Introduction
Thank you for purchasing the CATEYE V2c.
The V2c is a high-performance computer for riders who wish to train extensively and
analyze their data.
2.4GHz-frequency digital wireless technology, which is the same technology used for
wireless LAN, is used for both the speed/cadence integrated speed sensor. This technol-
ogy practically eliminates interference from external noise and cross-talk with other wire-
less computer users, providing you with stress-free riding.
Read this instruction manual thoroughly and understand the functions of the product
before using it.
Keep it in a safe place for future reference.
Important
• Always follow the sections that are marked with "
• No part of this manual may be reproduced or transmitted without the prior written
permission of CatEye Co., Ltd.
• The contents and illustrations in this manual are subject to change without notice.
• If you have any questions or concerns about this manual, please contact CatEye at
www.cateye.com.
About the manuals
Basic installation and operation
Please go here for installation of the unit on the bicycle, preparing the computer, and the
basic operation of the product.
1. How to install the unit on your bicycle ............... See page 6-8
2. Preparing the computer ..................................... See page 9-14
3. Basic operation of the computer ........................ See page 15-16
Measurement screen
Please go here to learn how to operate the computer functions.
• Measurement screen .......................................... See page 17-21
Ride data review
Please go here to check and manage recorded data
• File view ............................................................. See page 23-26
Changing computer configuration
Please go here for changing and checking each menu items.
• Changing the computer configuration ................ See page 22-33
Advanced use
• Recording lap and split time data ....................... See page 19 "Lap function"
• Training with target cadence zone ...................... See page 34
Warning!!!".
"Use of the target zone"
ENG-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC-TR200DW (V2c) and is the answer not in the manual?

Questions and answers

Related Manuals for Cateye CC-TR200DW (V2c)

Summary of Contents for Cateye CC-TR200DW (V2c)

  • Page 1 • No part of this manual may be reproduced or transmitted without the prior written permission of CatEye Co., Ltd. • The contents and illustrations in this manual are subject to change without notice. • If you have any questions or concerns about this manual, please contact CatEye at www.cateye.com. About the manuals...

  • Page 2: Table Of Contents

    Changing the computer About the manuals ... 1 configuration ... 22 File view (FILE VIEW) ... 23 Proper use of the CatEye V2c ... 3 Setting the clock/date Description of computer and its parts ... 4 (CLOCK.DATE) ... 27 Computer ... 4 Wheel selection and tire Accessories ...

  • Page 3: Description Of Computer And Its Parts

    Description of computer and its parts Computer Front Back-light button (LT) Start / stop / enter button (SSE) Back Battery cover All clear button (AC) Menu button (MENU) Accessories Bracket / Speed sensor Bracket band (SPEED/CADENCE) Wheel magnet Cadence magnet ENG-4 Screen display Indicate Speed sensor signal status.

  • Page 4: Attach The Bracket To The Stem Or Handlebar

    How to install the unit on your bicycle 1. Attach the bracket to the stem or handlebar The Flex Tight ™ bracket can be attached to either the stem or the handlebar depend- ing on how the bracket and band are configured. Caution: Tighten the dial on the bracket band by hand only.

  • Page 5: Remove/Install The Computer

    2-3. Adjust the distance to the magnet 1. Adjust the distance between the wheel magnet and the SPEED side of the speed sensor to be about 3 mm. After adjustment, tighten the setscrew on the SPEED side. 2. Adjust the distance between the cadence About 3 mm magnet and the CADENCE side of the speed sensor to be about 3 mm.

  • Page 6: Formatting/Restarting Operation

    1. Formatting/Restarting operation Formatting operation (At initial purchase, or reset all to default.) Caution: All data are reset to the default and deleted. 1. While pressing the MENU button on the back of the computer, press AC button. Release the MENU button when a test pattern is displayed on the screen.

  • Page 7: Tire Circumference Input

    3. Tire circumference input Enter the tire circumference of the bicycle wheel in millimeter. 1. Enter the last 2 digits of the tire circumference. Enter using the M1/+ and M2/- buttons, and move digits using the SSE button. Then, enter the first 2 digits in the same way.

