TECHNICAL DATA
Rated motor power
Rated current
Air outlets
Quick connector fitting size
Weight
Input
Power cord length
Air tank capacity
Free air delivery
Maximum air delivery
Maximum air pressure
Working pressure range
Pressure gauge
Maximum rotational shaft speed
Operating temperature
Hazard level
Plant design registration number
Measured sound pressure level (the reference number
of the noise test code: EN ISO 2151:2008)
Measured sound power level (the reference number
of the noise test code: EN ISO 2151:2008)
REPLACEMENT PARTS
Air filter
WARNING!
Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
GENERAL SAFETY WARNINGS
WARNING! When using electric tools, basic safety precautions
should always be followed to reduce the risk of fire, electric shock
and personal injury. Read all these instructions before attempting to
operate this product and save these instructions.
Read all instructions.
Know your power tool. Read the operator's manual carefully. Learn the
applications and limitations as well as the specific potential hazards
related to this tool.
WORK AREA SAFETY
■ Keep work area clean. Cluttered areas and benches invite
accidents. Do not leave tools or pieces of wood on the tool while
it is in operation.
■ Do not use in dangerous environments. Do not use power tools in
damp or wet locations or expose to rain. Keep the work area well lit.
■ Keep children and visitors away. All visitors should wear safety
glasses and be kept a safe distance from work area. Do not let
visitors contact tool or extension cord while operating.
■ Never use in an explosive atmosphere. Normal sparking of the
motor could ignite fumes.
6
AIR COMPRESSOR
ELECTRICAL SAFETY
■ Guard against electrical shock by preventing body contact with
grounded surfaces, e.g., pipes, radiators, ranges, refrigerator
enclosures.
■ Do not abuse cord. Never carry tool by the cord or yank it to
disconnect from receptacle. Keep cord from heat, oil, and sharp
edges.
■ Should any electrical component of the tool fail to perform
properly, shut off the power switch, remove the plug from the
power source and replace before resuming operation.
■ Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
PERSONAL SAFETY
■ Stay alert and exercise control. Watch what you are doing and use
common sense. Do not operate tool when you are tired. Do not
rush.
■ Dress properly. Do not wear loose clothing, neckties, or jewellery
that can get caught and draw you into moving parts. Rubber
gloves and nonskid footwear are recommended when working
outdoors. Also wear protective hair covering to contain long hair.
■ Always wear safety glasses with side shields. Everyday eyeglasses
have only impact-resistant lenses; they are not safety glasses.
■ Protect your lungs. Wear a face or dust mask if the operation is
dusty.
■ Protect your hearing. Wear hearing protection during extended
periods of operation.
■ Do not overreach. Keep proper footing and balance at all times.
■ Remove adjusting keys and wrenches. Form habit of checking
to see that keys and adjusting wrenches are removed from tool
before turning it on.
6
2 pcs, 6.35mm (1/4") NITTO style connector/
coupler (suitable for NITTO fitments)
6.35 mm (1/4") BSP thread
220 - 240 V AC, 50 Hz
375 L/min at 0 bar tank pressure
8 bar (116 psi)
6 - 8 bar (87 - 116 psi)
2 pcs, 41 / 51 mm diameter
PV 6-265881/22
L
=75.69 dB(A), K
pA
L
=87.73 dB(A), K
wA
39892001021
AC30100S
2200 W
9.2 A
71.5 kg
2 m
100 L
196 L/min
1400 min
-1
0 - 45°C
D
=3 dB(A)
pA
=3 dB(A)
wA
