MAIN COMPONENTS (Cont...)

1. Air tube to carbure�or

2. Fuel ﬂow control valve & Injector

3. Carbure�or

4. Fuel filter

1. Rear access cover

2. Front access cover

3. Resonator shield

FIG. 2

5. Spark plug

6. Fuel hose

7. 12V Power supply input

8. Remote control input

FIG .3

4. Chemical injector to resonator

5. Vehicle frame

6. Resonator
