INSTALLATION MANUAL
MBK410C CEILING MOUNTING BRACKET FOR NOBA8(A)
STEP 1
Remove the rubber feet by unscrewing the mounting
screws
STEP 3
Attach the safety cable to the NOBA8(A) chassis
PARTS AND ACCESSORIES
A
E
STEP 2
Attach the mounting brackets with the screws removed
in step 1.
STEP 4
5
D
3
Attach the ceiling plate and the safety cable bracket in
the desired location using the appropriate screws for
your mounting surface.
Note:
A cable guide channel is provided on the ceiling
plate. We recommend using it to prevent cables from
touching the woofer.
B
1
2
3
M4x6
M6x12
x2
x2
x2
A
E
C
D
5
4
M8x16 M8x20
C
B
