1. Safety information FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE POWERING OR INSTALLING YOUR E-BOX REMOTE BASIC! Save it for future reference. DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT! Make sure that the available voltage is not higher than stated on the fixture. Always disconnect the fixture from AC power before removing its cover.
2. Fixture description A - Top cover B - Top cover screws C - Mounting holes 1 - LED Output 1 (cable gland M20x1.5) 2 - LED Output 2 (cable gland M20x1.5) 3 - Power IN (cable gland M20x1.5) 4 - DMX IN (cable gland M12x1.5) View without top cover...
3. Mounting Fixture must be installed by a qualified electrician in accordance with all national and local electrical and construction codes and regulations. Setting and addressing the E-BOX REMOTE BASIC without top cover can be done by a qualified person only! Note for cable glands.
Page 7
Eminere Remote connection Mark Function Wire LEDs + DATA + Orange DATA - Black LEDS - White Ground Not connected Example of connection Terminator...
Page 8
Each line of Emineres Remote connected to the LED output of the E-box Remote Basic has to be terminated at the last fixture. EITHER connect a 120 Ohm resistor between terminals D+ and D- as shown, OR terminate via RDM as described on page 11.
Pass-Thr - LED modules are switched to an internal parallel connection. DMX addressing of connected LED modules has to be done manually by means of the Robe Universal Interface (or its wireless version Robe Uni- versal Interface WTX) and the software RDM Manager.
Page 10
Examples of RDM manager screenshots for one connected LED module. Initial screen of the RDM manager: Click on the device to show options of the Control panel Options in the Control panel allows you to set DMX address and Personality for each LED module. Click on the green arrow to save adjusted values...
Page 11
Options in the control panel: Possible numbers of connected LED modules for each E-box mode are stated in the chapter "3. Mounting". If no DMX is received, the unit will turn on the predefined Demo mode. You can modify it by setting the unit to a desired look via DMX and then save this via RDM by setting the "Init position LEDs"...
Page 12
The function "Pixel swap" from RDM control panel allows you to swap a pixel order. Example: In case of reconnecting the E-box Remote Basic on the other end of Emineres Remote line, the pixel order is not in succession: By means of the function "Pixel swap" you can rearrange pixels in order.
5. Technical specifications Input voltage 120-240 V AC; 277V AC Frequency 50/60Hz Power consumption: 520W Fuse 1 T 6.3A/500V AC Fuse 2 T 8A/250V AC Fuse 3 T 8A/250V AC LED Output Number of outputs Voltage 48V DC Max output power 380W per output Total Output power 480W max.
