Manuals for Iiyama ProLite B2280HS

Summary of Contents for Iiyama ProLite B2280HS

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a...
  • Page 3 For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing reflections from surrounding light and bright surfaces. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com...
  • Page 4 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......5 WALL MOUNTING ................5 FITTING AND REMOVAL OF BASE : ProLite B2280HS ....6 FITTING AND REMOVAL OF BASE : ProLite E2280HS / ProLite E2282HS ..........7 CONTROLS AND CONNECTORS : ProLite B2280HS ....8 CONTROLS AND CONNECTORS : ProLite E2280HS / ProLite E2282HS ..........9...

  • Page 5: Table Of Contents

    DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage.

  • Page 6: For Your Safety

    CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
  • Page 7  If you have to return your unit for service and the original packaging has been discarded, NOTE please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING  If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center.

  • Page 8: Special Notes On Lcd Monitors

     Supports Resolutions up to 1920 × 1080  High Contrast 1000:1 (Typical), Adv. Contrast Function Available / Brightness 250cd/m (Typical) / Quick Response Time 5ms (Typical) : ProLite B2280HS, ProLite E2280HS  High Contrast 1000:1 (Typical), Adv. Contrast Function Available / Brightness...

  • Page 9: Before You Operate The Monitor

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.  Power Cable*  DVI-D Cable...

  • Page 10: Checking The Contents Of The Package

    FITTING AND REMOVAL OF BASE : ProLite B2280HS CAUTION  Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped.  Do not give a strong impact to the monitor. It may cause damage.

  • Page 11: Fitting And Removal Of Base : Prolite B2280Hs

    FITTING AND REMOVAL OF BASE : ProLite E2280HS / ProLite E2282HS CAUTION  Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped.  Do not give a strong impact to the monitor. It may cause damage.  Unplug the monitor before removal or installation to avoid electric shock or damage.

  • Page 12: Fitting And Removal Of Base : Prolite E2280Hs / Prolite E2282Hs

    CONTROLS AND CONNECTORS : ProLite B2280HS <Front> <Back> Power Switch ( ) Menu Button (MENU) + / Volume / Blue Light Reducer Button ( + / Power Indicator NOTE Blue: Normal operation Orange: Power Management - / ECO Button ( - / Auto Button (AUTO) Speakers Audio Connector ( VGA Connector (D-SUB) DVI-D Connector (DVI) HDMI Connector (HDMI) AC Connector( : Alternating current) (AC IN) Keyhole for Security Lock...

  • Page 13: Controls And Connectors : Prolite B2280Hs

    CONTROLS AND CONNECTORS : ProLite E2280HS / ProLite E2282HS <Front> <Back> Power Switch ( ) Menu Button (MENU) + / Volume Button / Blue Light Reducer ( + / Power Indicator NOTE Blue: Normal operation Orange: Power Management - / ECO Button ( - / Auto Button (AUTO) Speakers Audio Connector ( VGA Connector (D-SUB) DVI-D Connector (DVI) HDMI Connector (HDMI) Installation hole of Cable Holder AC Connector( : Alternating current) (AC IN) Keyhole for Security Lock...

  • Page 14: Controls And Connectors : Prolite E2280Hs / Prolite E2282Hs

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office.

  • Page 15: Connecting Your Monitor : Prolite B2280Hs

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office.

  • Page 16: Connecting Your Monitor : Prolite E2280Hs / Prolite E2282Hs

    COMPUTER SETTING  Signal Timing Change to the desired signal timing listed on page 31: COMPLIANT TIMING. ADJUSTING THE VIEWING ANGLE : ProLite E2280HS / ProLite E2282HS  For optimal viewing it is recommended to look at the full face of the monitor. ...

  • Page 17: Computer Setting

    ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite B2280HS  For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference.

  • Page 18: Adjusting The Height And The Viewing Angle : Prolite B2280Hs

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 31. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 21 for SCREEN ADJUSTMENTS.

  • Page 19: Operating The Monitor

    ADJUSTMENT MENU CONTENTS Picture Adjust ProLite B2280HS PICTURE ADJUST BRIGHTNESS GEOMETRY COLOR SETTINGS CONTRAST MODE1 EXTRA STANDARD I-STYLE COLOR ADV. CONTRAST Adjustment Item Problem / Option Button to Press Too dark Brightness * Too bright Too dull Contrast Too intense...

