- Page 1 MAP1 IP Configuration July 2021 Cutting edge simplicity...
-
Page 2: Table Of Contents
Introduction .......................3 PC Requirements ......................3 MAP1 Front View ......................4 Software IP Configuration Tool ................4 USB IP Configuration Tool ..................7 IP Reset ........................12 Copyright © 2021 Cansec Systems, Ltd. MAP1 IP Configuration Page 2 of 12 July 2021 • Rev. 1.2... -
Page 3: Introduction
Introduction The MAP1 is factory set to DHCP mode when shipped and is recommended to leave it in DHCP mode. First Access software will automatically find all connected controllers in the local network. The MAP1 controller can optionally be set to a static IP address. Cansec... -
Page 4: Map1 Front View
Note: The new controller is factory set to acquire an IP address automatically (DHCP mode enabled) and is highly recommended. If the IP address of the MAP1 controller needs to be set or reset to factory default, follow instructions below. - Page 5 3. In most cases, the IP Configuration Tool will detect and display the default IP address range ready to be scanned. However, the IP address range can be manually modified accordingly. 4. Click Scan to scan the network for all possible connected MAP1 controllers. MAP1 IP Configuration Page 5 of 12...
- Page 6 Trusted Host IP and can be connected from any host. If you have an old firmware, please contact Cansec support. 6. The factory default or current password for a new un-configured MAP1 controller is Cansec. The password must be changed to something else other than Cansec.
-
Page 7: Usb Ip Configuration Tool
Important: Shutdown Push Button (PB1) must be used to avoid data corruption on the MAP1 controller. 1. If the MAP1 controller is powered on, press and hold the PB1 button, using a small screw driver or a paper clip, for a period of 5 to 8 seconds and proceed to step 2. - Page 8 5. Insert the power connector into the MAP1 controller. The unit will begin the power up sequence which takes about 30 to 40 seconds. When complete, the MAP1 controller will beep indicating its mode e.g. First Access, Webster or CloudACS.
- Page 9 First Access Express having the software installed. If IpSecurity is enabled and ClientIp has a valid IP address specified then the MAP1 controller accepts data connection (SrvPort 5000) from only this host computer. Other connections on DiagPort 5001 and UpdatePort 5002 are not affected by this setting.
- Page 10 < USB INIT DONE > < USB INIT DONE > Please remove this line after this file has been correctly modified. The MAP1 controller reads parameters in this file during boot up sequence and configures the IP address accordingly after which it will write <USB INIT DONE>...
- Page 11 13. If no error file is present, it is recommended that the file MAPCFG.txt be reviewed to ensure that the line <USB INIT DONE> has been written by the MAP1 controller indicating that the IP configuration has been successfully saved and initialized.
-
Page 12: Ip Reset
(DHCP mode enabled) and erases any previous static IP address settings. Default password will also be reset to Cansec. Note: If a USB drive is present during reboot, the MAP1 controller will look for the file named MAPCFG.txt and extracts IP settings parameters to configure its IP address information accordingly.