  • Page 8: Selecting Speed Unit

    5. Selecting speed unit Select the speed unit from “km” and “mile”. 1. Select the speed unit. ↔ ↔ mile: ↔ ↔ km ↔ M1/+ (or) M2/- 2. After selecting, press the MENU button. The measurement screen appears and the computer set-up is completed. 6.

  • Page 9: Starting/Stopping The Measurement

    Starting/Stopping the measurement Initially, the unit starts or stops measurement automatically in sync with the bicycle motion. This is called auto-mode function. “km/h” or “mph” flashes during measurement. The total distance, maximum speed, and maximum cadence are up- dated independently of stating/stopping measurement. Auto-mode function When the auto-mode is turned on ( lights up), the unit detects...

  • Page 10: Lower Display Data

    Lower display data Elapsed time Displays the elapsed time from the start of measurement to the 1/10 second. When it exceeds 99:59’59”, it repeats from 00’00”0. * When the elapsed time reaches 1 hour, the 1/10 second is not displayed. M2/- Trip distance Displays the trip distance from the start of measurement.

  • Page 11: Countdown Distance

    Lap time and split time The lap time displays elapsed time from the last press of the LAP button. The split time displays the elapsed time from the start of measurement to the point LAP button is pressed. * The measured lap data is saved to a file when you perform a reset operation (page 16) and can be reviewed in “File view”...

  • Page 12: Changing The Computer Configuration

    Changing the computer configuration Pressing the MENU button in the measurement screen switches to the menu screen. In the menu screen, you can view and delete the files saved, and view and change various configurations. * Use the M1/+ and M2/- to change menu items. * After changes are made, be sure to review the setting(s) and confirm by pressing the MENU button.
  • Page 13 2. Select the file using the M1/+ and M2/- buttons, and confirm with the SSE button. Switching the file number: M1/+ (or) M2/- 3. Scroll through the data saved in each file by pressing the SSE button. The display items are as follows. When the CDC target zone is set to OFF Various average...

  • Page 14: Setting The Clock/Date (Clock.date)

    Deleting files Delete the file saved in the computer. You can select deleting only the file specified, or all files. Switch to the menu screen “File view” (page 23). 1. Simultaneously press the SSE button and the M1/+ or M2/- button to switch to the deleting screen.

  • Page 15: Wheel Selection And Tire Circumference (Wheel)

    M2/- Wheel selection and tire circumference Switch the Wheel Size (A / B), and change the Tire Size (tire roll out length). * For the tire size, see “Tire circumference” (page 12). 1. Press the MENU button in the measurement screen to switch to the menu top screen.

  • Page 16: Setting The Measurement Unit (Unit)

    M2/- Setting the measurement unit Change the unit (km or mile). * Stop measurement and perform the resetting operation (page 16) before you change the unit. Unless you perform the resetting operation, “DATA RESET” appears on the screen, preventing from changing the unit. 1.

  • Page 17: Setting Sound (Sound)

    M2/- 2. Enter the target distance using the M1/+ and M2/- buttons, and move digits using the SSE button. * The target distance can be set to the 0.1 km. Increase/decrease: M1/+ Move digits: (or) M2/- 3. Pressing the MENU button returns to the menu top screen (C.D.DST→...

  • Page 18: Cdc.zone

    * On/off of the alarm sound is selected from the menu screen “Setting sound” (page 32). ENG-34 Trouble shooting If a malfunction occurs, check the following before contacting CatEye or your retailer for repair or service. Trouble on display Display motion be- comes slower.

  • Page 19: Trouble On Operation

    Trouble on operation Trouble Check Items Pressing the SSE button Check whether the auto- When does not start/stop mode is turned on (with is on; you cannot start or stop mea- measurement. illuminating). surement by pressing the button. Turn off the auto-mode. (See “Setting the auto-mode”...

  • Page 20: Maintenance

    Maintenance Perform the daily care according to the following instructions. • Regularly check that the positions of the magnets and sensors are correct, and they are secured firmly. • When the computer, and speed/cadence are dirty, wash them with water or wipe them with a soft cloth dampened with diluted neutral detergent, then wipe with dry cloth.

  • Page 21: Registration

    CatEye products are warranted to be free of defects from materials and workmanship for a period of two years from original purchase. If the product fails to work due to normal use, CatEye will repair or replace the defect at no charge. Service must be performed by CatEye or an authorized retailer.
