- Page 2 Corner Fitting: Base Unit: Quantity-1 Quantity-3 24” Pipe: Quantity-1 Tires (with 5/8 bolts and lock nuts): 44.5” Tapered Pipe: Quantity-4 Quantity-2 41.5” Pipe: Quantity-6 Trigger Unit: Quantity-1 Target Cross Brace: Quantity-1 Bucket Assembly: Quantity-1 Target Arm: Quantity-1 Filler Tube Hook: Collar: Quantity-1 Quantity-1...
- Page 3 Filler Tube Clips: Filler Tube: Quantity-4 Quantity-1 Guar Gum: Quantity-8 (8 ounce bags) Target: Quantity-1 Green/Yellow Food Dye: Sponge Balls: Vinyl Canvas: Quantity-8 Quantity-12 Quantity-1 (16 ounce bottles) Drum Pump: Quantity-1 Drum: Quantity-1...
- Page 4 Attach tires to the base unit, with the 5/8” bolt and lock nut. (The nut goes on the inside side of the tire.) Insert a 44.5” tapered pipe in each cor- ner fitting of the base unit. (The tapered end goes up.)
- Page 5 Put the target arm cross brace onto two of the tapered pipes. NOTE: The arm pivot IMPORTANT goes on the inside and is on the opposite side from the wheels. Insert a 41.5” pipe onto each tapered pipe .
- Page 6 Insert the remaining 41.5” pipes in- to the corner fitting and tighten. Slide the bucket assembly onto the trigger unit. Make sure that it is posi- tioned so that the roller engages with the trigger hook. Place the remaining two corner fit- tings onto either end of the 24”...
- Page 7 Insert filler tube hook and tighten. Attach filler tube. The drum can be at- tached to the base Use the clips to route using the ratchet the filler tube along strap. the frame to where ever you are going to Insert the pump in- place the drum.
- Page 8 Create a fine mist with a garden hose sprayer. VERY SLOWLY sprinkle about half of the guar gum into the mist. Once the drum is half filled (and the guar gum half used), stop and stir thor- oughly. NOTE: A cordless drill with a mixing attach- ment works perfectly for this.
- Page 9 Fill the drum with water, then add 6-8 caps full of green food dye and mix. NOTE: The food dye is undiluted and will stain. NOTE: A cordless drill with a mixing attachment works perfectly for this.
- Page 10 Do not allow anyone to climb on or lean against the Slime Machine. ♦ Do not allow anyone to hit the target with their hand. ♦ Take down the Slime Machine if there is high wind or chance of lightening.
