  • Page 1 User Manual CLUSTER B2 W USER MANUAL...

  • Page 2: Table Of Contents

    1.1. General Preventive Measures 1.2. Regulations for equipment that connects to power mains 1.3. Technical warnsigns and explanation 2. Introduction 2.1. About us 2.2. CLUSTER B2 W 3. General Product Information 3.1. Scope of delivery 3.2. Control Functions 3.3. Features 4.
  • Page 3 User User Manual Manual 7. Technical Data / Diagrams 7.1 Technical drawings and measurements 7.2 IP Rating 7.3 Technical Data 7.4 DMX-Charts 7.5 RDM Templates 8. Troubleshooting 9. Manufacturer´s Declaration...

  • Page 4: Safety Informations

    1.1.1. Please read, understand and follow the instructions. 1.1.2. Store the instructions and information in a safe place. Best solution is the ring binder provided by ROXX. 1.1.3. Follow all safety warnings. Under no circumstances remove safety warnings or other information from the equipment.

  • Page 5: Regulations For Equipment That Connects To Power Mains

    User User Manual Manual 1.1.20. Observe all disposal laws applicable in your country. Especially for the packaging. 1.1.21. Plastic bags are not a toy! Keep away from children! 1.1.22. Please note that changes or modifications which are not approved by the party responsible for compliance will void the user’s authority to operate the device.

  • Page 6: Technical Warnsigns And Explanation

    User User Manual Manual 1.3. Technical warnsigns and explanation In order to prevent the risk of an electric shock, under no circumstances remove the cover/back or open the unit in any way! No user serviceable parts are inside. Service, maintenance and repairs should only be done by qualified service personnel or the manufacturer.

  • Page 7: Introduction

    This ensures innovative, easy-to-use and performance- oriented solutions, which provide added value for our customers. Made to last Recommended for permanent outdoor use, most ROXX products feature additional corrosion protection and en- ®...

  • Page 8: General Product Information

    Manual 3. GENERAL PRODUCT INFORMATION 3.1. Scope of delivery 1x CLUSTER B2 W Power cord with plug (EU country specific, if not ordered differently) Pre-installed PUK We´re offering a wide range of professional accessories (optional). Please see under menu 6 or at our website www.roxxlight.com...

  • Page 9: Installation & Setup

    4. INSTALLATION & SETUP 4.1 Physical Installation and Rigging ROXX CLUSTER B2 W may be installed in any orientation. For this purpose the product provides several options: Standing: The fixtures Yoke includes two M8 inner threads to install the optional ROXX YOKE FLOOR EXTENSION.
  • Page 10 A: 3x Camlock with ¼ turn adapters B: 3x M12 / ½“ C: 1x TV Spigot 3. Using optional ROXX RIGGING BRACKET For seemless connection of multiple Blinders, to avoid gaps due to bracing of the truss structure by variable, sliding mounting positions.
  • Page 11 User User Manual Manual 2. Pre-Link Magnets on top and side help to allign the fix- tures due cluster process and giving support operation for convenient and save interlocking. Important Note: Even though the pre-link magnet system is strong enough to hold the devices to- gether, at least one hand must always remain on the device for support during the connection.
  • Page 12 User User Manual Manual The maximum loads listed here below take into account the 10-fold safety! 1. Rigging by integrated 1/4 turn Camlocks on top- or rear side Max. Tension Load: 90kg Max. Tension Load: 90kg Max. Torsion Load: 18.703 Nmm Max.
  • Page 13 Max. Tension Load: 88kg Max. Tension Load: 66kg Max. Torsion Load: 8.238Nmm Max. Torsion Load: 6.476Nmm 3. Using optional ROXX RIGGING BRACKET with 2x Mounting Clamps Max. Tension Load: 72kg Max. Torsion Load: 6.326 Nmm Important Note: Please be aware of using the centering PUK for safe RIGGING BRACKET installation to the...

  • Page 14: Connections

    POWER IN and POWER OUT sockets are protected from spraying water, as in accordance with IP65. 4.2.1. AC Power The CLUSTER B2 W operates on any 100–260 V, 50/60 Hz AC mains power supply with a maximum power con- sumption of 220W.

  • Page 15: Dmx Connection

    Manual 4.2.2. DMX Connection The CLUSTER B2 W is fully controllable by DMX (USITT DMX512-A standard, based on RS-485) and RDM. 4.2.2.1. Cable Connection If using a cabled DMX system, connect the DMX IN cable to the input connector (male 5-pin XLR connector) and DMX OUT cable to the output (female 5-pin XLR connectors).

