- Page 1 A 205-PENSIERO min. Technical Service min. End User VIDEO link Assembly Instructions...
- Page 2 (in c h ) (m m ) T r a c k T it le P ie c e T h i c k n e s s L e n g t h W i d t h P ie c e T h i c k H e i g h t M o s t...
- Page 3 Accessories List MNX 02 MNG - 01 TAP - 01 KVL 01 32 / piece 32 / piece 32 / piece 36 / piece IM - 01 (6x30) mm CT - 02 ( 6x30 ) mm VKP - 01 (22) mm CT - 01 ( 6x40 ) mm 8 / piece 2/ piece...
- Page 4 KVL-01 x 4 STEP 1 MNX-02 x 4 MNX - 02 KVL 01 KVL-01 x 8 MNX-02 x 4 KVL-01 x 8 KVL-01 x 4 KVL-01 x 8 VIDEO KVL-01 x 4 link Page 3...
- Page 5 STEP 2 D-L/D-R MNX - 02 MNX-02 x 12 STEP 3 MNG - 01 210° MNG - 01 x4 VIDEO link Page 4...
- Page 6 STEP 4 210° MNG - 01 MNG - 01 x4 STEP 5 MNG - 01 210° MNG - 01 x12 VIDEO link Page 5...
- Page 7 H 01 STEP 6 MNG - 01 STEP 7 MNG - 01 MNG - 01 x 12 210° VIDEO link Page 6...
- Page 8 STEP 8 ATTENTION! Please be sure that ‘’part A’’ s fully stra ght wh le fix ng back panels. VD - 02 x 8 VIDEO AVT - 01x 8 link Page 7...
- Page 9 STEP 9 OT - 054 CT - 01 AL - 01 CAUTION DO NOT UNLOCK BEFORE INSTALL MKZ - 02 (2xL/2xR) IM - 01 VIDEO AL - 02 link Page 8...
- Page 10 ATTENTION!!! Must be secured to the wall made of brick, concrete or similarly strong material. STEP 10 Mounting to wooden or metal studs is also acceptable. Do not mount directly to sheetrock or paper-mache type walls not supported by studs. DD - 01 Ø...
- Page 11 WALLS MADE OF DRYWALL WITH WOODEN OR METAL STUDS STEP 10-1 Ø 10 mm / 0,254 inc FİRST LOCATE THE STUDS BY USİNG ''STUD FİNDER'' İN THE WALL AND DRİLL İT ACCORDİNG TO THE HEİGHT MEASURMENTS GİVEN ON THE SİDE. UPPER HOLES SHOULD BE DRİLLED FOR ATTACHİNG BED AT NEXT STEP .
- Page 12 STEP 11 45-50° 45-50° LET THE STOPPER LOCK MOVE DOWN !!! VIDEO link Page 11...
- Page 13 STEP 12 CAUTION ! LADDER MUST BE ATTACHED TO THE UPPER BUNK WHILE IT IS IN USE FOR MRD 01 ADDITIONAL SUPPORT AND SAFETY. STEP 15 SC-61 VIDEO link Page 12...
- Page 14 STEP 13 KMT - 01 VTB - 02 X 4 KMT - 01 VKP - 01 X 2 KP - 01 VIDEO link Page 13...
- Page 15 STEP 14 CT - 02 OT - 06 AL - 01 AKR 01 X 2 AL - 01 VIDEO link Page 14...
- Page 16 STEP 15 TTC 01 X 4 KKS - 01 X 4 TTC 01 X 4 VIDEO link Page 15...
- Page 17 STEP 16 KBP - 01 KOR 02 KBP - 01 YSB - 02 X 2 CAUTION ! MAKE SURE THAT HEADBOARDS AND GUARDRAILS ARE FOLDED BEFORE CLOSING THE BED KBP - 01 KLF 02 (fabric cover) KOR 02 VIDEO link Page 16...
- Page 18 With seasonal humidity change please inspect the interior and exterior of the furniture for deformation and/or discoloration. Before any un-mounting or disassembly please contact Multimo Beds for technical support and instructions Failure to properly detach may result in personal injury and damage to property.
- Page 19 Page 18...
- Page 20 www.mult mobeds.com...
