PRODUCT MODEL NUMBER:
TL-9916 16 in 1 IP QAM
MODULATOR
ABOUT THIS
MANUAL
DISCLAIMER
No part of this document may be reproduced in any form without the written permission of the copyright
owner.
The contents of this document are subject to revision without notice due to continued progress in
methodology, design, and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or
damage of any kind resulting from the use of this document.
COPY WARNING
This document includes some confidential information. Its usage is limited to the owners of the
product that it is relevant to. It cannot be copied, modified, or translated in another language
without prior written authorization from TRANSLITE GLOBAL LLC
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TransLite TL-9916
Summary of Contents for TransLite TL-9916
- Page 1 The contents of this document are subject to revision without notice due to continued progress in methodology, design, and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or damage of any kind resulting from the use of this document.
-
Page 2: Table Of Contents
P a g e INDEX TABLE OF CONTENTS CHAPTER 1 INTRODUCTION ........................3 1.1 PRODUCT OVERVIEW........................3 1.2 KEY FEATURES........................... 3 1.3 SPECIFICATIONS ..........................4 1.4 PRINCIPLE CHART ..........................5 1.5 APPEARANCE AND DESCRIPTION ...................... 6 CHAPTER 2 INSTALLATION GUIDE ...................... -
Page 3: Chapter 1 Introduction
INTRODUCTION PRODUCT OVERVIEW TL-9916 16 in 1 IP QAM modulator is the latest generational Mux-scrambling modulating all-in-one device developed by TRANSLITE. It has 16 multiplexing channels, 16 scrambling channels and 16 QAM (DVB-C) modulating channels, and supports maximum 512 IP input through the 3 GE ports and 16 non-adjacent carriers (50MHz~960MHz) output through the RF output interface. -
Page 4: Specifications
P a g e SPECIFICATIONS Input Input 512 IP input, 2 100/1000M Ethernet Port (SFP optional) Transport Protocol TS over UDP/RTP, unicast and multicast, IGMP V2/V3 Transmission rate Max 840Mbps for each GE input Input Channel Output Channel Max PIDs 180 per channel PID remapping (auto/manually optional) Functions... -
Page 5: Principle Chart
P a g e RF Output Interface 1 F typed output port for 16 carriers, 75Ω impedance RF Range 50~960MHz, 1kHz stepping Output Level -20dBm~+10dBm(87~117dbµV), 0.1dB stepping ≥ 40dB General Dimension 420mm×440mm×44.5mm (WxLxH) Temperature 0~45℃(operation), -20~80℃(storage) Power Supply AC 100V±10%, 50/60Hz or AC 220V±10%, 50/60Hz PRINCIPLE CHART... -
Page 6: Appearance And Description
P a g e Carrier Setting Illustration CH X CH X CH 1 CH 2 CH X CH 15 CH 16 ……… ……… 192M Start Frequency End Frequency APPEARANCE AND DESCRIPTION Front Panel Illustration NMS/CAS: network management port and CA data port Power Indicator... -
Page 7: Chapter 2 Installation Guide
P a g e Rear Panel Illustration RF output port Reset IP: Reset webmaster IP address, recover it to default IP address Link/Act indicators Data Input /Output 1/2 Power switch AC Power socket Grounding CHAPTER 2 INSTALLATION GUIDE This section is to explain the cautions the users must know in some case that possibly injure may bring to users when it’s used or installed. -
Page 8: Installation Preparation
➢ Checking the possible device missing or damage during the transportation ➢ Preparing relevant environment for installation ➢ Installing TL-9916 16 in 1 IP QAM Modulator ➢ Connecting signal cables ➢ Connecting communication port (if it is necessary) DEVICE’S INSTALLATION FLOW CHART... -
Page 9: Environment Requirement
P a g e ENVIRONMENT REQUIREMENT Item Requirement When user installs machine frame array in one machine hall, the distance Machine Hall between 2 rows of machine frames should be 1.2~1.5m and the distance Space against wall should be no less than 0.8m. Electric Isolation, Dust Free Machine Hall Volume resistivity of ground anti-static material: 1X107~1X1010，... -
Page 10: Frame Grounding
When the device adopts united way, the grounding resistance should be smaller than 1Ω. Caution: Before connecting power cord to TL-9916 16 in 1 IP QAM Modulator, user should set the power switch to “OFF”. -
Page 11: Web Nms Management
P a g e | 11 Signal and NMS Cable Connection The signal connections include the connection of input signal cable and the connection of output signal cable. CHAPTER 3 WEB NMS MANAGEMENT User can only control and set the configuration in computer by connecting the device to web NMS Port. - Page 12 P a g e | 12 User can click any item here to enter the corresponding interface to check information or set the parameters. Figure-2 Monitor → Input Status: Clicking “Input Status”, it will display the interface as Figure-3 where users can check the input status of Data1 and Data 2.
