04. Carbure�or
1. Venturi
2. Upper Gasket
7. Spring washer
8. Bolt
13. Ring
14. Nut
19. O-ring
20. Engine rear peg
25. Air gasket
26. Washer
31. Air gasket washer
32. Air gasket nut
3. Cone sha�
9. Lower Gasket
15. Engine upper pipe
21. Reducer
27. Air Gasket Bolt
33. Air gasket nut
NETHERLANDS | SOUTH KOREA | USA
info@vectorfog.com | www.vectorfog.com
11
4. Petrol valve board
5. Petrol valve
10. Engine
11. Ejec�on nozzle
16. Plug
17. Plug cap
22. Run tee
23. Elbow
28. Air elbow
29. Extension hose
6. Petrol valve support
12. Nozzle
18. Metal grip
24. Explosion pipe
30. Air gasket bolt