  • Page 20: Adjustment Menu Contents

    Geometry ProLite B2280HS PICTURE ADJUST IMAGE SETTINGS GEOMETRY PIXEL CLOCK COLOR SETTINGS PHASE HORIZONTAL POSITION EXTRA VERTICAL POSITION ASPECT FULL Adjustment Item Problem / Option Button to Press Too narrow Pixel Clock* Too wide Phase* To correct flickering text or lines Too left Horizontal Position*...
  • Page 21 Color Settings* ProLite B2280HS PICTURE ADJUST COLOR SETTINGS GEOMETRY MODE1 GAMMA COLOR SETTINGS COLOR TEMP USER USER PRESET EXTRA GREEN BLUE Adjustment Item Problem / Option Button to Press Mode1 Normal Gamma Mode2 High contrast Mode3 Dark Too weak Green...
  • Page 22 ProLite B2280HS PICTURE ADJUST ON SCREEN DISPLAY SETTINGS GEOMETRY OSD HORIZONTAL POSITION COLOR SETTINGS OSD VERTICAL POSITION OSD TIME EXTRA LANGUAGE ENGLISH Adjustment Item Problem / Option Button to Press OSD is too left OSD Horizontal Position OSD is too right...
  • Page 23 Extra ProLite B2280HS PICTURE ADJUST EXTRA GEOMETRY RESET COLOR SETTINGS HDMI SIGNAL SELECT AUDIO INPUT HDMI EXTRA OVERDRIVE INFORMATION Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Reset Return to Menu. Auto Select the signal input automatically.
  • Page 24 Direct You can skip the Menu items and directly display an option setting screen or an adjustment scale by using the following button operations.  Volume: Press the + Button when the Menu is not displayed. Adjustment Item Problem / Option Button to Press Too soft Volume...

  • Page 25: Screen Adjustments

    If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Image Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). Adjust the image by following the procedure below to get the desired picture.

  • Page 26: Screen Adjustments

    Pressing and holding of the AUTO Button for about 3-4 seconds. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Image Adjust. Adjust the V.Position so that the top and bottom of the picture frame will fit to the display area.
  • Page 27 Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. NOTE  In case the strong flicker or blurs remain on a part of the screen, repeat steps because the Clock may not be adjusted correctly. If the flicker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again.
  • Page 28 POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below.

  • Page 29: Power Management Feature

    MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
  • Page 30 A strange noise is  The Audio Cable is properly connected. heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. 26 TROUBLE SHOOTING / RECYCLING INFORMATION...

  • Page 31: Recycling Information

    APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS : ProLite B2280HS-B1 / ProLite B2280HS-W1 Size Category 21.5" Panel technology Size Diagonal: 21.5" (54.7cm) Pixel pitch 0.2482mm H × 0.2482mm V Brightness 250cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 80 ° each (Typical)

  • Page 32: Appendix

    SPECIFICATIONS : ProLite E2280HS-B1 / ProLite E2280HS-W1 Size Category 21.5" Panel technology Size Diagonal: 21.5" (54.7cm) Pixel pitch 0.2482mm H × 0.2482mm V Brightness 250cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 80 ° each (Typical) Response time 5ms (Black, White, Black, Typical) Display Colors Approx.16.7M...

  • Page 33: Specifications : Prolite E2280Hs-B1 / Prolite E2280Hs-W1

    SPECIFICATIONS : ProLite E2282HS Size Category 21.5" Panel technology Size Diagonal: 21.5" (54.7cm) Pixel pitch 0.2482mm H × 0.2482mm V Brightness 250cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left: 85 ° each Up / Down: 80 ° each (Typical) Response time 5ms (Black, White, Black, Typical), 2ms (Gray to Gray) Display Colors Approx.16.7M...
  • Page 34 DIMENSIONS : ProLite B2280HS 509.5mm/20.1” 48.5mm/1.9” 478.0mm/18.8” ( ) : Maximum adjustment range DIMENSIONS : ProLite E2280HS 509.5mm/20.1” 48.5mm/1.9” 478.0mm/18.8” 219.5mm/8.6” DIMENSIONS : ProLite E2282HS 509.5mm/20.1” 48.5mm/1.9” 478.0mm/18.8” 229.5mm/9.0” 30 APPENDIX...

  • Page 35: Dimensions : Prolite B2280Hs

    COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640 × 480 37.500kHz 75.000Hz 31.500MHz 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 800 × 600 37.879kHz 60.317Hz 40.000MHz 46.875kHz 75.000Hz 49.500MHz 48.363kHz 60.004Hz 65.000MHz 1024 × 768 56.476kHz 70.069Hz 75.000MHz...