  • Page 16: Operation

    Once the fixture is connected to AC power, the boot process starts and the following information will appear on the display: “Ready to ROXX”, the product name and the current software version. After this process, the fixture is ready for operation, and starts in the previous- ly enabled mode.
  • Page 17 User User Manual Manual Display Off Pressing ESC + arrow down simultaneously the display backlight function will set to off and the display will turn off immediately. Once a control is pressed the display backlight will turn on. Manual display flip function* The fixture includes an auto display flip function by default.

  • Page 18: Configuration

    User User Manual Manual 5.4 Configuration Home Screen After boot process the fixture is ready for operation and starts in the previously enabled mode. At home screen the following information will appear, depending on the current operating mode: DMX Adress Operating Mode (DMX Mode, Quick Light or Standalone Mode) Next available DMX address depending on the fixtures DMX footprint External Data protocol (DMX).

  • Page 19: Stand Alone

    User User Manual Manual Level 1 Level 2 Menu DMX Mode DMX Mode 1CH DWE 2CH DWE Stand Alone 4CH DWE Slave 5CH STROBE Settings 7CH STANDARD System Info 10CH EXTENDED 13CH EXTENDED 5.4.3 Stand Alone* Press ENTER to access to main menu (level 1). While using the UP / DOWN arrows, please select the menu item “Stand Alone”...
  • Page 20 User User Manual Manual Once it´s confirmed or denied the display will automatically jump back to level 3. To stop running a selected Effect please chose “Stop Program” at level 3 or "Stop Stand Alone" at level 2. For returning back to homescreen please press ESC three times. At homescreen the selected Stand Alone mode “Auto”...

  • Page 21: Slave Mode

    User User Manual Manual 5.4.4 Slave Mode* Slave Mode allows same model fixtures to be controlled by the “Master” fixture via DMX). The “Master” device should run in Stand Alone mode, all “Slave” devices should set to “Slave”. Level 1 Menu DMX Mode Stand Alone...
  • Page 22 User User Manual Manual Main Menu Menu level 2 Menu level 3 Menu level 4 Description On= Flip control panel display by Display Flip <on/off> 180° (e.g. for overhead installation) Off= normal control panel display On= controls permanent on, display itself will deactivate after 60 minues of incativity Backlight <on/off>...
  • Page 23 User User Manual Manual Adjust fan speed relative to internal fixture Auto temperature Silent Low fan speed for silent operation Fan Off Fan Off Max. Power High fan speed for maximum cooling effect Invert Mapping On / Off Inverts the pixel layout of the fixture Including DMX Address Transfer the same menu settings of this fixture to all the other in daisy chain (same model),...

  • Page 24: System Info

    User User Manual Manual Dimmer Curves LINEAR EXPONENTIAL LOGARITHMIC S-CURVE 5.4.6 System Info Level 1 Menu DMX Mode Stand Alone Slave Settings System Info Main Menu Menu level 2 Menu level 3 Menu level 4 Firmware Version vx.xx Display installed firmware version Serial Number 200xxxxxxxx RDM UID...

