- Page 1 SmartLock ® INSTALLATION MANUAL April 2009...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ........................3 Diodes ..........................3 Power Supply Notice ...................... 3 Terminal Strips and Cable ....................4 SPECIFICATIONS ........................5 SMARTLOCK CONTROLLER LAYOUT ................... 7 LED Indicators ........................ 8 Mounting ........................8 RS-485 COMMUNICATIONS WIRING ..................9 CLAUSB Communications Device .................10 CANLAN Network Communications Device ..............11 SMARTLOCK CONNECT WIRING ..................12... -
Page 3: Introduction
PC. Up to two control panels are easily mounted in a SmartLock enclosure along with a Cansec 12 VDC power supply and a back-up battery. -
Page 4: Terminal Strips And Cable
Splice multiple cables to a single cable, and then run the single cable to the terminal strip on the control panel. Complimentary Screwdriver A standard Cansec screwdriver is included with every control panel for use with terminal strips. ® SmartLock... -
Page 5: Specifications
Specifications Power Requirements ® SmartLock Controller: ..........12 VDC, 100 mA NOTE: When determining power supply current requirements, you must consider lock and reader current draw if using the same supply for these devices. NOTE: In some jurisdictions, the use of a UL approved power supply and connection to the fire alarm system for emergency release may be required. - Page 6 Reader Cable Wiegand Readers: ....6 conductor (twisted pair not required) ................22 AWG, overall shield ............... 152 m (500 ft) max total length ® iButton Readers: ............... 6 conductors ............22 AWG, shielded or unshielded ..............15 m (50 ft) max total length Dimensions &...
-
Page 7: Smartlock Controller Layout
SmartLock Controller Layout EXIT READER (WIEGAND) +12 VDC READER VOLTAGE INPUT SELECTOR ADDRESS ENTRY READER SWITCH DEFAULT (WIEGAND) (DO NOT CHANGE) WIEGAND DATA LED ENTRY READER PROGRAMMING MODULE (iBUTTON) RELAY LEDS DOOR CONTACT EXIT BUTTON COMMS DOOR OPERATOR (INPUTS) RS-485 COMMUNICATIONS LOCK CONTROL DOOR OPERATOR... -
Page 8: Led Indicators
3. The communication LED will flicker GREEN while communicating with SmartLock software. MOUNTING Up to two SmartLock controllers can be mounted in the SmartLock enclosure along with a Cansec 12 VDC power supply and a backup battery. ® SmartLock Page 8 of 29 Installation Manual April 2009 •... -
Page 9: Rs-485 Communications Wiring
RS-485 Communications Wiring Up to 30 SmartLock access control panels may be connected on an RS-485 bus. An additional 30 control panels may be connected via a Cansec communications device. NOTE: For CLA50 communications device wiring (for use with SmartLock Connect dial-up configurations) please see Appendix I. -
Page 10: Clausb Communications Device
CLAUSB COMMUNICATIONS DEVICE SMARTLOCK CONTROLLER +12 VDC NOTES: - Each Smartlock controller must ADDRESS “1” SHOWN (Dipswitch 1 is OFF) have a unique address - For communication wiring, use 22 AWG, twisted pair, stranded, SMARTLOCK shielded cable, 2000 ft ( 609 m ) MAX CONTROLLER... -
Page 11: Canlan Network Communications Device
CANLAN NETWORK COMMUNICATIONS DEVICE SMARTLOCK CONTROLLER +12 VDC NOTES: - Each Smartlock controller must ADDRESS “1” SHOWN (Dipswitch 1 is OFF) have a unique address - For communication wiring, use 22 AWG, twisted pair, stranded, SMARTLOCK shielded cable, 2000ft ( 609 m ) MAX CONTROLLER... -
Page 12: Smartlock Connect Wiring
SmartLock Connect Wiring MODEM CONFIGURATION (DIAL-UP) CLA50 RS-485 TO CONTROLLERS CANSEC MODEMS CUSTOM MODEM CABLE PART # CA-SOMOCAB REMOTE END (DIAL-UP) 12 VDC PLUG IN TRANSFORMER SMARTLOCK 2.1 mm PLUG, CENTRE POSITIVE CONTROLLER +12 VDC (SUPPLIED) CLA50 ADDRESS “1” SHOWN... -
Page 13: Programming Module (Stand-Alone)
PROGRAMMING MODULE (STAND-ALONE) DIP SWITCH POSITIONS THROUGH MUST BE FOR STAND-ALONE OPERATION CABLE: 22 AWG, 6 CONDUCTOR, STRANDED, 50 ft (15m) MAX LENGTH +12 VDC BEEP RED LED GREEN LED NOTES: The stand-alone programming module must be installed within 50 feet of the SmartLock controller in a location accessible for programming using the portable programming key. -
Page 14: Reader Wiring
Connecting a 5 V reader to a 12 V power supply will damage the reader. ® NOTE: The SmartLock controller supports Cansec’s 37-bit format as well as standard 26-bit format. ® SmartLock... -
