- Page 1 Operating Instructions Pure Control unit www.inventer.de...
- Page 2 GmbH. ® The copyright to this document remains with the manufacturer. Rights to all content and images: © inVENTer GmbH 2022. All trademarks used in this document are the property of their respective manufacturers and are hereby acknowledged.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of contents User and safety instructions ....................4 User information ......................4 Safety instructions ......................4 System overview: Pure controller ..................6 Function ......................... 7 Operation ..........................8 General information......................8 Setting the ventilation level .................... 9 Switching off the ventilation .................... -
Page 4: User And Safety Instructions
Action focus: To be taken into account in the corresponding step. Safety instructions The operating instructions are part of your Pure control unit and must be available at all times (see www.inventer.de/downloads). When handing the system to a third party, the information regarding access to the operating instructions must be handed over also. - Page 5 Intended use The Pure control unit (also referred to in the further text as "controller" or "Pure controller") must only be used to control decentralised iV ventilation units with heat recovery from inVENTer GmbH.
-
Page 6: System Overview: Pure Controller
Integrated indicator lights mean that the switch acts simultaneously as a visual feedback / display for the user. The Pure controller can be used either as a base control unit or with additional sensors connect- An external interface allows the scope of functions to be expanded: •... -
Page 7: Function
SYSTEM OVERVIEW: PURE CONTROLLER Function The Pure controller is a control unit for decentralised ventilation units with heat recovery from inVENTer GmbH. Where these are connected, the information determined at the controller via the sensor technology is incorporated into the control of the ventilation unit. -
Page 8: Operation
The display LED lights up solid for 10 seconds after switching the double switch (of an input). The LED then goes out automatically. If the LED is flashing, this indicates a state that must be actively resolved by the user or controlled by the sensor technology. Pure controller | Installation instructions... -
Page 9: Setting The Ventilation Level
25 % 100 % 50 % 50 % • Only the left-hand rocker • Only the right-hand rock- • Both rocker switches are switch is pressed er switch is pressed pressed 100 % 100 % Pure controller | Installation instructions... -
Page 10: Switching Off The Ventilation
1. This is not an error, but rather the flat version of the Pure controller. Complete switch-off of the ventilation unit is only possible with the standard version of the Pure controller. Pure controller | Installation instructions... -
Page 11: Setting Heat Recovery / Ventilation Mode
On summer days, this is also recommended. The higher outdoor temperature compared to the indoor temperature means that the supply of heat is significantly re- duced during ventilation. Pure controller | Installation instructions... -
Page 12: Activating / Deactivating The Pause Timer
You should therefore leave the inner cover open. Select the pause timer if your ventilation unit is to be temporarily switched off, for example before going to sleep. Pure controller | Installation instructions... -
Page 13: Acknowledging A Filter Change
The LED to indicate the current operating mode lights up solid for 10 seconds. The filter change interval is reset to 180 days. ► Select the ventilation level at which the ventilation unit is to operate. Pure controller | Installation instructions... -
Page 14: Sensor Technology Activated
The function remains active until the corresponding limit value falls below the pre-set limit value again: • the green LED on the Pure controller goes out. • All of the ventilation units connected to the controller restart in the originally set operating mode and ventilation level. -
Page 15: Cleaning And Care
The Pure p4 controller is virtually maintenance-free. Any servicing work required can be carried out by the user after brief instructions. -
Page 16: Accessories And Spare Parts
ACCESSORIES AND SPARE PARTS Accessories and spare parts Contact your local distributor to order accessories for your ventilation system. Component Item number Programming unit Pure p4 controller series switch 1004-0210 2008-0013 (p4) 2008-0015 (p4 Flat) Control module incl. LEDs 2008-0016 (p4 Fire) -
Page 17: Troubleshooting And Disposal
Dismantling and disposal Dismantle the controller before disposal. Your Pure controller contains valuable materials that can be recovered and recy- cled. The separation of waste materials into different varieties facilitates recovery of the recyclable materials. Contact an electronic appliance disposal company to arrange environmentally friendly recycling and disposal of your old system. -
Page 18: Guarantee And Warranty
The guarantee covers all defects that were present at the time of purchase. Failure to observe the intended use will invalidate all warranty claims. Manufacturer warranty inVENTer GmbH provides a five-year warranty for electronic components. This covers premature product wear. Further information about the warranty is available at www.inventer.de/garantie... - Page 19 GUARANTEE AND WARRANTY NOTES Pure controller | Installation instructions...
- Page 20 GmbH Ortsstraße 4a 07751 Löberschütz Germany www.inventer.de Subject to modifications. We accept no liability for printing errors. Item number: 5021-0021 Version: 1.0 – 02/2022...
