Installation

Step 1

Remove two plastic tabs on the front of the marine radio cover to access four mounting
screw holes. You need to fasten the radio cover to the dash through the screw holes.
Note: Use a plastic prying tool to remove the tabs. Exercise caution when prying the tabs
off to prevent damage on the radio cover.
Mounting screw holes
Tab

Step 2

Attach your head unit to the radio cover through the opening of the radio cover. The
opening fits a 7" x 2.0" head unit (single DIN). Make sure the head unit is securely attached.
7.7"
2.7"

Step 3

Secure the radio cover in the dash through four screw holes (as described in Step 1) using
four supplied screws and clip nuts. The cut-out in the dash is 8.7" x 3.3" (W x H).
Note: The top of the radio cover needs extra clearance, so that the spring-activated door
can glide smoothly to the open position (top opening).
8.7"
3.3"
(Back view)