Page 15: Ibutton ® Reader
iBUTTON READER ® NOTE: Exit reader not supported with SmartLock iButton readers. NOTE: If using the SmartLock Connect Programming Module with iButton readers, connect the programming module in parallel with the iButton reader. ® SmartLock Page 15 of 29 Installation Manual April 2009 •... -
Page 16: Lock Output Relay Wiring
Lock Output Relay Wiring DC ELECTRIC STRIKES Option 2 Option 1 ≤ 250mA > 250mA NOTE: Use 1N400x series diode as shown, to prevent “back EMF” from damaging the controller. ® SmartLock Page 16 of 29 Installation Manual April 2009 • Rev. 1.7... -
Page 17: Dc Maglocks
DC MAGLOCKS Option 2 Option 1 ≤ 250mA > 250mA NOTE: Use 1N400x series diode as shown to prevent “back EMF” from damaging the controller if the maglock is not equipped with sufficient spike and surge protection. Check the maglock specifications for details. ®... -
Page 18: Ac Maglocks And Ac Electric Strikes
AC MAGLOCKS AND AC ELECTRIC STRIKES ® SmartLock Page 18 of 29 Installation Manual April 2009 • Rev. 1.7... -
Page 19: Input Wiring
Input Wiring EXIT BUTTON, HANDICAP BUTTON, DOOR CONTACT IF YOU ARE CONNECTING A DOOR CONTACT SET DIP SWITCH 8 TO OFF (LEFT) IF YOU ARE CONNECTING A DOOR CONTACT SET DIP SWITCH 8 ON (RIGHT) EXIT BUTTON - NORMALLY OPEN - MOMENTARY TO ACTIVATE HANDICAP BUTTON... -
Page 20: Output Wiring
Output Wiring DOOR OPERATOR, FORCED ENTRY, DOOR-HELD-OPEN Use dry contact relays. RELAY LEDS TURN SET RELAY CONTACTS ON ACTIVATION = N/O = N/C N/O: RELAY CLOSES ON ACTIVATION N/C: RELAY OPENS ON ACTIVATION DOOR OPERATOR OUTPUT ACTIVATED MOMENTARILY WHEN HANDICAP BUTTON IS DEPRESSED AFTER LOCK RELAY IS ACTIVATED. -
Page 21: Dip Switch
DIP Switch FUNCTION The DIP switch is used: to erase the controller’s memory and run diagnostics; to enable or bypass the door contact input; and to set the controller address from 0 to 60 (0 for stand-alone only). LOCATION SWITCH WIEGAND DATA LED COMMS... -
Page 22: Erase Controller Memory, Diagnostics
ERASE CONTROLLER MEMORY, DIAGNOSTICS 1. Disconnect communication and device wiring. 2. To erase controller memory (factory default), set all switches to the OFF position (left on diagram above). 3. Disconnect power from the board momentarily, then re-connect power. 4. The controller’s memory will be erased. All three relays will cycle ON/OFF once the memory has been cleared. -
Page 23: Door Contact Bypass Switch Setting
DOOR CONTACT BYPASS SWITCH SETTING WIEGAND DATA LED IF YOU ARE CONNECTING A DOOR CONTACT SET DIP SWITCH 8 TO OFF (LEFT) IF YOU ARE CONNECTING A DOOR CONTACT SET DIP SWITCH 8 ON (RIGHT) COMMS Door Contact Connected: Set switch 8 OFF (LEFT on diagram) Door Contact Not Connected: Set switch 8 ON (RIGHT on diagram) NOTE: If door contacts are not installed, but door contacts are enabled on the control panel via switch 8, unlock schedules will fail to take effect. -
Page 24: Set Address For Smartlock Connect (Stand-Alone)
SET ADDRESS FOR SMARTLOCK CONNECT (STAND-ALONE) To enable stand-alone operation and programming using the Stand-Alone Programming Module, set the controller switch settings as follows: 1. Locate DIP switch position 8 using the diagram above. 2. Set switch positions 1 through 6 to the ON position (address 0). 3. -
Page 25: Controller Address Table
Controller Address Table Set the unique address of each controller from 0 to 60 as per the table below. Address “0” is used for ALL stand-alone units to be programmed using SmartLock Connect software. For SmartLock, the same address used must ®... - Page 26 ADDRESS SW-1 SW-2 SW-3 SW-4 SW-5 SW-6 ® SmartLock Page 26 of 29 Installation Manual April 2009 • Rev. 1.7...
- Page 27 ADDRESS SW-1 SW-2 SW-3 SW-4 SW-5 SW-6 NOTES: 1. Switch setting changes do not take effect until the power is disconnected, then reconnected. 2. All stand-alone units must be addressed as “0”. ® SmartLock Page 27 of 29 Installation Manual April 2009 •...
-
Page 28: Appendix
Appendix CLA50 COMMUNICATIONS WIRING SMARTLOCK +12 VDC CONTROLLER NOTES: - Each Smartlock controller must ADDRESS “1” SHOWN (Dipswitch 1 is OFF) have a unique address - For communication wiring, use 22 AWG, twisted pair, stranded, SMARTLOCK shielded cable, 2000 ft ( 609 m ) MAX CONTROLLER... - Page 29 ® SmartLock is a registered trademark of Cansec Systems Ltd. ® iButton is a registered trademark of Maxim Integrated Products, Inc. ® SmartLock Page 29 of 29 Installation Manual April 2009 • Rev. 1.7...
