Swave-E2 / Swave-W Electronic Speed Controller
User Manual v1.0
In this document mentioned and included how to use the product / cautions / maintains / warranty /
disclaimer / terms & conditions
Introduction
Thank you for choosing Swave E2 & W Electronic Speed Controller, its novel technology provides smoothest and
ultra-efficient performance. Please, read this manual and terms and conditions carefully before installing your new
Swave E electronic speed controller. All Ensotech products was sealed with a label shows the hyper link to download
this manual.
Once the seal is broken and the package opened, the acceptance of the below
Terms and conditions :
https://shop.ensotech.ltd/index.php?route=information/information&information_id=5
Warranty:
https://shop.ensotech.ltd/index.php?route=information/information&information_id=14
If you have any queries and uncertain please do not open the package, consults with your seller or Ensotech.
Registered Trademark
ENSOTECH is registered trademarks of Ensotech Limited.
All other brands mentioned in this guide are protected by copyright being the property of their respective owners.
Safety Precautions and Maintenance
-
.
Not for children under 14 years old. This is not a toy
-Swave E needs NO external capacitors or any other rework.
-Use Ensotech certified sensored motor with Ensotech Brushless ESC for best performance and protection.
-Using a not approved sensored motor may result in excessive current draw due to advance motor timing and may
cause severe ESC damage that will not be covered by product's warranty!
- Swave E ESC is a high end racing product that offers many customized parameters. If you are not certain about any
of the settings, contact your dealer for assistant or contact us.
-Do not overload motor due to incorrect/high gear ratios. Make sure the gear mesh is set properly. If the mesh is too
loose it can cause motor and ESC overheat which will damage the ESC and motor.
- Do not allow motor, ESC and battery in contact with water or other fluids, this could cause internal shortcut and
damage.
- Disconnect and remove the battery when ESC is not used.
-To prevent the runaway of your R/C car model, do not connect battery to the ESC or switch on the ESC without
switching-on the transmitter.
-Plug-in and solder connections may loose due to vibrations or collisions. Please, ensure secure connections,
otherwise you may experience a short-circuit which will damage the device.
-Always switch off the ESC before connect and disconnect programming cable.
