MBK530
This pole mount adapter allows speakers to be mounted to different poles.
Included hardware:
Pole mount
Installation:
1
x4
M6 bolt x 10 mm
Installation manual
Step 1:
Fix the MBK530 to the desired pole and
height without a speaker mounted.
The pole mount can be attached to poles
with a diameter ranging from 75 mm to
140 mm.
Tighten by closing the hose clamp.
Step 2:
Mount the loudspeaker to the pole mount
by securing it with the four M6 bolts pro-
vided.
The mounting holes on the pole mount are
tapped, making the use of nuts unneces-
sary.
MBK530 installation guide