- Page 13 P a g e | 13 Monitor → Output Status: Clicking “Output Status”, it will display the interface as Figure-4 where users can check output status of the 16 carriers and 16 IPs. Users need to enable the output status in “Modulator” and “IP Stream”...
- Page 14 P a g e | 14 Parameters → TS Config: Clicking “TS Config”, it will display the interface where users can configure the output TS parameters in this interface. ➢ Output TS X Clicking “Output TS X”, it will display the interface as Figure-6 where users can select the output TS channels.
- Page 15 P a g e | 15 Input Area Output Area Set output IP address of streamer Operation Area Figure-7 Configure ‘Input Area’ and ‘Output Area’ with buttons in ‘Operation Area’. Instructions are as below: : To add input channel which come from Data1or Data 2 or Data/Module : To edit the input channel : To delete the input channel : To delete all inputs channel...
- Page 16 P a g e | 16 To refresh the output program information Select one input program first and click this button to transfer the selected program to the right box to output. Similarly, user can cancel the multiplexed programs from the right box. To select all the input programs To select all the output programs To parse programs...
- Page 17 P a g e | 17 Figure-9 Figure-9 ➢ PID Pass Clicking “PID Bypass”, it will display the interface as Figure-10 where user can add PIDs to be passed, click the “+” symbol, input current IP channel number, then input current IP source PID and output PID which is customer needed, then click “set”...
- Page 18 P a g e | 18 Parameters → Scrambler: Clicking “Scrambler”, it will display the interface where users can choose the programs to scramble. (Figure-11) Scramble channel select carrier select CA channel select EMMG and ECMG working state, green means it work normally, while red means communication error...
- Page 19 P a g e | 19 Click “quickly config” to set all channels RF QAM output parameters Click “Channel config” to set each channel RF QAM output parameters Figure-12 When users click “quickly config” button, it triggers a dialog box as follow where users can set all channels configration.
- Page 20 P a g e | 20 Parameters → IP Stream: TL-9916 supports TS to output in IP (16*MPTS) format through the DATA port. Clicking “IP Stream”, it will display the interface as Figure-13 where to set IP out parameters. Quickly Config...
- Page 21 P a g e | 21 Set output IP address Click to enable the status and select TS out thru Data 1 or Data 2 When users click “Channel Config” button, it triggers a dialog box where users can set corresponding MPTS channel configuration.
- Page 22 P a g e | 22 System → Password: Clicking “Password”, it will display the screen as Figure-15 where to set the login account and password for the web NMS. Figure-15 System → Configuration: Clicking “Configuration”, it will display the screen as Figure-16 where to set your configurations for the device.
- Page 23 P a g e | 23 System → Firmware: Clicking “Firmware”, it will display the screen as Figure-17 where to update firmware for the device. Figure-17 System → Date/Time: Clicking “Date/Time”, it will display the interface as Figure-18 where users can set date/time for this device.
-
Page 24: Chapter 4 Troubleshooting
CHAPTER 4 TROUBLESHOOTING All TRANSLITE products have been passed the testing and inspection before shipping out from the factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by TRANSLITE. To prevent potential hazard,... -
Page 25: Chapter 5 Packing List
Device was suffered from physical damage ➢ Longtime idle. ➢ After switching on and restoring to factory setting, device still cannot work properly. ➢ Maintenance needed CHAPTER 5 PACKING LIST TL-9916 16 in 1 IP QAM Modulator User's Manual Power Cord... -
Page 26: Chapter 6 Applications
P a g e | 26 CHAPTER 6 APPLICATIONS...
