OPERATING INSTRUCTIONS
MIKASA FORWARD PLATE COMPACTOR
MVC-F60H, MVC-F80H
Version 2.0 (February 2022)
FOR MORE INFORMATION
EXCLUSIVE TO
CONTACT US ON
1300 353 986
OR VISIT
flextool.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVC-F60H and is the answer not in the manual?

Questions and answers

Summary of Contents for Mikasa MVC-F60H

  • Page 1 OPERATING INSTRUCTIONS MIKASA FORWARD PLATE COMPACTOR MVC-F60H, MVC-F80H Version 2.0 (February 2022) FOR MORE INFORMATION EXCLUSIVE TO CONTACT US ON 1300 353 986 OR VISIT flextool.com.au...
  • Page 2 F82/88G/98D Contents of “Declaration of Conformity” W e t h a n k y o u f o r s e l e c t i n g Mikasa Plate Compactor. For your safe and proper operation, please read this manual and be always sure to keep it ready for Please refer the ...
  • Page 3 2) Manufacturer’s name and address. 4-3, Sarugaku-cho 1 chome, Chiyoda-ku, Tokyo101-0064, Japan Yoshiharu Nishimaki, engineer 3) Name and address of the person who keeps the R. & D. Division, Mikasa Sangyo Co., Ltd. technical documentation. Shiraoka-machi, Saitama, Japan 4) Type: Vibratory Plates...
  • Page 4 10) Guaranteed sound power level(dB) 11) Max. Sound pressure level(dB) Hand-Arm Vibration Level Remarks Model h (m/sec MVC-F60H MVC-F60R MVC-F70H MVC-F70R MVC-F80H MVC-F80R MVC-88GH MVC-88GE MVC-98D MVC-F60H VAS MVC-F60R VAS MVC-F80H VAS MVC-F80R VAS MVC-88GH VAS MVC-88GE VAS MVC-98D VAS...
  • Page 6: Table Of Contents

    TABLE of CONTENTS Preface Applications, Warnings, Structure and Power Transmission Warning Symbols Safety Precautions 4. 1 General Precautions 4. 2 Refueling Precautions 4. 3 Location and Ventilation Precautions 4. 4 Precautions Before Starting 4. 5 Precautions During Work 4. 6 Lifting Precautions 4.
  • Page 7: Preface

    For inquiries about repair parts, parts lists, service manuals, and repairs, please contact the store where you purchased the product, our sales office, or the Mikasa Parts Service Center. For parts lists, please visit our homepage at: http://www.mikasas.com/ where you can access Mikasa WEB parts lists.
  • Page 8: Warning Symbols

    Before inspection and maintenance work, stop the engine, and do your work on a flat surface area. If a cell is attached, remove the battery wiring before your work. Mikasa does not accept any responsibility for accidents caused by remodeling or rework done on the machine. 4.2 Refueling Precautions When adding fuel, Make sure you work in a well ventilated location.
  • Page 9: Location And Ventilation Precautions

    4.3 Location and Ventilation Precautions Do not run the machine in an unventilated location, such as indoors or inside a tunnel. The exhaust gas from the engine contains toxic gases such as carbon monoxide and is very hazardous. Do not operate the machine near open flames. 4.4 Precautions Before Starting Check each part to see if it is tightened properly.
  • Page 10: Transportation And Storage Precautions

    4.7 Transportation and Storage Precautions Stop the engine during transportation. Transport after the engine and the machine are cooled down. Always drain the fuel before transporting. Securely fix the machine to prevent it from moving or falling during transportation. 4.8 Maintenance Precautions Appropriate maintenance is required to ensure safe and efficient operation of the machine.
  • Page 11: Labeling Position

    4.9 Labeling Position MVC-F60/F70/F80/F82 VAS HANDLE MVC-88GE/88GH VAS HANDLE...
  • Page 12 MVC-98D VAS HANDLE LABEL PART No. PART NAME Q’ TY REMARK PLATE, SERIAL NO. / EU WATER TANK 9201-01410 DECAL, MIKASA MARK 120X60 NP-141 9201-05070 DECAL,MIKASA MARK 125MM WATER TANK NP-507 9209-00090 DEAL,LIFTING POSITION NPA-1474 9209-00090 DEAL,CAUTION ICONS Warnig labels...
  • Page 13: Description Of Symbols Used Warning Labels

    4-10. Descriptions of symbols used on warning labels Do not use. (For cutters) NPA-1480 NPA-1473 NPA-1479 NPA-1474 Do not use. (For cutters) Danger: poisonous exhaust gas Be careful not to approach danger Carbon monoxide poisoning may occur if source. the exhaust gas is inhaled. Do not operate During operation, Be careful not to approach hot the machine in a poorly ventilated area.
  • Page 14: Specifications