  • Page 25: Accessories

    User User Manual Manual 6. ACCESSORIES Yoke 2.2 Yoke 4.3 Floor Extension Rigging Bracket Art.: 13907001 Art.: 13907101 Art.: 13907411 Art.: 13907201 Omega Bracket ST Case 4 pcs. / 8 pcs. Art.: 13907411 Art.: 90900002 Case 2 pcs / 4 pcs Art.: 13907511...
  • Page 26 User User Manual Manual 7. TECHNICAL DATA / DIAGRAMS 7.1 Technical drawings and measurements...
  • Page 27 7.2 IP Rating ROXX products conform to officially classified IP standard levels. CLUSTER B2 W is rated to IP65 when using the co- vers for the housing parts. IP stands for Ingress Protection and IP65, according to classified standard, means shielded against dust and high-pressure jets of water from any side.
  • Page 28 User User Manual Manual 7.3 Technical Data Photometrics LED expected lifetime 50.000 hours Lightsource 2x 300W Warm-White + Amber + Red Type of optical system Reflector with Compound Eye Lens LED PWM Frequency selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz Beam angles (50%) 50°...
  • Page 29 User User Manual Manual 7.3 Technical Data Operator & Controller Master Dimmer, Master Dimmer Fine, Shutter, Duration, Dimmer 1-2, Dimmer 1-2 DMX Functions Fine, Dimmer Curve, Dimmer Response, Redshift, Effect, Device Settings 1CH DWE, 2CH DWE, 4CH DWE, 5CH STROBE, 7CH STANDARD (default), 10CH DMX channels EXTENDED, 13CH EXTENDED DMX modes...
  • Page 30 User Manual 7.4 DMX-Charts 1CH DWE 2CH DWE 4CH DWE 5CH STROBE 7CH STANDARD (default) 10CH EXTENDED 13CH EXTENDED 7CH STANDARD 1CH DWE 2CH DWE 4CH DWE 5CH STROBE 10CH EXTENDED 13CH EXTENDED (default) Dimmer Dimmer 1 Dimmer Master Dimmer Master Dimmer Master Dimmer Master Dimmer...
  • Page 31 User Manual 1CH DWE Function Value Setting Remark Default Dimmer 000-255 0 - 100% 2CH DWE Function Value Setting Remark Default Dimmer 1 000-255 0 - 100% Dimmer 2 000-255 0 - 100% 4CH DWE Function Value Setting Remark Default Dimmer 000-255 0 - 100%...
  • Page 32 User Manual Strobe 5: random opening pulse 130 - 144 (fast slow) 145 - 149 Shutter open Strobe 6: random closing pulse 150 - 164 (fast slow) 165 - 169 Shutter open 170 - 184 Strobe 7: burst pulse (fast slow) 185 - 189 Shutter open...
  • Page 33 User Manual Strobe 8: random burst pulse 190 - 204 (fast slow) 205 - 209 Shutter open 210 - 224 Strobe 9:sine wave (fast slow) Shutter 225 - 229 Shutter open 230 - 244 Strobe 10: burst (fast slow) 245 - 255 Shutter open Dimmer 1 000-255...
  • Page 34 User Manual 125 - 129 Shutter open Strobe 5: random opening pulse 130 - 144 (fast slow) 145 - 149 Shutter open Strobe 6: random closing pulse 150 - 164 (fast slow) 165 - 169 Shutter open 170 - 184 Strobe 7: burst pulse (fast slow) Shutter...
  • Page 35 User Manual 000-029 No function 030-034 Display Backlight On (hold 3s) 035-039 Display Backlight Off (hold 3s) 040-044 No function 045-049 DMX Fail Blackout (hold 3s) 050-054 DMX Fail Hold (hold 3s) DMX Fail - Emergency Light 055-059 (hold 3s) 060-064 No function 065-069...
  • Page 36 User Manual 13CH EXTENDED Function Value Setting Remark Default Master Dimmer 000-255 0 - 100% Master Dimmer Fine 000-255 0 - 100% 000 - 019 Shutter close 020 - 024 Shutter open 025 - 064 Strobe 1 (fast slow) 065 - 069 Shutter open Strobe 2: opening pulse 070 - 084...
  • Page 37 User Manual No Function - Current Preset from 000-063 Menu Settings 064-127 LED / fast Dimmer Response 128-191 Medium 192-255 Halogen / slow No Function - Current Preset from 000-84 Menu Settings Redshift 085-170 Redshift Off 171-255 Redshift On 000-40 No Function 041-083 Effect 1 (slow to fast)
  • Page 38 User Manual 135-139 No function 140-144 Invert Mapping On (hold 3s) 145-149 Invert Mapping Off (hold 3s) 150-154 No function Device Settings 155-159 LED Mode - Illumination (hold 1,5s) (please see 160-164 LED Mode - Boost (hold 1,5s) remark *1) 165-169 No function 170-174...
  • Page 39 Device ID: 202 xxxx * Note: During RDM identifying process CLUSTER B2 W flashes white alternately. RDM functions For easy identifying ROXX CLUSTER B4 W during RDM process the unit will strobe in white color. DMX Start Adress 001-512 0x00F0...
  • Page 40 User User Manual Manual 0x805B Invert Mapping 0= Off / 1= On 0x805C LED Mode 0= Illumination / 1= Boost 0x805D USB Update Yes/No 0= No / 1= Yes 0x805E Factory Reset Yes/No 0= No / 1= Yes 0x805F User Reset Yes/No 0= No / 1= Yes 0x00C0...
  • Page 41 Hansestr. 91 51149 Köln Email: info@roxxlight.com or the ROXX authorized reseller in your country, from where you purchased your product. Correct Disposal of this product This is for the European Union and European countries with electrical waste collection systems. When this label is shown on the product or brochure it means that the item cannot be disposed with household waste.
  • Page 42 User User Manual Manual CE Compliance The equipment marketed by ROXX GmbH complies (where applicable) with the essential requirements and other specifications of the following Directives: • 2014/30/EU (EMC) • 2014/35/EU (LVD) • 2011/65/EU (RoHS) The complete EU- and UK-Declaration of Conformity can be found at www.roxxlight.com/support, or you can also request it at info@roxxlight.com...