    5.Specifications 5.1 Machine Specifications MVC-F60R MVC-F60H MVC-F80R MVC-F80H MVC-F70R MVC-F70H Model (VAS) (VAS) (VAS) (VAS) Robin Honda Robin Honda Robin Honda Model EX13D GX120 EX17D GX160 EX17D GX160 915 (930) Overall Length Overall Width 860 (1000) Overall Height Plate Size (W X L)
  • Page 15: Appearance

    6. Appearance 6.1 Overall Dimensions...
  • Page 16: Control Unit Positions And Names

    17. Fuel Valve Lever 18.Choke Lever 19. Air Cleaner 20. Spark Plug 21. Muffler 22. Starter Grip 23. Rubber Plug 24. F.O. Drain Plug 25. Fuel injection pump 26. L.O. Drain plug 27. Oil Filler Cap / Dipstik MVC-98D MVC-98D MVC-F60H/F70H/F80H/F82H/88GH...
  • Page 17: Inspection Before Operation

    7. Inspection Before Operation Conduct inspection while the engine is stopped. If you get caught in the rotating parts, you may suffer serious damage. Conduct inspection after making this machine level and checking that the body does not move. ★ Refer to the "Regular Check and Adjustments"...
  • Page 18 Set the machine on a level surface, then remove the oil gauge of the vibrator. Check the oil gauge to see if the oil is at the specified level. Use engine oil SAE10W-30 as lubrication oil. Recommended oil quantity for MVC-F60/F70/F80/F82 is 140cc and MVC-88/98D, 200cc.
  • Page 19: Operation

    8.Operation 8.1 Starting Fuel cock (HONDA) The engine exhaust gas contains carbon dioxide and is very dangerous. Do not use this machine where ventilation is poor. Fuel cock lever FLOW Gasoline engine Turn the lever of the fuel cock downward and feed Fig.3-1 fuel.
  • Page 20: Operation

    Grip the starting knob of the recoil starter. When you pull the rope a little, you will feel some resistance. Then pull it at a stroke. Be careful not to pull the rope too strongly, or the rope may break or come off. (Fig.8-1 &...
  • Page 21 Diesel engine Hold the starting handle properly. The engine is started in the manner described below. Pull out the recoil starting handle. Pull out the handle to the point where you feel strong resistance, and then return it to the initial position.
  • Page 22: Stopping Machine

    8.2 Operation vibrating plate 9. Stopping Machine When you finish the work and stop the engine, return the speed control lever to the low speed position, and Engine switch keep the engine running at low speed for 3-5minutes. When the temperature of the engine has decreased, stop the engine.
  • Page 23: Transportation

    10 Transportation Make sure there is no breakage of guard frame and anti-vibration rubber nor loosened or missing bolts. Always stop the engine when lifting. Use an intact wire rope without any deformation with sufficient strength. Slowly lift upward without applying any impact. Never let people or animals go under the lifted machine.
  • Page 24: Regular Check And Adjustments

    12. Regular Check and Adjustments 12.1 Inspection and Maintenance Schedule Table For details about the check and maintenance of the engine, please refer to the attached engine operation manual. Caution: The above table shows the check frequency for standard condition. The check frequency may vary depending on the condition in which the machine is used.
  • Page 25: Changing Engine Oil

    12.2 Changing Engine Oil Perform the first engine oil change after 20 hours of operation, then change at every 100 hours. 12.3 Cleaning Air Cleaner When the air cleaner element becomes dirty, the engine does not start smoothly, and sufficient output cannot be obtained.
  • Page 26: Troubleshooting

    13. Troubleshooting 1. Gasoline Engine (1) Starting problem Bridging Spark Plug Carbon accumulated on Spark Plug Short circuit due to insulation problems of Electricity reaches Spark Plug to High Voltage Cable Inappropriate gap of Spark Plug Fuel is supplied, but Spark Plug does not ignite Short circuit of Stop Switch...
  • Page 27 2. Diesel Engine (1) Starting problem (A) In case of compression problem Intake / Exhaust Valve upthrust No compression at all Decompressor adjustment problem Contact with seat not close enough Piston Ring wear Almost no compression Cylinder wear Cylinder, Cylinder Head mating surface problem Nozzle seat looseness (B) In case of inappropriate fuel injection inside the combustion chamber Clogging of Tank Cap Air Hole...
  • Page 28 Valve open/close timing inappropriate Engine revolution Clogged exhaust hole, muffler does not increase Overload Piston, Cylinder Ring wear Nozzle hole clogging Piston Ring stuck Wrong assembly (upside down) of Piston Ring Inappropriate injection timing Inappropriate Valve open/close timing Looseness of Injection Pump joint Leakage from fuel passage Fuel consumption too Clogging of the Air Cleaner Element...
  • Page 30 Design and technical specifications may be subject to changes. © This publication is copyright. All rights are reserved. Flextool is a registered trade mark of Parchem Construction Supplies Pty Ltd. Mikasa is a registered trade mark of Mikasa Sangyo Co. Ltd, used under licence.
